UTStarcom F1000 Series Manual de usuario

REGULATORY STATEMENT (R&TTE /

WLAN IEEE 802.11B)

European standards dictate maximum radiated transmit power of 100mW

EIRP and frequency range 2.400-2.4835GHz; In France, the equipment

must be restricted to the 2.4465-2.4835GHz frequency range and must be

restricted to indoor use.

CE DECLARATION OF CONFORMITY

For the following equipment: WiFi handset F1000

Is herewith confirmed to comply with the requirements set out in the Council

Directive on the Approximation of the Laws of the Member States relating to

Electromagnetic Compatibility (89/336/EEC), Low-voltage Directive

(73/23/EEC) and the Amendment Directive (93/68/EEC), the procedures

given in European Council Directive 99/5/EC and 89/3360EEC.

The equipment was passed. The test was performed according to the

following European standards:

 EN 300 328 V.1.4.1 (2003-04)

 EN 301 489-1 V.1.3.1 (2001-09) / EN 301 489-17 V.1.1.1 (2000-09)

 EN 50371: 2002

 EN 60950: 2000

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

FCC RF EXPOSURE COMPLIANCE

This PCS phone has been tested and complies with the Federal

Communications Commission (FCC) RF exposure limits for the General

Population/Uncontrolled exposure environment. In addition, it complies with

the following Standards and Guidelines:

 FCC 96-326, Guidelines for Evaluating the Environmental Effects of

Radio-Frequency Radiation

 FCC OET Bulletin 65 Edition 01-01 (2001) Supplement C, Evaluating

Compliance with FCC Guidelines for Human Exposure to Radio

Frequency Electromagnetic Fields

 ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect

to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz

to 300 GHz

 ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the

Measurement of Potentially Hazardous Electromagnetic Fields - RF and

Microwave

 Note: For body-worn operation, this phone has been tested and

meets FCC RF exposure guidelines when used with an accessory

that contains no metal and when the back of the phone faces your

body.

 Use of other accessories may not ensure compliance with FCC RF

exposure guidelines.

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

1. BASIC OPERATIONS

1.1 Switch the Phone On/Off

Press and hold the power key to switch the phone on/off.

If the PowerOn Code function is active, after switching on the phone, enter

the security code and press the left soft key (Ok).

1.2 Access Menu/Names Options

1. In standby mode, press the left soft key (Menu) or the right soft key

(Names).

2. Press to reach the desired submenu, and then press the left soft

key (OK).

3. Repeat step 2 to reach the desired option.

 Note: To return to the previous menu level, press the right soft key

(Exit). To return to standby mode without changing the menu

settings, press .

1.3 Make a Call

1. Key in the phone number, or access Search and highlight the

desired phone number.

2. Press to call the number.

3. To end the ongoing call, press the right soft key (Hangup) or the

key.

 Note: Prior to making or receiving calls, the phone must be

connected to a wireless Access Point (AP) and registered with the

service network.

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

1.4 Use Speed Dial

If you have assigned a phone number to one of the speed dial keys ~

, you can quickly call that phone number:

1. In standby mode, press and hold the corresponding speed dial key to

automatically display the phone number.

2. Press to call the number.

1.5 Answer/Reject a Call

 To answer a call, press the left soft key (Answer) or the key

 To reject a call, press the right soft key (Hangup) or the key

 To stop the vibration or ring alert without picking up the incoming call,

press

1.6 Call Waiting

If the Call Waiting function is activated, when another call comes in during a

call, the earpiece will sound a waiting tone.

 To reject the incoming third party call and continue the current call,

press the right soft key (Hangup)

 To hold the current call and answer the incoming third party call, press

the left soft key (Answer)

1.7 In Call Operations

While on a call, you can perform the following operations:

 Press to increase or to decrease the listening volume

 Press to access the phonebook entry list (if the phonebook is not

empty)

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

 Press the left soft key (Option) and select from the following

options:

- Hold or Unhold: To take the call on/off hold

- New Call: To make a third party call

- Conference: To make a conference call (available only when the

Three Way Call function is active)

- Blind or Consult: To transfer the ongoing received call

- Mute: To mute the microphone volume

1.8 Keypad Lock

In standby mode, press and hold to lock the keypad. The indicator

will be displayed. To unlock the keypad, press and hold again.

2. PHONEBOOK (NAMES)

2.1 Add Phonebook Entries

You can add phone book entries in either of the following ways:

 In standby mode, key in the phone number and press the left soft key

(Save). Follow the prompts to enter the name and select the group

 Access Add Entry. Follow the prompts to enter the name and

phone number, and select the group

2.2 Search Phonebook Entries

In the phonebook entry list, press ~ to enter the first

letter(s)/digit(s) of the desired entry (name). A maximum of six letters/digits

can be entered. All names starting with these letter(s)/digit(s) will be

displayed.

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

2.3 Assign Phone Numbers to Speed Dial Keys

Access Speed Dial, press to select the desired speed dial

key. Press the left soft key (Set) to display the phonebook entry list.

Highlight the desired entry and press the left soft key (Ok) to assign the

number to the key.

3. MENU

In standby mode, press the left soft key (Menu) to access the menu.

The following submenus are available:

3.1 Call Log

Call Log

This submenu enables you to view missed call log (Missed Log), received

call log (Received Log) and outgoing call log (Dialed Log).

3.2 Profiles

Profiles

This submenu enables you to customize the phone alert settings to suit a

variety of environments. You can set the Ring Volume, Ring Mode, Ring

Tone, Alarm Tone, Keypad Tone and Alert Tone for a profile.

3.3 Settings

Settings

From this submenu, you can perform various phone settings, including:

Scheme, Date/Time, Answer Mode, Language, Display and Set

Security.

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

3.4 Tools

Tools

From this submenu, you can use the Calculator, view the Calendar, set

the Alarm, change the current Time Zone, perform DST Setting or set the

Time Format.

3.5 WiFi-Settings

WiFi-Settings

From this submenu, you can perform the following WiFi settings, including

Net Search, WiFi Config, Network Parameter and Signal Protocol.

 Note: After completing WiFi settings, switch the phone off and then

on, to apply the changed WiFi settings.

3.5.1 Net Search

WiFi-SettingsNet Search

This option enables you to search available APs for the phone. APs can be

defined and saved using the Net Search feature if APs have broadcast

turned on and the phone is within their ranges.

3.5.2 WiFi Config

3.5.2.1 AP Profile

WiFi-SettingsWiFi ConfigAP Profile

This option enables you to set up to four AP (Access Point) profiles. Each

time you switch on the phone, the phone will try to connect to one of these

APs according to their respective profile settings.

After you select this option, the AP profile list will be displayed. If the

security mode of an AP profile is set to WEP Key, the icon will be

displayed in front of the AP profile. If the security mode is set to WPA-PSK,

the icon will be displayed in front of the AP profile. If the security mode

is set to Open AP, no icon will be displayed in front of the AP profile.

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

Press to highlight the desired AP profile, and then press the left soft

key (Ok). The following options will be available:

SSID

This option enables you to save an AP’s SSID to the AP profile.

After accessing this option, enter the SSID (32 alphanumeric characters

maximum), and then press the left soft key (Ok) to complete the

operation.

Security Mode

This option enables you to set the security mode for the AP profile.

After accessing this option, select Open AP, WEP Key or WPA-PSK:

 If WEP Key is selected, the phone will then display the options of WEP

Key Info (refer to “WEP Key Info”)

 If WPA-PSK is selected, the phone will then display the PSK-editing

screen (refer to “WPA-PSK Info”)

WEP Key Info

If the AP profile’s security mode is set to WEP Key, select this option to set

the WEP key.After accessing this option, observe the following operations:

1. Select Auth Method, and then select the authentication method: Open

Key or Shared Key.

2. Select 64bit or 128bit according to the AP’s WEP key setting. Enter the

WEP key that the AP used, and press the left soft key (Ok).

- If 64bit is selected, ensure that the WEP key consists of five ASCII

characters or ten hexadecimal characters

- If 128bit is selected, ensure that the WEP key consists of 13 ASCII

characters or 26 hexadecimal characters

3. Select WEP Key Index. Enter the WEP key index (1-4), and then press

the left soft key (Ok).

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

 Note: The WEP key setting may be different due to AP settings.

If an AP supports only a fixed hexadecimal WEP key, you should

enter the same WEP key in the phone.

If an AP supports both ASCII and hexadecimal WEP keys, you can

enter either the ACSII WEP key or the hexadecimal WEP key in the

phone.

WPA-PSK Info

If the AP profile’s security mode is set to WPA-PSK, select this option to set

the WPA-PSK key.

After accessing this option, enter the WPA-PSK key and press the left soft

key (Ok) to complete the operation.

 Ensure that the WPA-PSK key consists of 8-63 ASCII characters or 64

hexadecimal characters

Activate

Select this option to connect to the AP according to the AP profile setting. If

the connection fails, the phone will try to connect to other AP profiles’APs. If

the phone fails to connect to all these APs and the Auto Scan function is

active, the phone will try to search and connect to another available open

AP. (Refer to “Auto Scan”)

3.5.2.2 Auto Scan

WiFi-SettingsWiFi ConfigAuto Scan

If the Auto Scan function is active, when the phone is switched on and fails

to connect to the APs specified in “AP Profile”, the phone will do a scan for

available APs and try to connect to one open AP of these scanned APs.

After accessing this option, select Enable or Disable to activate or

deactivate the Auto Scan function.

 Note: If the phone fails to connect to all the specified and scanned

APs, the phone will periodically retry AP connections.

 If the phone fails to register with the Vonage network after the AP

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

connection, the phone will prompt you to try another AP.

3.5.3 Network Parameter

3.5.3.1 DHCP

WiFi-SettingsNetwork ParameterDHCP

After accessing this option, select Disable or Enable to disable or enable

DHCP.

3.5.3.2 IP

WiFi-SettingsNetwork ParameterIP

This option enables you to perform IP settings. Select IP Address, Subnet

Mask or Gateway IP Address; key in the IP address, subnet mask or

gateway IP address; press the left soft key (Ok) to complete the

operation.

3.5.3.3 DNS

WiFi-SettingsNetwork ParameterDNS

This option enables you to perform DNS settings, including Primary DNS

Server IP Address, Secondary DNS Server IP Address and Priority.

3.5.3.4 Network Information

WiFi-SettingsNetwork ParameterNetwork Information

Select this option to view the network information.

3.6 Network Service

Network Service

From this submenu, you can set network services, including Call Waiting,

Call Transfer, Three Way Call, Register Interval Time, Caller-ID Block,

Repeat Dial on Busy, Reject Anonymous Incoming Call and Personal

www.voipon.co.uk [email protected] Tel:(0)1245 808195 Fax: (0)1245 600030

Otros manuales para F1000 Series

Tabla de contenidos

Otros manuales de Teléfono móvil de UTStarcom

UTStarcom

UTStarcom cdm7025US Manual de usuario

UTStarcom

UTStarcom PLS-7025 Manual de usuario

UTStarcom

UTStarcom 860 Guía de configuración

UTStarcom

UTStarcom PLS-7075 Manual de usuario

UTStarcom

UTStarcom SideKick 3 Manual de usuario

UTStarcom

UTStarcom CDM-7000 Manual de usuario

UTStarcom

UTStarcom Verizon UV100 Manual de usuario

UTStarcom

UTStarcom GSM738 Manual de usuario

UTStarcom

UTStarcom cdm7126 Manual de usuario

UTStarcom

UTStarcom GSM708 Manual de usuario

UTStarcom

UTStarcom Verizon CDM9200VW Manual de usuario

UTStarcom

UTStarcom CDM8460 Manual de usuario

UTStarcom

UTStarcom CDM8932 Manual de usuario

UTStarcom

UTStarcom UT GF251 Manual de usuario

UTStarcom

UTStarcom XV6800 Manual de usuario

UTStarcom

UTStarcom CDM1450 Manual de usuario

UTStarcom

UTStarcom GPRS1229 Manual de usuario

UTStarcom

UTStarcom CDM7025 Manual de usuario

UTStarcom

UTStarcom Gz One Type S Manual de usuario

UTStarcom

UTStarcom UTS700X Manual de usuario

UTStarcom

UTStarcom CDM8630 Manual de usuario

UTStarcom

UTStarcom PN-820 Manual de usuario

UTStarcom

UTStarcom UT611 Manual de usuario

UTStarcom

UTStarcom CDM89215 Manual de usuario

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Nokia

Nokia Lumia 620 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LG LM-X420QN Manual de usuario

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

LG LM-K420EMW Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario
