Unitech PA950 Manual de instalación y operación

1-1

Unitech PA950

Product Reference Guide

400365 REV A

All product names mentioned in this manual may be

trademarks or registered trademarks of their respective

companies and hereby acknowledged.

1-2

Table of Contents

Chapter 1 Introduction

Chapter 2 Pocket PC Basic

Chapter 3 Setting

Chapter 4 ActiveSync

Chapter 5 Calendar

Chapter 6 Contacts

Chapter 7 Tasks

Chapter 8 Notes

Chapter 9 Pocket Word

Chapter 10 Pocket Excel

Chapter 11 Windows Media Player

Chapter 12 Microsoft Reader

1-3

Chapter 13 Calculator

Chapter 14 Games

Chapter 15 Pictures

Chapter 16 Terminal Services Client

Chapter 17 Terminal

Chapter 18 Pocket Internet Explorer

Chapter 19 Inbox

Chapter 20 MSN Messenger

Chapter 21 Bluetooth

Chapter 22 Scanner

Chapter 23 Technical Specification

Chapter 24 Contact Information

1-4

Introduction

PA950

Accessories

Tour of PA950

First Step with PA950

Supplying Power to PA950

Charring the Terminal Battery

Using the PA950 Keypad

PA950



Thank you for purchasing Unitech PA950.



Your PA950 is a rugged PDA with Microsoft Windows®Mobile 2003

Software for Pocket PCs and incorporates an integrated bar code

scanning laser device, and a 19 key-keypad.



This PA950 product reference guide will guide you to access your

PA950.

1-5

Accessories

The listed accessories are for PA950, please contact your sales

representive for availability.

5000-600627 Cradle for PA960 / PA950

5100-600635 2 Slot Battery Charger for PA960/PA950

5100-600636 4 Slot Battery Charger for PA960/PA950

1550-600622 Cable Module RS232+DC 16PIN 26AGW 200cm

1550-600623 Cable Module USB+DC 16PIN 26AGW 200cm

1550-600626 Cable Module USB(A/B) 4 Pin 8AQG2C24AWG2C 150cm

1550-600682 Cable Module PA960 DB9F to DB9M 26AWG 200cm

1979-600646 Stylus for PA960/PA950

1400-201002 BATTERY LITHIUM 7.4V 720MAH

1010000550 AC 110-240V DC 9V/2A Power Adaptor with US Plug

1.3*3.5*10mm

1010000560 AC 110-240V DC 9V/2A Power Adaptor with EU Plug

1.3*3.5*10mm

10100000570 AC 110-240V DC 9V/2A Power Adaptor with UK Plug

1.3*3.5*10mm

Car Kit Car Kit for PA960/PA950

1-6

Tour of PA950: Front View

LCD Displa

LED

Indicato

Bar Code

Scanner

Right Scanner

Trigger

Powe

On/Of

Keypad

Stylus

1-7

Tour of PA950: Back View

Stylus

Product Label

Battery

Component

Software

Reset Pin

Infrared

Port

Hardware

Reset Pin

Serial/USB Port

Hanstrap Connector

Microphone

Speaker

Earphone Jack

Handstrap Connector

1-8

Tour of PA950: Back View (Con.)

Backup Battery Switch

(Left: Backup Battery Off, Right: Backup Battery On)

SD Slot Door:

Remove the door to

access SD Slot.

1-9

First Step with the PA950

In order to start using your PA950 for the first time:



Check that the backup battery is on.

Backup Battery Switch

(Left: Backup Battery Off, Right: Backup Battery On)

1-10



Install Main Battery Pack

Remove the battery door component by using the screwdriver, which is

integrated in stylus.

Position the battery with the label side toward you.

Insert and fully seat the battery pack.

Make sure the shape of battery pack fits the shape of battery component.

Main Battery Pac
