Uwatec Z1 Manual de usuario
User Manual
2
The manually initiated dive mode is compliant with the European standard
EN13319.
Welcome to the SCUBAPRO Z1 and thank you for purchasing the Z1. You
are now the owner of an extraordinary partner for your dives. This manual
provides you with easy access to the Z1’s key features and functions.
IMPORTANT
• Before using, please make sure your new Z1 is full charged.
• Information on checking the battery power can be found on page 13.
The Z1 does not conform to 100m diver watches stated in ISO6425 and
JISB7023.
Authentication Standard
R&TTE
EN 60950-1
EN 300 328
EN 301 489-1
EN 301 489-17
EN 62479
FCC FCC Part 15
3
1. Introduction
• The Z1 is a dive computer designed to support safer no-decompression
diving.
• The Z1 is powered by a rechargeable battery. Recharging is accom-
plished by way of an integrated solar panel that generates the neces-
sary electrical power.
• The Z1 offers multiple functions: dive computer, wristwatch, alarm,
timer, stopwatch, compass, etc. In Dive Mode, information on depth,
water temperature, dive time, ascent speed and decompression are
provided. In Surface Mode, the Z1 provides surface interval time and
desaturation time (Desat time). In Watch Mode, it acts as a world time
watch.
• The Z1 is capable of programming up to 4 different Nitrox gases. Com-
prehensive accelerated decompression is possible because the oxygen
(O2) level can be set from 21% to 100% in 1% increments.
• The calculation model used for the Z1’s decompression program
is based on the decompression theory of Dr.A.A.Bühlmann (Bühl-
mannZHL16C Algorithm).
Before using the Z1 it is important that you understand all of its warnings
and cautions as outlined in this user manual.
To avoid serious accidents, please make sure to read this user manual
thoroughly to enable you to fully understand the Z1. If you have any ques-
tions, contact the dealer where you purchased your Z1.
NOTE: As you engage in your diving activities, it is recommended that you
always have access to this user manual. Understanding the use and func-
tions of the Z1 ensures safer and more enjoyable diving.
WARNING
4
2. Features & Functions
The Z1 provides the following functions.
• Solar power to charge the battery.
Generates electricity from the sun and other light sources.
• Directional compass bearing.
You can check the direction and current position of selected target.
• Alarm setting (in Watch Mode).
When the set time arrives, the Z1 issues an audible alarm.
• Can be used as a stopwatch.
Measures elapsed time.
• Can be used as a timer (in Watch Mode).
Counts down a pre-set time;
announces time-out with an audible alarm.
• Provides World Time (in Watch Mode).
Displays the time of 48 cities from around the world.
• Transfers data using Bluetooth SMART.
Enables the wireless transmission of log and profile data.
• Multi-gas capable.
Provides gas settings and switching for up to 4 gas mixes
5
3. Safety Precautions
Illustrations and graphics used in this user manual, and also on the display
screen of the Z1 itself, incorporate various labels, icons and terms to ad-
vise you of the correct way to operate your Z1 to prevent harm or damage
to you as well as to other people. This user manual also provides adviso-
ries, defined as follows:
If you ignore this serious alert and handle the product incorrectly, there is
a risk of death or serious injury.
If you ignore this warning and handle the product incorrectly, there is a
risk of death or serious injury.
If you ignore this cautionary indicator and handle the product incorrectly,
situations can be created that can cause injury to a person or may cause
physical damage.
DANGER
WARNING
CAUTION
6
Make sure that you completely understand how to use your Z1, as well
as all of the warnings and cautions outlined in this user manual, before
taking your Z1 into the water. It is recommended that you use your Z1 in a
closed water or pool environment before using it in open water.
Before using your Z1 in a scuba diving situation, you need to first take a
scuba training course and obtain a certification card issued by one of the
internationally acknowledged dive training organizations. (You can use
the Z1 while in training under the guidance of an instructor.)
Before using the Z1 for a Nitrox (Enriched Air Nitrox, or EANx) dive, you
need to complete a Nitrox dive training course. Otherwise, do not use your
Z1 for Nitrox diving. (EANx is a mixed gas containing 22%-100% O2.)
For safety’s sake, when diving with your Z1, also carry a secondary com-
puter, diver’s watch and/or depth gauge as a backup.
If a “decompression stop violation” warning and/or an “out of measure-
ment range” warning is displayed on your Z1, cancel your dive immediate-
ly and pay close attention to any changes in your physical condition.
If your Z1 fails at any time during a dive, that dive must be terminated
immediately, and dive training-prescribed surfacing procedures must
be initiated (including a slow ascent and a 3- to 5-minute safety stop at
15 ft/5m).
If you notice any abnormal performance with your Z1, stop using it imme-
diately and contact the dealer where you purchased your Z1.
DANGER
7
• Check to make sure the battery power level your Z1 is at “H” before
diving. In the event of a low power level, resulting in a warning
displayed while diving, safely exit the water as soon as possible and
recharge your Z1.
NOTE: If this low power warning comes on during a dive, there is still
sufficient power to safely end the dive, so there is no need to panic.
Deal with the situation calmly. Ref: Low Power Alarm • • • P.15
• Respond to any warnings or cautionary messages immediately.
• The Z1 should be used for recreational diving only. Do not use your Z1
for any other type of diving.
• Never lend or share your Z1 with another diver if residual nitrogen still
exists in your body after using the Z1.
• Make sure to set or check the O2% before every dive. It is extremely
dangerous when the O2% in the tank and the Nitrox setting on the Z1
don’t match.
• Do not disassemble, repair, modify, or exchange the rechargeable
battery or conduct pressure chamber tests on the Z1 by yourself. This
is extremely dangerous and may cause a malfunction. Please see an
authorized SCUBAPRO dealer for any maintenance needs.
• The Z1 is designed for dives using compressed air (21% 02) and Nitrox
(22% to 100% 02). The Z1 cannot be used with any other mixed gas.
• Each diver should be responsible for planning and conducting the
safest dives possible in accordance with his or her diving skills and
physical condition.
• Please practice safe diving. Do not exceed the displayed data on your
Z1. The Z1 cannot prevent you from developing decompression illness
completely.
• The Z1 does not measure, display or control the air pressure in your
tank. Use a separate submersible pressure gauge to monitor your tank
pressure.
• If the rechargeable battery is removed from your Z1, make sure that
small children do not swallow it. Put the battery out of reach of chil-
dren. If swallowed, contact a doctor at once.
WARNING
8
• Since the metal parts of the Z1’s casing and wristband can trap dirt
and contaminants which could soil the sleeves of clothing, please
keep your Z1 clean at all times. After immersion in sea water, wash
thoroughly with fresh water to avoid any corrosive build-up.
• Because the main casing and wristband come in direct contact with
the skin, there is risk of a skin rash caused by:
1. Dirt, rust and sweat on the casing and/or wristband as a result of
poor maintenance.
2. Allergies to metal and resin.
3. Physical condition, etc.
• Wearing the wristband too tight increases sweat and reduces airflow
between band and skin, making it much easier to develop a rash.
Therefore, for everyday use it is recommended that you wear your Z1
on your wrist slightly looser rather than tighter. In the unlikely event
that a rash appears, discontinue use and consult a doctor.
• To prevent unexpected injuries and allergic rashes, remove your Z1 at
bedtime. Also, when holding or touching an infant, remove your Z1 to
prevent rashes caused by allergies or other medical conditions.
• Always ensure that log data are stored separately from your Z1 by
keeping a written log or by transferring data to a PC. A malfunction,
necessary repair or dead battery could cause stored data to disappear.
• Please be sure to remove any product protection stickers before using
your Z1. If you use your Z1 without first peeling off the stickers, dirt
can become trapped which may cause rust and skin irritation.
• Don’t drive a car or operate a boat while wearing your Z1 with the Au-
to-Light function turned on. The light could be distracting and might
hinder driving which could be dangerous.
• The danger of explosion exists if the Z1’s battery is incorrectly
installed. The battery must be replaced with the same or equivalent
model. Please go to your authorized SCUBAPRO dealer for any battery
replacement needs.
• Do not expose your Z1 to excessive heat such from intense sunlight,
fire, etc.
CAUTION
9
TABLE OF CONTENTS
1. Introduction•••••••••••••••••••••••••••••••••••••••••••••••••••••• 3
2. Features & Functions••••••••••••••••••••••••••••••••••••••••• 4
3. Safety Precautions•••••••••••••••••••••••••••••••••••••••••••• 5
4. Things To Check Before Using the Z1••••••••••••••••••• 13
4-1. Check the Battery Power Level••••••••••••••••••••••••••••••••••••••••• 13
4-2. Charging with Light (Solar Charge)•••••••••••••••••••••••••••••••••• 13
4-3. How to Charge•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 13
4-4. Insufficient Charge or Out of Charge ••••••••••••••••••••••••••••••• 14
4-5. Charging Times •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 15
4-6. Low Power Alarm•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 15
4-7. Power Saving•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 16
5. Mode Reference Guide ••••••••••••••••••••••••••••••••••••••• 17
5-1. Mode Functions•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 17
5-2. Button Operation and Switching Mode •••••••••••••••••••••••••••• 18
6. Setting Your Z1•••••••••••••••••••••••••••••••••••••••••••••••••• 20
6-1. Configure Home City and Daylight Saving Time Settings •••••• 22
6-2. Select 12-Hour or 24-Hour Clock •••••••••••••••••••••••••••••••••••• 24
6-3. Set Current Time and Date••••••••••••••••••••••••••••••••••••••••••••••• 25
6-4. Set Button Operation Sound•••••••••••••••••••••••••••••••••••••••••••• 26
6-5. Select Backlight Duration •••••••••••••••••••••••••••••••••••••••••••••••• 27
6-6. Set Power Saving ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 28
6-7. Set Units of Measure ••••••••••••••••••••••••••••••••••••••••••••••••••••••• 29
6-8. Set the MMDD/DDMM Display •••••••••••••••••••••••••••••••••••••••••• 30
6-9. Main Display Setting in Dive Mode ••••••••••••••••••••••••••••••••••• 31
6-10. Set Auto Light •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 32
10
7. Watch Mode / Surface Mode(TIME) ••••••••••••••••••••• 33
7-1. Displayed Contents of Surface Mode••••••••••••••••••••••••••••••• 34
8. Dive Mode (DIVE) ••••••••••••••••••••••••••••••••••••••••••••••• 35
8-1. How to Switch the Mode to Dive Mode ••••••••••••••••••••••••••••• 35
8-2. No Decompression Mode ••••••••••••••••••••••••••••••••••••••••••••••••• 36
8-3. Safety Stop •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 37
8-4. Decompression Dive •••••••••••••••••••••••••••••••••••••••••••••••••••••••• 38
8-5. Warnings in Dive••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 39
8-6. Gas O2% Confirmation / Gas Switch •••••••••••••••••••••••••••••••• 42
9. Log Mode (LOG)•••••••••••••••••••••••••••••••••••••••••••••••••• 43
9-1. Confirm the Dive History •••••••••••••••••••••••••••••••••••••••••••••••••• 43
9-2. Correction Function of Dive Number in Dive History•••••••• 44
9-3. Check the Dive Log••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 44
9-4. Warnings Recorded in the Log ••••••••••••••••••••••••••••••••••••••••• 48
9-5. Setting the Dive Profile Sampling Rate•••••••••••••••••••••••••••• 48
9-6. Oxygen Uptake/ppO2Profile Saving Setting •••••••••••••••••••• 49
9-7. Check the Dive Profile••••••••••••••••••••••••••••••••••••••••••••••••••••••• 49
10. Plan Mode(PLAN)••••••••••••••••••••••••••••••••••••••••••••• 52
10-1. O2% Setting•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 52
10-2. Enriched Air Nitrox(EANx) Diving ••••••••••••••••••••••••••••••••••• 53
10-3. Default Function of O2%••••••••••••••••••••••••••••••••••••••••••••••••• 53
10-4. Set Safety Factor ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 54
10-5. Depth Interval Alarm setting•••••••••••••••••••••••••••••••••••••••••• 55
10-6. Maximum Water Depth Warning Settings•••••••••••••••••••••• 56
10-7. Plan Diving ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 57
10-8. Display the Oxygen Toxicity Unit(OTU(UPTD)) ••••••••••••••• 57
Otros manuales para Z1
1
Tabla de contenidos
Otros manuales de Mirar de Uwatec
