UR3-SR2

Operating Manual

For Easy Clicker

This remote control is designed to operate most Digital

and Analog Cable Boxes, as well as TVs, and a VCR or

DVD player.

Introduction

Install two

AAA alkaline batteries

as shown here

Before you program or operate the remote control, you

must install two new AAA alkaline batteries.

STEP1 Remove the battery compartment cover from the

back of your remote control.

STEP2 Check battery polarity carefully, and install the

batteries as shown in the illustration below.

STEP3 Replace the battery compartment cover.

Replacing Batteries

Button Functions

Programming the Remote Control.

A. Manual Pr

A. Manual Programming

ogramming

The remote control can be programmed by entering a three-

digit code number that corresponds to particular brands and

models of equipment. The three-digit code numbers are listed

in the code tables sections of this instruction manual.

*Note : In this section, when you are instructed to press a

[DEVICE] button, that means you should press either

the CBL, TV, or VCR button, depending on which

device you are programming the remote to operate.

STEP1 Turn on the equipment that you want the remote

control to operate Cable Box, TV and VCR(DVD).

STEP2 Press the [DEVICE] button and the [SELECT]

button simultaneously for three seconds. The

corresponding device LED will turn on indicating

that it is ready to be programmed. The LED will

remain on for 20 seconds. The next step must be

entered while the LED is on.

STEP3 Point the remote control toward the equipment

and enter the three-digit code number assigned

to your brand from the code tables. If there are

more than one three-digit number listed for your

brand, try one code number at a time until your

equipment turns off.

*Note : You can verify that you have selected the correct

code by pressing the [MUTE] button. The

equipment should turn on or off.

STEP4 Store the three-digit code by pressing the same

[DEVICE] button once again. The device LED will

blink twice to confirm that the code has been

stored.

*Note : Try all the functions on the remote control. If any

of the functions do not operate as they should,

repeat the instructions from Step 2 using the next

three-digit code number from the same brand list.

B. Auto Sear

B. Auto Search Method

ch Method

If none of the three digit code numbers assigned to your

brand of equipment works, or the code table does not list

your brand, you can use the Auto Search Method to find the

correct three-digit code number for your equipment by

following steps:

STEP1 Turn on the equipment that you want the remote

control to operate (Cable Box, TV, VCR, or DVD).

STEP2 Press the [DEVICE] button and the [SELECT]

button simultaneously for three seconds. The

device LED will turn on indicating that it is ready

to be programmed. The LED will remain on for 20

seconds. The next step must be entered while

the LED is on.

STEP3

Press the [CH+] or [CH-] button one at a time or

keep it pressed. The remote will emit a series of

Power ON/OFF code signals. Release the [CH+] or

[CH-] button as soon as the equipment turns off.

*Note : You can verify that you selected the correct code

by pressing the [MUTE] button. The equipment

should turn On or Off.

STEP4 Press the same [DEVICE] button to store the

code. The Device LED will blink twice to confirm

that the code has been stored.

C. T

To find the Thr

o find the Three-Digit Code that W

ee-Digit Code that Was

Programmed using the Auto Sear

ogrammed using the Auto Search

Method

STEP1 Press the appropriate [DEVICE] button and the

[SELECT] button simultaneously for three

seconds. The device LED will turn on for 20

seconds. The next step must be performed while

the LED is on.

STEP2 Press the [INFO] button. The device LED will blink

a number of times indicating the number of each

digit for the code. Each digit is separated by a

one second interval of the LED being off.

Example : One blink, then three blinks, then eight blinks

indicates the code number 138.

*Note : Ten blinks indicates the number 0.

D. Pr

Programming a Second TV to the VCR

ogramming a Second TV to the VCR

Button

STEP1 Press the [VCR] button and the [SELECT] button

simultaneously for 3 seconds. The VCR LED will

turn on for 20 seconds. The next step must be

performed while the LED is on.

STEP2 Press the [TV] button.

STEP3 Point the remote control toward the TV and enter

the three-digit code for your TV from the TV

codes table.

STEP4 Store the three-digit code by pressing the [VCR]

button. The device LED will blink twice to confirm

that the code has been stored.

E. Pr

Programming for Advanced Functions.

ogramming for Advanced Functions.

In the CABLE device mode, the A,B,C and blank macro

buttons can be programmed to act as macro buttons to

send out up to 10 commands with one button press. In this

section, when you’re instructed to press a [MACRO]

button, you need to press either the A, B, C or blank macro

button (depending on which button you are attempting to

program).

*Note : The A, B, and C buttons are not programmable if

you have a Digital Cable Box made by Pace,

Pioneer, or Scientific-Atlanta.

STEP1 Press the [CBL] button to select the CABLE

mode.

STEP2 Press a [MACRO] button and the [SELECT] button

simultaneously for 3 seconds. The CBL device

LED will turn on for 20 seconds. The next step

must be performed while the LED is on.

STEP3 Press up to 10 buttons you wish to store. The CBL

device LED will blink once for each command

entered.

STEP4 Press the [CH+] button to store the functions that

are selected. The CBL device LED will blink twice

to confirm the storage of functions.

To erase the Macro programming and return to the

original function:

STEP1 Press the [CBL] button to select the CABLE mode.

STEP2 Press a [MACRO] button and the [SELECT] button

simultaneously for 3 seconds. The CBL device

LED will turn on for 20 seconds. The next step

must be performed while the LED is on.

STEP3 Press the [CH+] button to erase the functions

stored in the button. The CBL device LED will blink

twice to confirm that the memory button has

been erased.

. Assigning the V

Assigning the Volume and Mute keys to a

olume and Mute keys to a

Dif

Differ

ferent Device

ent Device

By default, the VOL+, VOL- and MUTE keys operate

through your TV. If you would like those keys to operate

those functions on a different device, follow these

steps.

STEP1 Press the [SELECT] button and [CBL] button

simultaneously for three seconds. The device

LED will turn on for 20 seconds. The next step

must be performed while the LED is on.

STEP2 Press the [VOL +] button. The device LED will

blink.

STEP3 Press the [DEVICE] button corresponding to the

device that you would like the volume and mute

buttons to control. The device LED will blink

twice to confirm the programming.

Example : If you wish to have the volume and mute keys

operate your Cable Box, press the [CBL]

button in Step3.

G. Assigning the Channel keys to a

Assigning the Channel keys to a

Dif

Differ

ferent Device

ent Device

By default, the CH+, CH-, NUMERIC and LAST keys

operate through your Cable Box. If you would like those

keys to operate those functions on a different device,

follow these steps.

STEP1 Press the [SELECT] button and [CBL] button

simultaneously for three seconds. The device

LED will turn on for 20 seconds. The next step

must be performed while the LED is on.

STEP2 Press the [VOL -] button. The device LED will

blink.

STEP3 Press the [TV] button. The device LED will blink

twice to confirm the programming.

*Note : If you wish to have the channel keys operate your

Cable Box, press the [CBL] button instead of the

[TV] button in Step 3.

H. Low Batter

H. Low Battery W

y War

arning

ning

When the battery is low (2.3V-2.0V) and needs to be

replaced with fresh batteries, device LED will blink 2 times

in sequence whenever a [DEVICE] button is pressed to

turn on equipment.

I. Memor

I. Memory Lock System.

y Lock System.

This remote control is designed to retain programmed

memory for 10 years — even after batteries are removed

from the remote control.

Set-up Code Tables

MAKER(BRAND) NAME

CODE No

CONVERTER

CABLE TV

SCIENTIFIC ATLANTA EXPLORER Series 001 007

8600X 011

8600 021

8540,8570,8590 022

8500 023

IPN Series 051

MOTOROLA DCT Series (DVR Model) 008

VIP Series 053

GENERAL INSTRUMENT DCT Series,DCH Series, CFT2200 002

DL4,DQNV/DRX,DPBB,DPV/DP/DQN,DRZ

027

JERROLD BMC9012/BMC9022 006

DSR470 005

CFT2000 012

DRZ 024

DL4,DP(V),DQN(V),DPBB 025

DRX 002

Some Model 048

DL4,DQNV/DRX,DPBB,DPV/DP/DQN,DRZ

027

ADB ADB Series 054 055

ADB5810WX 115

AMINO AmiNET Series 049

AT&T U-VERSE 051

CISCO RNG200 113

IPN Series 051

COMCAST RNG200 113

DIGEO 2056-MSX 153

DIRECTV HR20,HR21 229

HAMLIN CR6000 042

CR6600,6800,CR83 043

CRX5000 044

MOXI MOXI MEDIA CENTER 006

MOXI HD DVR 052

2056-MSX 153

MYRIO Evo Series 054 055

NFUSION

NUVENIO SD PHOENIX, NUVENIO HD,

SOLARIS, NOVA 192

NOW TV NOWTV 114

NSC IM781R 046

IM781 047

OAK SIGMAONE, P1,P2,P3, SIGMA 2000 037

RTC56,RKDM 038

SIGMA 2001,2002 039

SIGMA 450,500,550 040

PACE 500 Series 001 007

TDC Series 008

DTA Series 113

Otros manuales para Easy Clicker UR3-SR2

Tabla de contenidos

Otros manuales de Mando a distancia de Universal Remote Control

Universal Remote Control

Universal Remote Control ZC800 Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR3L-SR4 Manual de usuario

Universal Remote Control

Universal Remote Control TeLeCOMMANDE UNIVERSELLE RC 8 Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR3-SR3 Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR3L-SR4 Manual de usuario

Universal Remote Control

Universal Remote Control PHAZR-5 Manual de usuario

Universal Remote Control

Universal Remote Control UR5-MDVR Manual de usuario

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manual de usuario

Universal Remote Control

Universal Remote Control UR5L-9000L Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Manual de usuario

Universal Remote Control

Universal Remote Control UR-J2000TVE Manual de usuario

Universal Remote Control

Universal Remote Control PHAZR-5 - SPECS SHEET Manual de usuario

Universal Remote Control

Universal Remote Control UR3-EXP Manual de usuario

Universal Remote Control

Universal Remote Control MX600 Manual de usuario

Universal Remote Control

Universal Remote Control TOTAL CONTROL FX-1 Manual de usuario

Universal Remote Control

Universal Remote Control R7 - SPECS SHEET Manual de usuario

Universal Remote Control

Universal Remote Control R7 - SPECS SHEET Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR3L-SR4 Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR3-SR3 Manual de usuario

Universal Remote Control

Universal Remote Control UR4U-MDVR-CHD2 - SPECS SHEET Manual de usuario

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Manual de usuario

Universal Remote Control

Universal Remote Control URC-A6 Manual de usuario

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
