Unitech MS920 Manual de usuario

MS920 Quick Start Guide

The Unitech MS920 2D Pocket Scanner

Scan here to begin pairing the MS920 to a host device. Note: This factory

default barcode will return your scanner to its original factory settings, a

useful feature for troubleshooting purposes.

Begin pairing

Step 2:

Bluetooth Mode: HID

Scan here to continue the pairing process between your mobile device

and the MS920.

HID Mode

Step 3:

Scan to indicate the beginning of the pincode sequence.

Pincode Start

Step 5:

connect and Charge

1. Flip the rubber cover up to expose the micro USB port on the scanner.

2. Plug the micro USB cable into the port on the scanner and into a free USB port of a host computer. Charge for 4 hours.

Step 1:

SETUP AND Pairing

The following steps will help you pair the MS920 to a host device.

Open a word processing program or app such as Microsoft Word

or Notepad on your host. Now scan the following barcode:

Test & Finish

If the word “Unitech” appears on the screen you have succesfully

installed your scanner. Congratulations!

Step 8: Enter Barcode

Scan to indicate the end of the pincode sequence. Your device

is now paired with the MS920.

Step 7:

Enter

Scan the pincode sequence provided by your device using these barcodes.

Numeric Barcodes

Step 6:

Enable Bluetooth on host

Go to your host device (phone/tablet/computer) settings

and turn on the Bluetooth function.

The MS920 will appear on your device as

“Wireless Scanner” or “Unitech BT”

Select/Press “Wireless Scanner”

If you have Bluetooth 2.1, “Wireless Scanner” will now

appear as paired. Your host device is now paired with

the MS920.

*If your device does not pair automatically and you

are prompted to enter a pincode, proceed to step 5*

Step 4:

Factory Default

MS920 Quick Start Guide

How can we help you?

The MS920 should be recognized as a generic HID device by

your host device, similar to a standard keyboard. This allows

you to scan into any eld that you could normally type into.

Unitech’s professional support team is available to quickly

answer questions or technical-related issues. Should equipment

issues occur, please contact a Unitech Service Representative

at (800) 861-8648 for more information.

You can bring up the keyboard on Apple iPhones using

the MS920.

Simply double tap the scan button on your MS920.

Double tap the scan button once again to hide the

keyboard.

Keyboard Toggle

Settings and configuration

The following section covers the most common

conguration settings for your MS920 scanner.

For additional conguration options please visit

unitechscanners.com/MS920 and select the “Download”

tab. You will nd the User’s Manual and a variety of

other resources.

Scan here to switch from Bluetooth Mode to Batch Mode. Data will now

be stored in the internal memory of the MS920 and the MS920 will no

longer transmit data via Bluetooth.

Switch to Batch mode

Scan here to send data from the MS920 to your host device after

collecting the data in Batch Mode.

transfer data

Scan these barcodes if you wish to erase the data stored on your

MS920. Please keep in mind that this process is irreversible.

Scan here to switch back to Bluetooth Mode. You can now pair the

MS920 with a host.

switch to Bluetooth Mode

delete data

Transfer Data Bluetooth ModeEnable Batch
