V-tech 17450 Manual de usuario

For product support

please call: 1 300 369 193

Model:

VTech 17450

Quick Start Guide

GOT EVERYTHING?

The package contains the following items:

• VTech 17450 handset

• VTech 17450 base unit

• Power adaptor

• Telephone line cord and adaptor

• Battery compartment cover

• 3 x AAA rechargeable batteries

• Wall mount bracket

• User guide

• Quick start guide

If you have purchased a multi-handset pack there will be

an extra handset, charger, power adaptor, and three AAA

rechargeable batteries for each additional handset.

CONNECT

NOTE

• Use only the adaptors provided.

• Make sure the electrical outlets are not controlled by wall

switches.

• The adaptors are intended to be correctly oriented in

a vertical or oor mount position. The prongs are not

designed to hold the plug in place if it is plugged into a

ceiling, under-the-table or cabinet outlet.

CONNECT THE TELEPHONE BASE

CONNECT THE HANDSET CHARGER

(FOR 17450 MULTI-HANDSET PACKS ONLY)

INSTALL THE HANDSET BATTERY

1. Slide open the battery compartment cover.

2. One by one, insert 3 AAA batteries into the battery

compartment, according to the polarity.

3. Slide the battery compartment cover back into place,

until you hear a click sound.

NOTE

• Use only the batteries provided.

• If the handset will not be used for a long time, disconnect

and remove the batteries to prevent possible leakage.

CHARGE THE BATTERIES

Place the handset in the telephone base to charge.

DATE AND TIME SETTINGS

You will need to set the correct time and date so that you

know when you received answering machine (applicable

to model with answering machine) or call log entries.

SET THE DATE FORMAT

1. Press MENU/OK and / to select HS SETTINGS.

2. Press MENU/OK and / to select CLOCK.

3. Press MENU/OK and / to select DATE FORM.

4. Press MENU/OK and / to select your desired

date format (DD-MM-YY or

MM-DD-YY).

5. Press MENU/OK to conrm.

SET THE TIME FORMAT

1. Press MENU/OK and / to select HS SETTINGS.

2. Press MENU/OK and / to select CLOCK.

3. Press MENU/OK and / to select TIME FORM.

4. Press MENU/OK and / to select your desired

time format (12 HR or 24 HR).

5. Press MENU/OK to conrm.

SET THE DATE AND TIME

1. Press MENU/OK and / to select HS SETTINGS.

2. Press MENU/OK and / to select CLOCK.

3. Press MENU/OK and / to select SET DATE.

4. Press MENU/OK then enter the date according to

DD-MM-YY or MM-DD-YY format. The date will be in

the format you set.

5. Press MENU/OK then enter the time information

according to 12 HR or 24 HR format. The time will be

in the format you set.

6. Press MENU/OK to conrm.

ANSWERING MACHINE

ANNOUNCEMENT

The announcement is the message a caller rst hear

when the answering machine answers their call. There

is a pre-recorded announcement message or you can

record your own.

RECORD YOUR OWN ANNOUNCEMENT

1. Press MENU/OK when the phone is not in use.Then,

press / to scroll to ANS. SYS.

2. Press MENU/OK and / to scroll to SET TAM.

3. Press MENU/OK and / to scroll to TAM MSG.

4. Press MENU/OK and / to scroll to RECORD.

5. Press MENU/OK. The handset displays

RECORDING.... Now speak into handset to record

your message.

6. Press MENU/OK to conrm your selection.

SOS EMERGENCY CALLS

You need to set the SOS numbers before you can make

SOS Emergency Calls.

PROGRAM THE SOS NUMBER

1. Press MENU/OK when the phone is not in use, and

then press / to scroll to SET SOS.

2. Press MENU/OK and / to scroll to SOS NUMBER.

3. Press MENU/OK and / to scroll to SOS 1, SOS 2,

SOS 3, SOS 4, or SOS 5.

4. Press MENU/OK twice to select ADD.

5. Enter the SOS emergency number, and then press

MENU/OK.

6. Enter the name for the SOS emergency number, and

then press MENU/OK.

RECORD YOUR SOS MESSAGE

The SOS message is your own recorded message to be

played directly when you make an emergency call. The

default SOS message is “This is an emergency call.

Please press any number key to start the conversation.”

You can record your own message using the handset.

Make sure your SOS message recorded includes your

name,the SOS message, and a request to far end on

pressing any number key to start the conversation. You

can also playback and listen to your SOS message or

delete it.

1. Press MENU/OK when the phone is not in use, and

then press / to scroll to SET SOS.

2. Press MENU/OK and / to scroll to SOS MSG.

3. Press MENU/OK and / to scroll to RECORD.

4. Press MENU/OK and the handset displays

RECORDING. Now speak into handset to record your

message.

5. Press MENU/OK to conrm.
