MRX-2 Owner’s Manual
Network Base Station
MRX-2 Owner’s Manual ©2013 Universal Remote Control, Inc.
The information in this manual is copyright protected. No part of
this manual may be copied or reproduced in any form without prior
written consent from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE
FOR OPERATIONAL, TECHNICAL OR EDITORIAL
ERRORS/OMISSIONS MADE IN THIS MANUAL.
The information in this manual may be subject to change without
prior notice.
Complete Control is a registered trademark of Universal Remote
Control, Inc.
All other brand or product names are trademarks or registered
trademarks of their respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OFCONTENTS
Introduction 1
Features and Benefits 2
Parts Guide 3
Front and Rear Panel Descriptions 4
Network Installation 6
Specifications 7
USA Limited Warranty Statement 8
Federal Communication Commission Interference Statement 10
Declaration of Conformity 11
Page 1
Introduction
The MRX-2 Network Base Station allows for control of your
components by sending infrared and serial commands to your system.
This base station can be used with either a Total Control or a
Complete Control system.
When used in a Total Control System:
Expand zones throughout the home or commercial space by
installing multiple MRX-2’s.
Control equipment such as shades and TV lifts using the base
stations sensors, relays and RS-232 ports.
Control URC RF Lighting using the optional RFTX-1 transmitter.
When used in a Complete Control System:
The MRX-2 is required to use the CC Control App for iOS devices,
like the iPad and iPhone.
Extend control to other rooms by installing multiple MRX-2’s
throughout the home or commercial space.
The MRX-2 offers traditional IR only control from compatible
URC MX series remotes via an optional RFX-250.
MRX-2 NETWORK BASE STATION
Page 2
Features and Benefits
When used in a Total Control System:
Expand Control: Add an MRX-2 to a Total Control system to
expand control to other rooms/areas in the home or office.
Components located out of reach from the MRX Advanced
Network System Controller may be controlled via IR, RS-232 or
Relays by using an MRX-2 to expand the scope of a Total
Control system.
Lighting Control: By connecting an optional RFTX-1 RF
Transmitter, take control of your URC lighting (within range).
Control a specific light, a whole room or even the entire home
from any remote control or iOS device.
When used in a Complete Control System:
Enables iOS Control: The addition of an MRX-2 base station to
a control system, allows for control via URC’s CC Control iOS
app for iPads, iPhones and iPod touch. Each iDevice requires
programming by a qualified custom install professional.
Note: Requires the purchase of CC Control Setup code (one
code per system).
No Aiming: Using a base station results in flawless control of
your components without having to aim the remote! The signal
travels to the base station via RF or Wi-Fi and is then converted
back to infrared before being sent to the device being
controlled; perfect for hidden components.
Note: An optional RFX-250 Antenna is required for use with
URC remote controls.
MRX-2 NETWORK BASE STATION
Page 3
MRX-2 NETWORK BASE STATION
Parts Guide
The MRX-2 Network Base Station includes:
1 - MRX-2 Network Base Station
1 - 12V-1000mA Power Supply
6 - Visible Emitters with 10 foot plug
in cables including 1 pink sleeved
emitter for the RFTX-1 port
1 - Two Meter 3.5mm Stereo to
3.5mm Stereo (for daisy chaining
multiple MRX-2 with one RFX-250)
1 - Adjustment Tool
1 - Mounting Plate for wall mounting
the MRX-2
Front and Rear Panel Descriptions
Front
The front panel consists of 4 indicator lights which will illuminate
when in use.
Power:
Illuminates when the power supply is connected to an outlet.
Status: Flashes blue when an RF or Network signal is received.
Sensor: Illuminates to indicate when the sensor is activated.
Ethernet: Illuminates when connected to an active network.
Reset: Press the Reset button located under the MRX-2 to restart the
unit.
Power Status Sensor Ethernet Reset: Bottom
MRX-2 NETWORK BASE STATION
Page 4
Rear
The rear panel ports are:
Power: Uses the included 12V/1Amp power supply.
LAN: Plug an ethernet cable (RJ45) to the LAN(Local Area network).
Relay NO, NC, COM: Configurable switch closure control.
RS-232 Ports: Two RS232 ports provide direct control.
Sensor: Connect with one of URC’s or compatible third party,
sensors.
IR IN:
Allows MRX-2 control from a base station such as a MRF-260.
Note:IR Routing is lost from commands received from this input.
IR Outputs: Connect emitters for IR control of connected devices.
RFTX Port: Dual port #6 for the RFTX-1 connecting cable or
included sleeved IR emitter.
RF IN: Connects to an optional single RFX-250 (Only for MX series
products.)
RF Out: Used for daisy chaining MRX-2s for RF Operation (Refer to
the RFX-250 manual.)
RF ID: 15 unique RF ID's provide RF control and routing to multiple
MRX-2’s in the same home.
Note: DO NOT USE RF ID #0, as it is the interference "sniffer", used
to detect RF interference in the area.
Page 5
Ethernet
Power
Relay:NO,
NC, COM
RS-232 Ports
Sensor
IR IN
IR Outputs: #1-6
RFTX Port: #6
RF IN RF Out
RF ID
MRX-2 NETWORK BASE STATION
Page 6
MRX-2 NETWORK BASE STATION
Network Installation
The MRX-2 can be installed in either a Total Control or a Complete
Control System. Connect the Ethernet cable (RJ45) to the rear of the
MRX-2 and the other end to the active network.
Total Control Install
Complete Control Install
Page 7
MRX-2 NETWORK BASE STATION
Specifications
Network: One 10/100 Ethernet port
Relay: One relay configurable to be NO, NC or Momentary
Sensor: One sensor supports Video or Voltage sensing via URC
sensors.
RS-232: Two RS-232 ports support TX, RX and GND two way
communication via URC cables.
IR: Six adjustable IR ports enable the included URC emitters to
control IR devices Note: 6th IR Output requires the included
sleeved emitter (identified by a pink connector), since it can
optionally be used to connect an RFTX-1
Weight: 8.4 oz.
Size: 248 x 120mm x28mm
Power: 12V External Power Supply
