Universal Laser Systems VLS2.30 Manual de usuario
VLS Desktop User Guide
VLS2.30, VLS3.50
www.ulsinc.com
Revision 2012.08
©2012 Universal Systems, Inc. All Rights Reserved. Universal Laser Systems logo and name are registered
trademarks, and High Power Density Focusing Optics, Rapid Reconfiguration, 1-Touch Laser Photo, Laser
Interface + and SuperSpeed are trademarks of Universal Laser Systems, Inc. All other company and product
names are trademarks or registered trademarks of their respective companies.
Universal’s laser systems are protected under one or more of U.S. Patents: 5,661,746; 5,754,575; 5,867,517;
5,881,087; 5,894,493; 5,901,167; 5,982,803; 6,181,719; 6,313,433; 6,342,687; 6,423,925; 6,424,670; 6,983,001;
7,060,934; 7,415,051; 7,469,000; 7,715,454; 7,723,638; 7,947,919. Other U.S. and international patents pending.
2
Thank you for choosing Universal Laser Systems®. We appreciate innovative customers like you who have made
Universal Laser Systems an integral part of their business.
Universal Laser Systems is committed to providing the highest level of customer satisfaction and support. To
ensure your satisfaction, we urge you to read the documentation provided with your equipment.
Since 1988, Universal Laser Systems has been committed to continually improving our technology and customer-
driven laser solutions. Your satisfaction is very important to us and we welcome your feedback. Te ll us about your
Should you have any questions, please contact Universal Laser Systems’ Customer Service Te am at 480-609-
Again, thank you for choosing Universal Laser Systems.
Your Universal Laser Systems Team
3
Table of Contents
USER GUIDE CD
Chapter 1 – Specifications 5
Chapter 2 – Safety 8
Chapter 3 – Installation 19
Chapter 4 – Operation 36
Chapter 5 – Accessories 68
Chapter 6 – Maintenance 92
Software
Your Reference Guide contains the Software Installation CD. Please follow the instructions for proper installation.
Warranty
Your Reference Guide contains Warranty documents pertaining to your purchase. Should you require a copy of
Parts
4
Chapter 1 - Specications
5
VLS2.30 VLS3.50
Operating
Environment Well-ventilated office (recommended) or clean, light-duty manufacturing
Operating
Temperature
50ºF (10ºC) to 95ºF (35º C) capable
73ºF (22ºC) to 77ºF (25º C) for best performance
Storage Temperature 50ºF (10ºC) to 95ºF (35º C)
Operating Humidity Non-condensing
Electrical Power Single Phase 110/240V AC, 10/5 Amp, 50/60 Hz
Grounded (earthed) and stable (surge and spike protected)
Particulate/Odor
Outside Ventilated
Exhaust System
High-pressure vacuum blower capable of:
150 CFM (cubic feet per minute) @ 6 inches
static pressure (255m3/hr at 1.5kPa)
250 CFM (cubic feet per minute) @ 6 inches
static pressure (425m3/hr at 1.5kPa)
Computer
Requirements
(See the Installation & Set-up
Guide for more information)
Windows XP or Windows Vista (32 and 64 bit)
2.0 GHz Processor (minimum)
1 GB of RAM (minimum)
40 GB Hard Drive (minimum)
Software
Requirement Graphics or CAD based
Laser Safety CO2Laser, Interlocked Safety Enclosure = Class 1
Red Diode Pointer = Class 2
6
VLS2.30 VLS3.50
Work Area* 16 x 12 in
(406 x 305 mm)
24 x 12 in
(610 x 305 mm)
Table 18.75 x 14.5 in
(476 x 368 mm)
26.75 x 14.60 in
(679 x 368 mm)
Maximum Part
(WxHxD) with 1.5” lens
18.75 x 14.5 x 4 in
(476 x 368 x 102 mm)
26.75 x 14.5 x 4 in
(679 x 368 x 102 mm)
Maximum Part Weight 20 lbs (9 kg)
Resolutions 1000, 500, 333, 250, 200, 83 dpi/lpi
Control Requires a dedicated PC to operate; requires Windows XP, Windows Vista, or Windows 7
(32-bit and 64-bit)
Interconnection USB 2.0 High Speed port only
Laser Options 10, 25 and 30 watts 10, 25, 30, 40 and 50 watts
Power Consumption up
to:
110V/10A
240V/5A
Overall Dimentions
(WxHxD)
With Cart:
26 x 44 x 25 in
(661 x 1118 x 635 mm)
Without Cart:
26 x 14 x 25 in
(661 x 356 x 635 mm)
With Cart:
34 x 44 x 25 in
(864 x 1118 x 635 mm)
Without Cart:
34 x 14 x 25 in
(864 x 356 x 635 mm)
Weight (uncrated) Does
not include Cart System = 85 lbs. (38 kg) System = 100–106 lbs. (45-48 kg)
Exhaust Hookup One 3-inch (10.16 cm) port
Laser Cartridge Weight
10 Watt = 13 lbs (6kg)
25/30 Watt = 20 lbs (9 kg)
40 Watt = 23 lbs (10 kg)
50 Watt = 26 lbs (12 kg)
Available Options Cart, Integrated Air Cleaner, Rotary Fixture, Air Assist, Compressed Air,
Cutting Table, Lens Kits
7
Chapter 2 - Safety
8
DANGEROUS VOLTAGES ARE PRESENT WITHIN THE ELECTRONICSENCLOSURES
OF THIS SYSTEM. Access to these areas is not necessary during normal operation.
If
it
bec
omes
necessary to open one of these enclosures for service
r
easons
,
please
remember
to disconnect
the
power cord from your electrical
supply
.
NEVER REMOVE THE GROUND LEAD TO THE ELECTRICAL CORD AND PLUG THE
SYSTEM INTO A NON-GROUNDED OUTLET. A laser system that is not properly
grounded
is
hazar
dous
and has the potential to cause severe or fatal electrical
shock
.
Without proper
g
r
ounding
,
the
laser
system may exhibit sporadic or
unpredictable
beha
vior
.
Always plug the system into a
pr
operly
grounded
(earthed)
outlet.
THE POWER SUPPLY CORD IS THE MAINS DISCONNECT DEVICE; THE EQUIPMENT
SHOULD BE LOCATED CLOSE TO AN EASILY ACCESSIBLE POWER OUTLET.
To
disconnect
the
equipment
from the supply
mains
,
the power cord should be
unplugged
from the power outlet
or
main power inlet (appliance coupler) of the
unit.
THE LASER SYSTEM IS DESIGNED AS A CLASSI, GROUP A, PLUGGABLE DEVICE.
I
t
is
also
designed for connection to
IT
power systems which provide the most
flexibility
to
the
user
.
THIS DEVICE IS SPECIFICALLY DESIGNED TO COMPLY WITH CDRH PERFORMANCE REQUIREMENTS
UNDER 21 CFR 1040.10 AND 1040.11 AND TO COMPLY WITH EUROPEAN LASER SAFETY
REGULATIONS UNDER EN60825-1. CDRH is the Center for the Devices of
R
adiolog
ical
Health division of the
Food and Drug Administration
(FDA)
in the USA. No guarantees of suitability or safety are provided for any use
other than those specified by Universal Laser
S
y
st
ems
,
I
n
c
.
CO2Laser Safety
ULS Laser systems are designed to support a sealed carbon dioxide (CO2) laser cartridge that produces intense
invisible laser radiation at a wavelength of 10.6 microns in the infrared spectrum. For your protection, the laser is
contained within a Class 1* enclosure designed to completely contain the CO2laser beam. CAUTION: Use of
controls or adjustments or performance of procedures other than those specified herein may result in exposure to
hazardous levels of invisible laser radiation.
•Laminated safety glass is employed in the viewing window to block 10.6 micron laser radiation from CO2
lasers. This viewing window will block transmission of CO2laser radiation allowing safe observation of
laser processing. Do not operate the laser system if the view port is damaged, with any of the doors
removed or if any of the safety interlocks are defeated.
•
T
he
intense light that appears during the engraving or cutting process is the product of material
c
ombustion
or vaporization. DO NOT STARE AT THIS INTENSE LIGHT FOR LONG PERIODS OF
TIME OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS SUCH AS BINOCULARS OR
MICROSCOPES.
•
This
device contains a visible Red Diode Pointer
(Class 2)
to aid in positioning material to be cut or
eng
ra
v
e
d
.
DO NOT LOOK DIRECTLY INTO THE RED LASER BEAM OR USE A REFLECTIVE
SURFACE TO REDIRECT OR VIEW THE RED LASER BEAM. NEVER ATTEMPT TO VIEW THE RED
LASER BEAM USING OPTICAL INSTRUMENTS SUCH AS BINOCULARS OR MICROSCOPES.
•
T
he
user door(s) are safety interlocked which will prevent the CO2laser beam from firing when the
user
door(s)
are
opened
.
T
he
Red Diode Pointer is NOT safety interlocked and can be automatically
activated with the
door(s)
either open or
closed
.
•DO NOT OPERATE THE LASER SYSTEM IF ANY SAFETY FEATURES HAVE BEEN MODIFIED,
DISABLED OR REMOVED.
This
may lead to accidental exposure to invisible CO2laser radiation
which may cause severe
ey
e
damage
and/or severe burns to your skin.
•
Always
use caution when
operating
a laser
sy
st
em.
*An
enclosure which does not permit human access to laser radiation in excess of the accessible emission limits of
Class
1
for the applicable
wavelength
and emission
duration.
10
