V-tech BLUEY JOTBOT Manual de usuario

Instruction

Manual

Included in the Package

* 2 of the data chips are for saving codes in Code-to-Draw mode.

WARNING:

All packing materials such as tape, plastic sheets, packaging locks,

removable tags, cable ties, cords and packaging screws are not part of

this toy and should be discarded for your child’s safety.

WARNING:

Please save this Instruction Manual as it contains important information.

1 JotBot 15 Double-sided

Drawing Data Chips*

1 Guidebook

1 Storage Box

1 Child-Friendly

Felt Tip Pen

Features

Switch to either or to power JotBot ON.

Switch to to power JotBot OFF.

Press this to confirm, to start an activity or to start drawing.

Command JotBot to move forwards (north) in Code-to-Draw mode.

Command JotBot to move backwards (south) in Code-to-Draw mode.

Command JotBot to move to your left (west) in Code-to-Draw mode.

It can also turn the volume down in other modes.

Command JotBot to move to your right (east) in Code-to-Draw mode.

It can also turn the volume up in other modes.

Command to toggle JotBot’s pen position up or down in

Code-to-Draw mode.

Press this to cancel or to exit an activity.

Animated Face

Control Panel

Power /

Mode Switch

Speaker

Data chip slot

Battery compartment

Pen

Holder

INSTRUCTIONS

BATTERY REMOVAL AND INSTALLATION

1. Make sure the unit is turned OFF.

2. Locate the battery cover at the bottom of the unit. Use a screwdriver

to loosen the screws and then open the battery cover.

3. If used batteries are present, remove these

batteries from the unit by pulling up on one

end of each battery.

4. Install 4 new AA (AM-3/LR6) batteries

following the diagram inside the battery

box. (For best performance, alkaline

batteries are recommended.

Rechargeable batteries are not

guaranteed to work with this product).

5. Replace the battery cover and tighten the screws to secure.

IMPORTANT: BATTERY INFORMATION

• Insert batteries with the correct polarity (+ and -).

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or rechargeable batteries.

• Only batteries of the same or equivalent type as recommended are to

be used.

• Do not short-circuit the supply terminals.

• Remove batteries during long periods of non-use.

WARNING:

Adult assembly required for battery installation.

Keep batteries out of reach of children.

Switch to either or to power JotBot ON.

Switch to to power JotBot OFF.

Press this to confirm, to start an activity or to start drawing.

Command JotBot to move forwards (north) in Code-to-Draw mode.

Command JotBot to move backwards (south) in Code-to-Draw mode.

Command JotBot to move to your left (west) in Code-to-Draw mode.

It can also turn the volume down in other modes.

Command JotBot to move to your right (east) in Code-to-Draw mode.

It can also turn the volume up in other modes.

Command to toggle JotBot’s pen position up or down in

Code-to-Draw mode.

Press this to cancel or to exit an activity.

TROUBLESHOOTING

If for some reason the program/activity stops working or malfunctions,

please follow these steps:

1. Please turn the unit OFF.

2. Interrupt the power supply by removing the batteries.

3. Let the unit stand for a few minutes, then replace the batteries.

4. Turn the unit ON. The unit should now be ready to play with again.

5. If the product still does not work, install a brand new set of batteries.

If the problem persists, please contact our Consumer Services Department,

and a service representative will be happy to help you. 6

• Remove exhausted batteries from the toy.

• Dispose of batteries safely. Do not dispose of batteries in fire.

RECHARGEABLE BATTERIES:

• Remove rechargeable batteries from the toy before charging.

• Rechargeable batteries are only to be charged under adult

supervision.

• Do not charge non-rechargeable batteries.

CARE & MAINTENANCE

1. Keep the unit clean by wiping it with a slightly damp cloth.

2. Keep the unit out of direct sunlight and away from any direct heat

sources.

3. Remove the batteries if the unit will not be in use for an extended

period of time.

4. Do not drop the unit on hard surfaces and do not expose the unit

to moisture or water.

Disposal of batteries and product

The crossed-out wheelie bin symbols on products and

batteries, or on their respective packaging, indicates they

must not be disposed of in domestic waste as they contain

substances that can be damaging to the environment and

human health.

The chemical symbols Hg, Cd or Pb, where marked, indicate

that the battery contains more than the specified value of

mercury (Hg), cadmium (Cd) or lead (Pb) set out in the

Batteries and Accumulators Regulation.

The solid bar indicates that the product was placed on the

market after 13th August, 2005.

Help protect the environment by disposing of your product or

batteries responsibly.

VTech®cares for the planet.

Care for the environment and give your toy a second life by disposing

of it at a small electricals collection point so all its materials can be

recycled.

In the UK:

Visit www.recyclenow.com to see a list of collection points near you.

In Australia & New Zealand:

Check with your local council for kerbside collections.

Getting Started

Insert Batteries

(To be done by an adult)

• Locate the battery compartment at the bottom of JotBot.

• Loosen the screws of the battery cover using a screwdriver.

• Insert 4 AA alkaline batteries as indicated inside the

battery compartment.

• Replace the battery cover and tighten the screws.

See p.4 for more information about battery installation.

Install Pen

• Place a scrap sheet of paper under JotBot.

• Turn On JotBot.

• Remove the cap of the bundled pen and insert it into the

pen holder.

• Push the pen gently down until it reaches the paper, and

then release the pen. The pen should rebound slightly

above the paper by around 1-2mm.

NOTE: To prevent the pen's ink from drying, please

replace the cap of the pen when it is not in use for a long

period of time.

1-2mm

Setup Paper

• Prepare an A4 or larger sheet of paper.

• Place it on a flat, level surface. Keep the paper at

least 10cm away from the edge of the surface to

avoid JotBot from falling.

• Clear any obstacles on or near the paper. Then, place

JotBot in the centre of the paper before JotBot begins

to draw.

NOTE: Tape the 4 corners of the paper to the surface for

the best drawing performance. Put an extra piece of

paper on the surface to protect the surface from staining.
