Unit UT526 Manual de usuario

Operating Manual

UT525/526

Electrical Testers

UT525/526 Operating Manual

Contents

Item Page

I. Safety Precautions

II. Features

III. Specications

IV. Front View of the Instrument

V. Function of Keys and Dial Plate

VI. Testing Preparation

VII. Earth Testing

VIII. RCD Testing

IX. Voltage Testing

X. Insulation Resistance Testing

XI. Replace Battery

XII. Maintenance

UT525/526 Operating Manual

Overview

UT525/UT526 is a digital multi-functional electric testing instrument adopting

new design and integrating large scale analog integrated circuit, digital circuit

and microprocessor chips, which can mainly test parameters of residual current

device (RCD), earth, insulation resistance, DCV and ACV; with features of full

functions, high accuracy, stable performance, easy and reliable operation, it

is available to test RCD, insulation and earth of electric equipments. UT525/

UT526 is the ideal selection for repairing, maintaining and testing RCD of all

electric equipments.

I. Safety Precautions

This instrument was designed, manufactured and tested according to

IEC61010 safety standard (Safety Requirements for Electrical Equipment).

This Instructions describe the warnings and safety rules which ensure the safe

operation and safe state of the instrument, which the user must follow. Please

read following instructions before using.

Warning

● Please read and understood the Instructions before using.

● Please follow the requirements of the Instructions, keep the

Instructions well for further reference at any time.

● During testing, incorrect operation will cause accident and

instrument damage.

Sign on the instrument tell the user that some operations should be

made according to relative requirements of the Instructions to ensure safety

operation of the instrument.

UT525/526 Operating Manual

It means under some conditions, the operation may cause

serious or fatal damages may be caused.

Warning It means taking care to keep away from electric shock.

It means avoiding instrument damage and gain accurate

testing.

UT525/526 Operating Manual

Note

Danger

● Do not test circuit with AC440V/DC440V or above.

● Do not test in the place with inammable conditions.

● Do not operate the instrument if the surface of the instrument is wet or the

hand is wet.

● During testing, do not touch the conductive part of the testing pen.

● Do not open the battery cover during testing.

● During testing insulation and RCD, do not touch the circuit to be tested.

Warning

● When there is anything unusual to the instrument, such as the instrument

is damaged or the metal is exposed, please do not use it.

● Operate carefully under the voltage over 33Vrms, 46.7Vacrms or 70Vdc,

electric shock may be caused under such kind of voltage during operating.

● After completing high resistance testing, the charge storage of the circuit

to be tested must be released.

● Do not replace battery if the instrument is in place with humidity.

● Make sure the all testing wires are connected with the testing ports rmly.

● Before opening cover of the battery, please make sure the instrument is

turned off.

Note

● Before testing resistance, the circuit to be tested must be discharged

completely and separated from the power circuit absolutely.

● If the testing pen or adapter is damaged and needs to be replaced,

please replace with testing pen or adapter with the same model and

electric specications.

● When the battery sign ( ) shows that the battery is used up, please do

not use the instrument any more. If the instrument won’t be used for a long

time, please take out the battery and then keep the instrument well.

UT525/526 Operating Manual

● Do not put or use the instrument in the place with high temperature, high

humidity, inammable or explosive matters and high electromagnetic eld.

● Do not clean the cover of the instrument with wet cloth of detergent, do not

use abrasives or solvent.

● When the instrument is wet, please make it dry and then put it in the

proper place.

UT525/526 Operating Manual

II. Features

Danger of electric shock may happen

The instrument has double-insulation or reinforced insulation

Earth

● Designed and manufactured strictly according to IEC61010 safety

standard, the instrument meets with Over Voltage Standard (CATIII600V)

and safety standard of Class II Pollution.

● Auto discharge function.

● Red warning light.

UT525/526 Operating Manual

III. Specications

Error limit: ±(a% reading + digits), one year of warranty period

Environment temperature: 23±5℃

Environment humidity: 45-75%RH

UT525/UT526 RCD testing indexes

RCD testing current 10mA 30mA 100mA 300mA

Applied voltage Voltage: 220V±10%, frequency: 45Hz-65Hz

Accuracy tolerance RCD testing current accuracy tolerance with AC (220V±2): (0+10%)

Testing time

range when

switch of

RCD is off

Accuracy tolerance ±(5%+2)

(10mA) range: 0-2,000mS

(30mA) range: 0-500mS

(100mA) range: 0-300mS

(300mA) range: 0-300mS

UT525/526 Operating Manual

UT525 earth testing indexes

Rated voltage About 5.0V

Test range 0.01Ω-200Ω

Test current ＞200mA for 0.00Ω-2.00Ω

Accuracy tolerance 0.01Ω-200Ω: ±(2%+5)

UT526 earth testing indexes

Rated voltage About 5.0V

Test range 0.01Ω-2,000Ω

Test current ＞200mA within 0.00Ω-2.00Ω

Accuracy tolerance 0.01Ω-2,000Ω: ±(2%+5)
