Universal Space FRUIT MANIA STD Manual de usuario

OperationManual

www.universal-space.com

STD

Fruit Mania Operation Manual

Non-technical personnel who do not have technical knowledge and

Expertise should refrain from performing such work that this manual

require or perform tasks which are not explained in this manual.

Failing to comply can cause severe accidents such as electric shock or

other serious injuries.

WARNING: To reduce the risk of fire, electric shock or personal injury,

unplug or disconnect the machine from the power supply before

servicing.

CONTENT

Important Safety Instructions ................................................................................. 2

1. SPECIFICATIONS...................................................................................................... 4

2. PACKAGE CONTENTS.............................................................................................. 5

3. PART NAMES ........................................................................................................... 6

4. SET UP & INSTALLATION........................................................................................ 7

5. HOW TO PLAY ........................................................................................................10

6. GAME OPTIONS .....................................................................................................12

7. SYSTEM RECOVERY...............................................................................................16

8. MAINTENANCE & INSPECTION............................................................................17

9. OVERALL CONSTRUCTION ...................................................................................18

WARNING

Fruit Mania Operation Manual

Thank you for purchasing FRUIT MANIA from Universal Space. We hope

you enjoy the product.

This manual contains valuable information about how to operate and maintain your

game machine properly and safely. It is intended for the owner and/or personnel in

charge of product operation. Carefully read and understand the instructions.

If you need any help during installation and setup please utilize this manual and

troubleshooting guide. If the product fails to function properly, non-technical personnel

should under no circumstance attempt to service the machine. Contact your distributor

or manufacturer for help.

Before use, please read IMPORTANT SAFETY INSTRUCTIONS.

IMPORTANT SAFETY INSTRUCTIONS

To ensure the safe usage of this product, carefully read and

understand these instructions before operating your game.

Save these instructions for future reference.

Use this product only as described in this manual. Other uses not recommended may

cause fire, electric shock or personal injury. Unplug the game from the outlet when not

in use, when moving from one location to another, and before cleaning/servicing.

Explanations which require special attention are indicated by signs of warning.

Depending on the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING

are used.

NOTE: A NOTE indicates useful hints or information about product usage.

NOTICE: A NOTICE indicates potential damage to product and how to avoid the

problem.

WARNING: A WARNING indicates a potential for product damage or serious personal

Injury.

It is important to understand the meaning of the following HAZARD SIGNS before

continuing:

High Voltage and Shock Hazard:

High voltage can cause electric shock.

Turn off/unplug power before servicing.

High Temperature Hazard:

This part may cause scalding.

Do not touch. Surface may be hot.

No Touching Hazard:

Fruit Mania Operation Manual

This part may be hot or can cause electric shock.

Do not touch.

Use the following safety guidelines to help ensure your own personal safety and to help

protect your equipment and surrounding environment from potential damage.

This product is an indoor game machine. Do not install

outdoors.

Avoid installing in the following places to prevent fire, electric shock, injury

and/or machine malfunctioning:

•Places subject to rain/moisture, or places subject to high humidity.

•Places subject to direct sunlight, or places subject to extremely hot or cold

temperatures to ensure that it is used within the specified operating range.

•Places where inflammable gas may be present or in the vicinity of highly

inflammable/volatile chemicals or items that can easily catch fire

•On unstable or sloped surfaces. The machine may topple or cause unforeseen

accidents.

•Vicinity of fire exits, fire extinguishers etc that may block/prevent safety

measures

Note: The contents of this manual may be updated without notice

Fruit Mania Operation Manual

1. SPECIFICATIONS

1) Rated power supply：AC110V 50/60Hz

2) Min. Power consumption：200W

3) Max. Power consumption：250W

4) Dimensions：：W1600xD730xH2137 (mm)

5) Weight：About 180kg

NOTICE: After turning off the game, please wait at least 1 minute

before restarting again.

Note: Game parameters are subject to change without notice.

31.41

Fruit Mania Operation Manual

2. PACKAGE CONTENTS

Open the package and make sure all the items are included:

•1 x Body Assembly

•Following accessories

No. Part No. Code Name Spec. Qty

1 N102-430-000 23301000001 Cord 10A/250V-1.8M 1

2 N102-724-000 41441202B001

Manual Chinese 1

3 N102-442-000

2.53.00171001

171 Key 171 1

4 N102-406-000

2.53.00000108

2222 Key 2222 1

5 N102-440-000 41300000003 USB Lenovo 2G 1

6 N102-434-000 21901000013 Fuse 5×20mm T10A

250VAC 1

7 N102-441-000 22604000007 Micro SW

Green SW 2

If any items are found to be missing, please contact your sales

representative for help immediately.

NOTE: Part models are subject to change without notice.

Fruit Mania Operation Manual

3. PART NAME

Marquee

Button

Cabinet

32” Display

Ticket payout

Coinmech

Fruit Mania Operation Manual

4. SET UP & INSTALLATION

This product is an indoor game machine. Do not install

outdoors.

zRefer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 2) for places to avoid

zPlace the unit on a dry level surface

zVentilation openings in the back of the unit must not be obstructed by objects or by

wall.

4.1 Play Zone

This machine requires space for playing and for maintenance as shown below.

Leave space around the game upon installation:

Service area:250mm

Play area：500mm

4.2 Level Adjustment

Install this machine on a flat surface. Adjust levers to lift casters off the ground to level

the game. If the game is installed on an unsuitable floor, it could cause game

malfunction.

To secure the game, adjust the Leveler down until it touches the floor, lifting the casters

off the ground by 5mm. Repeat the same for all levelers.

Play area

Fruit Mania Operation Manual

4.3 Transporting the Game

If you need to move the game, adjust the levelers back to an “up” position so the

casters touch the ground.

NOTICE

•Be careful not to damage the machine during transport.

•The machine should be handled with care when bringing it down from a higher

level.

•Always unplug the game before moving.

•Keep the machine in upright position during transport.

•For longer distance transport, package the game properly to prevent damages.

Leveler Caster

Move Fix

About 5mm

Make sure the machine is level with the ground and all the

adjustable legs should stick to the floor closely.

NOTICE

Leveler Caster

Move

Fruit Mania Operation Manual

4.4 Connecting Power

WARNING: Check the voltage rating before you connect the

equipment to an electrical outlet to ensure that the required voltage and

frequency match the available power source. Please refer the label of the

machine.

•Do not plug the equipment power cables into an electrical outlet if the power

cable is damaged.

•Avoid putting many loads on one electrical outlet as it could generate heat and

fire resulting from overload.

•Connect the grounding conductor to the earth terminal (GND):

WARNING

Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet

does not sit on the power cord as this could damage the cord and become hazardous.

To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the

cord.

To prevent electric shock, do not touch the power plug when hand is wet.

Ensure that nothing rests on the power cord and that it is not located where it can be

stepped on or tripped over.
