Uplus Lighting 200 LED RETRO Manual de usuario

User manual

200 LED RETRO

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3-4

Technical Specifications…………………………………………………………………………4

Control Menu ……………………………………………………………………………………5

DMX Channels ……………………………………………………………………………………5-6

Trouble Shooting…………………………………………………………………………………6

Fixture Cleaning………………………………………………………… ………………………6

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces. Be sure that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always

by taking its base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher

than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand

during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before

replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit

by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please

contact the nearest authorized technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any

repairs yourself. In the unlikely event your unit may require service, please contact your nearest

dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

fixed to avoid vibration and slipping while operating. And make sure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also

always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the

touch of people.

2.Technical Specifications

Light Sources: 200W LED White+RGB LED

Max Power Consumption: 260W

Power Input: 100-240V, 50/60Hz

Color Tempreture: 2400K or 3200K optional

LED Lifespan: 50000 hours

Operating mode: DMX512,Auto, Sound active, Master/slave,RDM

Channel mode: 12/37 DMX512 Channel

Beam range:102°

Display: Digital display

IP level: IP30

Dimension: 580*370*500mm

N.W：14kgs

All aluminum alloy structure, light and stylish design, elegant and generous. The biggest feature is

the close combination of traditional light source and LED,

LED200W lamp beads are used, and full-color LED are used as the background light to achieve

extraordinary visual effects. The lamp head is equipped with a protective decorative mesh.

No glare or glare. It can be quickly hung or used with a tripod, and the light is soft. It is suitable for

TV stations, studios,

It is used in large-scale entertainment occasions such as mobile performances. It can also be used

in commercial lighting or decorative lamps,

In addition to DMX control, there are powerful RDM control and wireless DMX control technology

3.Control Menu

Menu Operation

On the base of the control panel offers a number of features, such as setting DMX fixture address,

switch the lamp, run the test program, the mode selection.

Show

Value

Instruction

d001

001- 512

DMX512 -37Channels

A001

001- 512

DMX512 -12Channels

r255

000 - 255

Red dimmer-from dark to light

G255

000 - 255

Green dimmer-from dark to light

b255

000 - 255

Blue dimmer-from dark to light

u255

000 - 255

White dimmer-from dark to light

CL01

01 - 08

8 color output

FH01

01 -16

16 effects, from slow to fast.

4.DMX Channels

Model – CH12

Channel

DMX Value

Dispaly

Function

CH 1

0－255

Dimming

From dark to bright

CH 2

0－255

White

From dark to bright

CH 3

0－255

Strobe

From slow to fast

CH 4

0－255

Red

From dark to bright

CH 5

0－255

Green

From dark to bright

CH 6

0－255

Blue

From dark to bright

CH 7

0－255

Total Strobe

From slow to fast

CH 8

0－255

Feature selection

0—15;DMX Dimmer;15-255 effect

CH 9

0－255

Feature Speed

From slow to fast

CH 10

0－255

Red 1

Red 1 background , from dark to bright

CH 11

0－255

Green 1

Green 1 background , from dark to bright

CH 12

0－255

Blue 1

Blue 1 background , from dark to bright

Model – CH37

Channel

DMX Value

Dispaly

Function

CH 1

0－255

White

From dark to bright

CH 2

0－255

Red 1

From dark to bright

CH 3

0－255

Green 1

From dark to bright

CH 4

0－255

Blue 1

From dark to bright

……

CH 35

0－255

Red 12

From dark to bright

CH 36

0－255

Green 12

From dark to bright

CH 37

0－255

Blue 12

From dark to bright

5.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

6.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
