V-tech 527703 Instrucciones de montaje

Parent's Guide

4-In-1 Ride-On Fawn

INTRODUCTION

Speed into learning with the VTech®4-In-1 Ride-On Fawn!

This 4-in-1 grow with me fawn includes modes for ride-on play, push

walker, scooter and a shape sorting wagon. Little ones can grow and

develop with the fawn. The five light up buttons along with the Learn,

Explore and Music modes introduce the animal characters and

sounds, colours and play melodies and sing-along songs. The four

shape sorting pieces add to the learning and provide little ones with

the opportunity to problem solve.

Mode Switch

On/Off/Volume

Switch

Five Light Up

Buttons

Shape Sorter

Green Lock

INCLUDED IN THE PACKAGE

• 4-In-1 Ride-On Fawn

Fawn Head Wagon Body

Scooter Base Walker Handle

2 Rear Wheels 1 Set of Front Wheels

2 Handlebars 3 Shape Blocks 16 Scews

• Quick Start Guide

WARNING

All packing materials such as tape, plastic sheets, packaging locks,

removable tags, cable ties, cords and packaging screws are not part

of this toy, and should be discarded for your child’s safety.

NOTE

Please save this Parent's Guide as it contains important information.

WARNING!

This toy should be used in a safe area e.g indoors, in a private

garden, on level flat surfaces and away from any hazards such as

cars, stairs, water etc.

Not for use on pavements or in traffic.

Adult supervision is advised.

Please help your child to sit properly on the seat and to use the toy

correctly.

This toy should be used with caution to avoid falls or collisions that

could cause injury to the user or third parties.

Warning! Protective equipment should be worn. Not to be used in

traffic. 20 kg Max.

Please wear helmet, gloves, knee pads and elbow pads.

CAUTION:

Adult assembly required.

This package contains small screws.

For your child’s safety, do not let your child play with the toy until it is

fully assembled.

GETTING STARTED

BATTERY REMOVAL AND INSTALLATION

1. Make sure the unit is turned Off.

2. Find the battery cover on the back of

the electronic activity panel. Use a

screwdriver to loosen the screw and then

open the battery cover.

3. If used batteries are present, remove

these batteries from the unit by pulling

up on one end of each battery.

4. Install 3 new AA batteries following the

diagram inside the battery box. (For best

performance, alkaline batteries or fully

charged Ni-MH rechargeable batteries

are recommended).

5. Replace the battery cover and tighten the

screw to secure.

WARNING:

Adult assembly required for battery installation.

Keep batteries out of reach of children.

IMPORTANT: BATTERY INFORMATION

• Insertbatterieswiththecorrectpolarity(+and-).

• Donotmixoldandnewbatteries.

• Donotmixalkaline,standard(carbon-zinc)orrechargeable

batteries.

• Onlybatteriesofthesameorequivalenttypeasrecommended

are to be used.

• Donotshort-circuitthesupplyterminals.

• Removebatteriesduringlongperiodsofnon-use.

• Removeexhaustedbatteriesfromthetoy.

• Disposeofbatteriessafely.Donotdisposeofbatteriesinfire.

RECHARGEABLE BATTERIES

• Removerechargeablebatteriesfromthetoybeforecharging.

• Rechargeablebatteriesareonlytobechargedunderadult

supervision.

• Donotchargenon-rechargeablebatteries.

Disposal of batteries and product

The crossed-out wheelie bin symbols on products and

batteries, or on their respective packaging, indicates they

must not be disposed of in domestic waste as they contain

substances that can be damaging to the environment and

human health.

The chemical symbols Hg, Cd or Pb, where marked,

indicate that the battery contains more than the specified

value of mercury (Hg), cadmium (Cd) or lead (Pb) set out

in the Batteries and Accumulators Regulation.

The solid bar indicates that the product was placed on the

market after 13th August, 2005.

Help protect the environment by disposing of your product

or batteries responsibly.

VTech®cares for the planet.

Care for the environment and give your toy a second life by

disposing of it at a small electricals collection point so all its

materials can be recycled.

In the UK:

Visit www.recyclenow.com to see a list of collection points near you.

In Australia & New Zealand:

Check with your local council for kerbside collections.

ASSEMBLY INSTRUCTIONS

With the 4-In-1 Ride-On Fawn, safety comes first. To ensure your

child’s safety, adult assembly is required.

1. Attach the set of Front Wheels to the

underside of the Scooter Base. Use

six of the Screws to secure.

2. Attach the two Rear Wheels to the

underside of the Scooter Base. Use

eight of the Screws to secure.

3. Insert the Handlebars into either

side of the Fawn Head. You will

hear the Handlebars click into place

when inserted correctly. Once the

Handlebars have been attached, they

cannot be removed.

4. Push the Fawn Head onto the

Scooter Base. You will hear the Fawn

Head click into place when inserted

correctly. Turn the Scooter Base over

and use two of the Screws to secure.

5. Attach the Wagon Body to the Scooter

Base. You will hear the Wagon

Body click into place when inserted

correctly.

6. Insert the Walker Handle into the top

of the Scooter Base, then push and

turn the Green Lock clockwise to

secure the Walker Handle. Use the

Walker Handle to push or pull the

fawn.

WARNING:

Not to be used by children over 36 months. Insufcient

strength. Protective equipment should be worn. Not to be

used in trafc. 20kg Max. Regularly check for signs of wear or

tear on the snap in or locking devices. If damaged do not use

until repaired or replaced. Only to be used under the direct

supervision of a competent adult.

Convert from Ride-On Mode to Scooter Mode

1. Press the small green release button on the back of the Wagon

Body while rotating the Green Lock on the Walker Handle

anticlockwise, then pull the tab while removing the Wagon.

2. Insert the Walker Handle into the slot on the back of the Fawn

Head. Turn the Green Lock clockwise to secure the Walker

Handle. To remove the Walker Handle, press and hold the small

button on the left side of the handle while turning the Green Lock

anticlockwise.

3. You have the option to attach the Wagon

Body to the back of the Scooter. Insert

the hinge on the front of the Wagon Body

to the bottom of the Scooter Base. To

disconnect the Wagon Body, pull on the

hinge.

Convert from Ride-On Mode to Wagon

Mode

Remove the Wagon Body from the Scooter

Base and fold out the seat to make a pull

handle.
