United Spa Controls C5 Series Guía
T8-S To
p
side
Installation Manual & User’s Guide
For C5 Series Spa Controls with the T8-S Topside
Revision 06.19
Disclaimers
1
End User Disclaimer:
United Spa Controls systems have absolutely no end user
serviceable parts. United Spa Controls does not authorize attempts
by the spa owner/user to install or repair/service any United Spa
Controls products.
Non-qualied users should never open or remove the control box’s
cover, as this will expose dangerous voltage points and other
serious risks.
Non-qualied users should not attempt to make changes to
the topside’s programming, as mis-programming can result in
malfunction or possible damage.
Please contact your dealer or a locally licensed service center for
service and technical support.
Warranty Disclaimer:
It is extremely important that any user read this user’s guide in
it’s entirety before attempting to operate this United Spa Controls
system. Any damage that may occur due to misuse may void the
warranty. See warranty page for more information.
Safety Disclaimer:
When using this electrical equipment, basic safety precautions
should always be followed. Read and follow the important safety
instructions in the safety section before and during use.
Table of Contents
2
Disclaimers ....................................1
Safety .........................................4
For Qualied Service Professionals Only!
T8-S Topside Installation .........................7
About The T8-S Topside ..........................8
Using The T8-S Topside ..........................9
For Qualied Service Professionals Only!
T8-S Topside Initial Conguration .................10
Table of Contents
3
User Congurable Settings ......................14
T8-S User Settings Menu ......................14
Entering/Using the User Settings Menu ...........14
T8-S User Settings Menu Tree ..................15
Heat Mode .................................17
Time Settings ...............................17
Filtration Settings ............................18
Interface Settings ............................19
Lock Operation ..............................19
Operation Instructions ..........................20
Temperature Operation ........................20
Toggling Display Orientation ....................22
Operating Pump-1 ............................23
Operating Pump-2 (If Applicable) ................24
Operating Aux (Pump-3/Air Blower - If Applicable) ...25
Operating the Spa Light .......................25
Standard Display & Error Messages . . . . . . . . . . . . . . . 26
Warranty ......................................28
Safety
4
Important Safety Instructions:
When using this electrical equipment, basic safety precautions
should always be followed, including the following.
Read and follow all instructions!
1. Warning: Children should not use spas or hot tubs without adult
supervision
AVERTISSEMENT: NE PAS LAISSER LES ENFANTS UTILISER
UNE CUVE DE RELAXATION SANS SURVEILLANCE
2. Warning: Do not use the spa unless all suction guards are installed
to prevent body and hair entrapment
AVERTISSEMENT: POUR ÉVITER QUE LES CHEVEUX OU
UNE PARTIE DU CORPS PUISSENT ÊTRE ASPIRÉS, NE PAS
UTILISER UNE CUVE DE RELAXATION SI LES GRILLES DE
PRISE D’ASPIRATION NE SONT PAS TOUTES EN PLACE.
3. Warning: People using medication and/or having an adverse medical
history should consult a physician before using a spa or hot tub
AVERTISSEMENT: LES PERSONNES QUI PRENNENT DES
MÉDICAMENTS OU ONT DES PROBLÈMES DE SANTÉ
DEVRAIENT CONSULTER UN MÉDECIN AVANT D’UTILISER UNE
DE RELAXATION
4. Warning: People with inpectious diseases should not use a spa or
hot tub
AVERTISSEMENT: LES PERSONNES ATTEINTES DE MALADIES
INFECTIEUSES NE DEVRAIENT PAS UTILISER UNE CUVE DE
RELACATION
Safety
5
5. Warning: To avoid injury exercise care when entering or exiting
the spa or hot tub
AVERTISSEMENT: POUR ÉVITER DES BLESSURES, USER DE
PRUDENCE EN ENTRANT DANS UNE CUVE DE RELAXATION ET
EN SORTANT
6. Warning: Do not use drugs or alcohol before or during the use of a
spa or hot tub to avoid unconsciousness and possible drowning
AVERTISSEMENT: POUR ÉVITER L’ÉVANOUISSEMENT ET
LA NOYADE ÉVENTUELLE, NE PRENDRE NI ALCOOL AVANT
D’UTILISER UNE CUVE DE RELAXATION NI QUAND ON S’Y
TROUVE
7. Warning: Pregnant or possibly pregnant women should consult a
physician before using a spa or hot tub
AVERTISSEMENT: LES FEMMES ENCEINTES, QUE LEUR
GROSSESSE SOIT CONFIRMÉE OU NON, DEVRAIENT
CONSULTER UN MÉDECIN AVANT D’UTILISER UNE CUVE DE
RELAXATION
8. Warning: Water temperature in excess of 100°F (38°C) may be
injurious to your health.
AVERTISSEMENT: IL PEUT ÊTRE DANGEREUX POUR LA SANTÉ
DE SE PLONGER DANS DE L’EAU À PLUS DE 38° C (100° F)
9. Warning: Before entering a spa or hot tub measure the water
temperature with an accurate thermometer
AVERTISSEMENT: AVANT D’UTILISER UNE CUVE DE
RELAXATION MESURER LA TEMPÉRATURE DE L’EAU À L’AIDE
D’UN THERMOMÈTRE PRÉCIS
10. Warning: Do not use a spa or hot tub immediately following strenuous
exercise
Safety
6
AVERTISSEMENT: NE PAS UTILISER UNE CUVE DE RELAXATION
IMMÉDIATEMENT APRÈS UN EXERCICE FATIGANT
11. Warning: Prolonged immersion in a spa or hot tub may be injurious
to your health
AVERTISSEMENT: L’UTILISATION PROLONGÉE D’UNE CUVE DE
RELAXATION PEUT ÊTRE DANGEREUSE POUR LA SANTÉ
12. Warning: Do not permit electric appliances (such as a light, telephone,
radio, or television) within 5 feet (1.5 m) of this spa or hot tub
AVERTISSEMENT: NE PAS PLACER D’APPAREIL ÉLECTRIQUE
(LUMINAIRE, TÉLÉPHONE, RADIO, TÉLÉVISEUR, ETC) À MOINS
DE 1.5M (5 FEET) DE CETTE CUVE DE RELAXATION
13. Caution: Maintain water chemistry in accordance with manufacturer’s
instruction
ATTENTION: LA TENEUR DE L’EAU EN MATIÈRES DISSOUTES
DOIT ÊTRE CONFORME AUX DIRECTIVES DU FABRICANT
14. Hyperthermia occurs when the internal temperature of the body
reaches a level several degrees above the normal body temperature
of 98.6°F (37°C). The symptoms of hyperthermia include drowsiness,
lethargy, and an increase in the internal temperature of the body.
Effects: 1- Unawareness of impending hazard.
2- Fetal damage in pregnant women.
3- Failure to recognize the need to exit spa.
4- Physical inability to exit spa.
5- Unconsciousness and danger of drowning.
6- Failure to perceive heat.
15. Warning: The use of alcohol or drugs can greatly increase the risk of
fatal hyperthermia in hot tubs and spas
AVERTISSEMENT: LA CONSOMMATION D’ALCOOL OU DE
DROGUE AUGMENTE CONSIDÉRABLEMENT LES RISQUES
D’HYPERTHERMIE MORTELLE DANS UNE CUVE DE RELAXATION
T8-S Topside Installation
7
Topside Control Installation
The T8-S topside should be installed on an outward facing edge of the spa
so it’s not subject to trapped steam/moisture under the cover, as shown:
Failure to do so will result in the need to prematurely replace the graphic
decal assembly on the face of the topside control.
The T8-S topside control requires just a single 1.75” hole to be cut out of
the shell of the hot tub for installation, as shown:
Once ready to install, plug one end of the topside cable into the back of
the T8-S, snake the cable through the cutout in the shell and down to the
control box, and plug the opposite end of the topside cable into the control
box. Afx the topside by peeling off the paper over the adhesive tape on
the back of the topside, than pressing it rmly into place, slowly pressing
rmly all around the perimeter to assure a good bond to the shell.
Approx. 3-3/8” (83.5 mm)
Approx. 6-3/8” (~161 mm)
2-1/4” Hole 2-1/4” Hole 2-1/4” Hole
1-5/8” 1-5/8”
About The T8-S Topside
8
The T8-S Topside
You will be using the T8-S topside to operate your United Spa Controls C5
Series control box. The T8-S is pictured below, with the descriptions of the
items that will be referenced throughout this user’s guide.
10 - LED Display
20 - Jets-1 Button & Indicator Light
30 - Aux Button & Indicator Light
40 - Jets-2 Button & Indicator Light
50 - Temp Down Button
60 - Heat Indicator Light
70 - Light Button
80 - Temp Up Button
1
6
5
2
4
8
7
3
Using The T8-S Topside
9
Using The T8-S Topside
T8-S topsides use United Spa Controls’ patented technology.
This hybrid switching technology marries the satisfaction of having a
physical button to press, with the longevity and reliability of touch-panel
switching system with no moving parts to break down over time.
If your button presses are not registering, make sure that you are pushing
the raised buttons completely at against the panel, and that you are
waiting a second between button presses.
Upon Power-Up
Whenever the T8-S topside is powered on, the unit will ash ‘T8’ followed
by the units rmware version number (Example: ‘T808’) three times while
it starts up. All congurable settings are saved to permanent memory, the
only thing that needs to be set upon power-up of a T8-S topside that has
already been congured previously is the current time (it will default to 12
AM upon power-up).
Checking Software Version After Power-up
The software version can be accessed after initial power-up by simply
pressing and holding the ‘Aux’ button until display reads ‘PL-1’, followed
by pressing the Light button. The display will then, as it did at start up, ash
‘T8’ followed but the rmware version number three times. For example, a
T8-S with rmware version 8 would ash ‘T808’ three times.
NOTE: Do NOT connect/disconnect the T8-S topside while the control box
is powered. Always make sure the power is shut off at the breaker before
removing/installing a topside, as to avoid damaging the electronics.
