UPPAbaby G-LiTE Manual de usuario
Stroller
Poussette
Please read these instructions carefully prior to assembly and use.
Por favor lea atentamente estas instrucciones antes del armado y del uso
S’il vous plait lire les instructions attentivement avant l’assemblage et l’utilisa.tion.
ENGLISH
WARNINGS + SAFETY INFORMATION Page 2
CLEANING + GENERAL MAINTENANCE Page 3
PARTS LIST Page 4
STROLLER ASSEMBLY Page 5
STROLLER OPERATION Page 6
LIMITED WARRANTY Page 9
SpaNISH
INFORMACIÓN GENERAL Y SEGURIDAD Página 10
MANTENIMIENTO GENERAL Página 11
LISTA DE PIEZAS Página 12
ARMADO DE LA CARRIOLA Página 13
OPERACIÓN DE LA CARRIOLA Página 14
GARANTÍA LIMITADA Página 17
FRENCH
INFORMATIONS GÉNÉRALES ET CONSIGNES DE SÉCURITÉ Page 18
CONSIGNES GÉNÉRALES D’ENTRETIEN Page 19
LISTE DE PIÈCES Page 20
MONTAGE DE LA POUSSETTE Page 21
FONCTIONNEMENT DE LA POUSSETTE Page 22
GARANTIE LIMITÉE Page 25
TaBLE OF CONTENTS
TaBLE DE CONTENIDO / TaBLE DES MaTIERES
2UPPAbaby 2011 G-LiTE Instruction Manual
WaRNINGS + GENERaL SaFETY
INFORMaTION
WaRNINGS
aVOID SERIOUS INJURY FROM FALLING OR SLIDING
OUT– ALWAYS USE THE SEAT HARNESS.
NEVER LEaVE CHILD UNaTTENDED! KEEP THESE
INSTRUCTIONS FOR FUTURE REFERENCE.
STROLLER WaRNINGS:
Please read this manual carefully before using this stroller. Failure to follow
instructions properly may result in serious injury to your child.
• This stroller is suitable for babies from 6 months up to 50 lbs (22.7 kg).
• This stroller is intended to be used with one child only.
• Never leave your child unsupervised in the stroller.
• The brake must be locked while taking the child in or out of the stroller.
• Children and adults should be clear of moving parts while making stroller
adjustments. Damage to fingers or extremities may occur when opening or
closing the stroller frame.
• Stroller may become unbalanced if heavy weight is placed or hung upon
the handle.
• Unit may become unstable if the manufacturer’s recommended load is
exceeded, or if a parcel bag, accessory, or rack other than that recommended
by the manufacturer is used or hung from the unit.
• Unstable hazardous conditions may exist if package carrying accessories are
added onto the product.
• Maximum weight for the storage basket is 5 lbs (2.2 kg).
• Never leave child in the stroller while ascending or descending stairs, or using
an escalator.
• Do not make any alterations or modifications to the stroller with products not
supplied by the manufacturer as this may cause instability or structural damage
not covered under warranty.
WaRNINGS + GENERaL SaFETY INFORMaTION
ENGLISH
3
WaRNINGS + GENERaL SaFETY
INFORMaTION
CLEaNING + GENERaL MaINTENaNCE
CLEaNING:
• Clean frame with a damp cloth and a mild detergent and dry thoroughly.
Do not use abrasives.
• If the stroller chassis parts have been exposed to salt water we recommend
that they be rinsed with fresh (tap) water as soon as possible to avoid corrosion.
• The canopy may be sponged lightly using a damp cloth and a mild detergent.
• The removable seat pad is machine washable. Please wash separately in cold
water on gentle cycle with mild detergent. Dry flat and away from direct sunlight
before re-use or storage. Do NOT bleach, iron or dry clean.
MaINTENaNCE aND REpaIR:
• This stroller requires regular user maintenance. Regularly check all connecting
hardware (rivets, screws, etc.) for tightness and security. Inspect all brakes, wheels
and tires and replace or repair as necessary.
• Check all safety devices, locks and harnesses for correct and secure operation.
Never continue to use a product that is structurally unsound.
• If wheels squeak, lubricate sparingly with a Teflon® or silicone based lubricant.
Do NOT use oil or grease based products, as this may attract dirt, which will
clog movement.
• Only UPPAbaby replacement parts should be used. It may be unsafe to use parts
supplied by another manufacturer.
• We recommend a service check every 12 months.
• Contact Customer Service with any repair questions.
This product is designed and manufactured to comply with ASTM F833 Standard Consumer Safety Performance
Specification for Carriages/Buggies and is JPMA certified. This product is designed and manufactured to comply
with Canadian standard SOR/91-350,s. 1(F) Carriages and Buggy Regulations.
UPPAbaby reserves the right to make design changes and improvements
to any of our products as part of our commitment to innovation.
4UPPAbaby 2011 G-LiTE Instruction Manual
paRTS LIST
STROLLER
FRaME
SHOULDER
STRap
FRONT
WHEELS
BaCK
WHEELS
CUp HOLDER
CaNOpY
ENGLISH
5
STROLLER aSSEMBLY
Slide front wheels onto frame
until an audible “click” is heard.
TO SET BRaKE: Press down
each foot pedal to lock.
TO RELEaSE BREaK: Lift up
on each foot pedal.
STEp 1: Release the latch lock on the left side of the frame and
unfold the stroller.
STEp 2: Rest stroller on back wheels and push down pedal
(with your right foot) on the back of stroller while pulling both
handles up towards you.
STEp 3: Make sure each lock “clicks” to “out” position (as shown)
in order for frame to be fully open.
STEp 1
STEp 1
STEp 2
STEp 2
STEp 3
STEp 3
STEp 1: Slide canopy onto frame just below
mesh attachment and above plastic stud.
STEp 2: Press down lever to lock canopy open.
STEp 3: Fasten side canopy panel to Velcro strips.
Extend SPF 50 pop-out sun canopy for extra
protection against UV rays.
aTTaCHING THE
FRONT WHEELS OpENING STROLLER
SETTING/RELEaSING
THE BRaKE aTTaCHING THE CaNOpY
CLICK
1
2
2
1
CLICK
1
2
2
1
CLICK
1
2
2
1
CLICK
1
2
2
1
2
1
CLICK
1
2
2
1
6UPPAbaby 2011 G-LiTE Instruction Manual
STROLLER OpERaTION
STEp 1: Undo buckle and slide
harness fastener off.
STEp 1: Collapse the canopy by
lifting up levers.
STEp 4: Remove top of pad.
STEp 3: Lift lock tab on both sides.
STEp 2: Push harness straps and
buckles through hole in pad.
STEp 2: Lift metal safety tab on
right side latch.
STEp 5: Remove bottom of pad.
STEp 4: Pull the front wheels
and footrest up towards you.
STEp 3: Undo top Velcro strips.
STEp 5: Engage the locking
mechanism in standing position.
REMOVING THE SEaT paD
FOLDING THE STROLLER
CLICK
1
2
2
1
21
CLICK
1
2
2
1
2
1
2
1
CLICK
1
2
2
1
2
1
2
1
CLICK
1
2
2
1
CLICK
1
2
2
1
CLICK
1
2
2
1
CLICK
1
2
2
1
• Machine wash in cold
water on Gentle cycle
with mild detergent.
• Dry flat and away from
direct sunlight before
re-use or storage.
• DO NOT bleach, iron
or dryclean.
CLEaNING
ENGLISH
7
STROLLER OpERaTION
STEp 1: Slide plastic clip
into buckle until you
hear a “click”.
STEp 2: Secure buckle
cover Velcro.
STEp 1: Undo buckle and
slide shoulder harness
fastener off.
aTTaCHING THE CUp HOLDER (LEFT)
Snap cup holder into place using attachment pins
located below handle.
aDJUSTING THE CUp HOLDER (RIGHT)
STEp 1: Loosen screw and turn bracket 180 degrees.
STEp 2: Tighten screw to fasten bracket to cup holder.
STEp 2: Push harness
straps and buckles
through holes in pad.
STEp 3: Feed harness
straps and buckles
through desired slots.
STEp 4: Reattach shoulder
harness fasteners.
STEp 1: Lift buckle cover. STEp 2: Press middle
button to release.
OpERaTING RESTRaINT BUCKLE
aDJUSTING THE SEaT HaRNESS
aTTaCHING/aDJUSTING CUp HOLDER
TO aTTaCH RESTRaINT BUCKLE TO RELEaSE RESTRaINT BUCKLE
NOTE: Cup holder can be placed on either side of stroller.
WaRNING: Maximum cup holder weight is 1.5 lbs (.7 kg). Excessive weight may cause a hazardous, unstable
condition to exist. Do not place hot liquids in holder.
CLICK
1
2
2
1
CLICK
1
2
2
1
CLICK
1
2
2
1
21
CLICK
1
2
2
1
CLICK
1
2
2
1
ENGLISH
9
LIMITED WaRRaNTY
Your UPPAbaby stroller is warranted to be free from any manufacturing defects for
a period of 2 years from the date of purchase under normal use and in compliance
with the operating instructions.
This warranty extends ONLY to the original retail purchaser and is ONLY valid
when supplied with proof of purchase. Please retain proof of purchase with this
Limited Warranty.
This warranty is subject to the conditions set forth by the country in which the
items were purchased. Conditions may vary.
Please note that a repair issue will NOT be covered by this warranty if:
• The issue is caused by misuse or poor maintenance. Please refer to this instruction
booklet for guidance on stroller use and maintenance.
• Damage is caused by improper installation of UPPAbaby parts and/or accessories.
Please refer to this instruction booklet for guidance on stroller assembly and use.
• Damage is corrosion caused by lack of maintenance or service.
• Damage is due to general wear and tear which is the result of everyday use or
negligence.
• Damage is caused by sun intensity, sweat, detergents, damp storage or frequent
washings.
• Repairs or modifications are carried out by a third party.
• Stroller is purchased from an unauthorized retailer. Approved retailers are listed
on our website, www.uppababy.com
• Stroller is second hand.
• Stroller is damaged as a result of an accident, airline or freight damage.
UPPAbaby reserves the right to determine if warranty terms and conditions
have been met.
Please contact us in the USA at 339-499-7455 or email us at service@uppababy.com
if you have any questions regarding warranty. In Canada, contact 5514 Km
Corporation at 888.502.5514 or email [email protected].
18UPPAbaby 2011 G-LiTE Instruction Manual
WaRNINGS + GENERaL SaFETY
INFORMaTION
MISES EN GaRDE CONCERNaNT La pOUSSETTE :
Il est impératif de lire attentivement ce manuel avant d’utiliser la poussette. Le
non-respect de ces consignes pourrait entraîner des blessures graves pour l’enfant.
• Cette poussette convient pour les bébés âgés d’au moins 6 mois et pesant
jusqu’à 22,78 kg (50 lb).
• Cette poussette est conçue pour un seul enfant à la fois.
• Ne jamais laisser l’enfant sans surveillance dans la poussette.
• Le frein doit être serré pendant que l’enfant est installé ou sorti de la poussette.
• Les enfants et les adultes doivent écarter les doigts ou les orteils des pièces
mouvantes pendant le réglage de la poussette, ainsi qu’à l’ouverture ou la
fermeture du châssis de la poussette, pour éviter de se blesser.
• La poussette risque de devenir instable si un objet lourd est placé ou suspendu
à la poignée.
• La poussette risque de devenir instable si le poids de l’enfant dépasse la
charge maximale recommandée par le fabricant ou si un sac, un accessoire
ou un panier autre que ceux recommandés par le fabricant est utilisé ou
suspendu à la poussette.
• Les conditions hasardeuses instables peuvent exister si emballe des accessoires
porter sont rajoutés le produit.
• Le poids maximum pour le panier est 2,27 kg (5 lb).
• Ne jamais laisser l’enfant dans la poussette pour monter ou descendre des
marches ou sur un escalier roulant.
• N’apporter aucune modification à la poussette avec des produits non fournis
par son fabricant pour éviter tout problème d’instabilité ou de dommage
structurel non couvert par la garantie.
INFORMaTIONS GéNéRaLES ET CONSIGNES DE SéCURITé
MISE EN GaRDE
POUR ÉVITER TOUTE BLESSURE GRAVE RÉSULTANT D’UNE
CHUTE OU D’UN GLISSEMENT, TOUJOURS UTILISER LE
HARNAIS. IMpORTaNT : CONSERVER CES INSTRUCTIONS
POUR TOUTE RÉFÉRENCE ULTÉRIEURE.
Otros manuales para G-LiTE
5
Tabla de contenidos
Idiomas:
Otros manuales de Paseante de UPPAbaby
UPPAbaby
UPPAbaby G-LINK Manual de usuario
UPPAbaby
UPPAbaby 2010 VISTA Manual de usuario
UPPAbaby
UPPAbaby Cruz Manual de usuario
UPPAbaby
UPPAbaby RumbleSeat Manual de usuario
UPPAbaby
UPPAbaby RUMBLESEAT V2 Manual de usuario
UPPAbaby
UPPAbaby VISTA PiggyBack Manual de usuario
UPPAbaby
UPPAbaby 2010 VISTA Manual de usuario
UPPAbaby
UPPAbaby Cruz Manual de usuario
UPPAbaby
UPPAbaby G-LUXE Manual de usuario
UPPAbaby
UPPAbaby 0420-CRZ-NA Manual de usuario
UPPAbaby
UPPAbaby G-LUXE Manual de usuario
UPPAbaby
UPPAbaby G-LiTE Manual de usuario
UPPAbaby
UPPAbaby Infant SnugSeat Manual de usuario
UPPAbaby
UPPAbaby Minu Manual de usuario
UPPAbaby
UPPAbaby G-0100 Manual de usuario
UPPAbaby
UPPAbaby 2010 VISTA Manual de usuario
UPPAbaby
UPPAbaby Ub XTEND CRUZ V2 Manual de usuario
UPPAbaby
UPPAbaby VISTA V2 Manual de usuario
UPPAbaby
UPPAbaby Minu 0818-MIN-AU Manual de usuario
UPPAbaby
UPPAbaby G-LiTE Manual de usuario
