Uniden 2315+2 Manual de usuario

WDECT

2315

Wide Band Digital

Technology provides

the clearest sound

and the best privacy.

Guide

Quick Start

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page a

[ i ]

INSTALLATION & SAFETY

• This symbol

indicates important

operating and

servicing instructions.

• The earcap of this

telephone may attract

and retain small

metallic objects.

AVOID -

connecting

more than

phones as ringing

may be impaired

AVOID -

multi power boards.

CHARGE -

the new phone

for 15 - 20 hrs.

AVOID -

Moisture

Don’t -

overload the

power outlet.

AVOID -

moisture

AVOID -

Television sets and

other electronic

appliances AVOID -

Microwave ovens

AVOID -

Computers

AVOID -

other cordless

telephones

CHOOSE -

a central location

Note: Ringing will not be impaired by

adding extra cordless handsets.

Choosing the best location for your phone.

When choosing a location for your phone there are a number of appliances the phone

should not be near, and areas you should avoid.

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page i

[ ii ]

QUICK START GUIDE

This page is a very condensed version of the Owner’s

Manual. It is designed to allow you to get your phone

installed and operating as quickly as possible -

however it does not attempt to explain any of the

advanced features of the WDECT2315 series.

1) Connect the AC adapter to the DC IN 9V

jack and to a standard AC wall outlet.

AC adapter

(supplied)

To DC IN 9V

To AC outlet

Route the cord.

Make sure the AC

Adapter/s remains

switched ON at all

times. Use only the

Uniden AC Adapter/s

supplied with this unit.

Start

Here!

Installing the Base Unit

2) Connect the telephone line cord to the

TEL LINE jack and to a telephone socket

on the wall.

HIGH SPEED INTERNET

If your phone line also has High Speed

Internet, please insure you are using an

approved line filter before connecting the

telephone line cord.

Australia

New Zealand

Telephone line cord

To TEL LINE

To telephone socket

For wall mounting, see “Mounting the

Base Unit on a Wall” on page 6.

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page ii

[ iii ]

Installing the battery pack

1) Press down on the battery cover release and slide the

cover down until it comes off.

2) Connect the battery plug to the socket at the rear of the

battery compartment. The RED and BLACK battery wires

must match the RED and BLACK dots on the phone case for

the plug to fit properly. Press firmly until it clicks

into place.

3) Securely close the battery compartment cover by sliding it

up until it snaps into place.

Red

Wire

Black

Wire

3) Set the base on a desk or tabletop.

Connecting the charger

1) Connect the AC adapter into the charging cradle

and to a AC wall outlet.

2) Set the charger on a desk or tabletop.

• Charge the handset

battery pack for at

least 15-20 hours

before using your

new cordless

telephone for the

first time.

• Use only the Uniden

rechargeable battery

pack (BT-446)

supplied with your

cordless telephone.

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page iii

[ iv ]

Charging the handset(s)

1) Place the handset(s) in the main base unit or charging

cradle with the keypad facing forward.

2) Make sure the charge LED illuminates. If the LED does not illuminate, check to see

that the AC adapter is plugged in and that the handset makes good contact with the

base charging contacts.

• After installing the batteries in the handset, charge your handset at least 15-20 hours. During a power cut

or if the AC adapter

is switched off,

this telephone

will not operate.

Recharge your phone

on a regular basis by

returning the handset

to the base after

each phone call.

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page iv

[ v ]

CONTENTS

INSTALLATION & SAFETY i

QUICK START GUIDE ii

CONTENTS v

GETTING STARTED 1

Controls and Functions 1

Uniden Company Philosophy 3

Welcome 3

Features 4

Checking the Package Contents 5

Terminology 5

Mounting the Base Unit on a Wall 6

Battery Maintenance 7

Installing the Beltclip 8

Headset Installation 9

Display and Icons 9

About the Menu Options 10

Setting up the Menu 13

BASICS 20

Making and Receiving Calls 20

Keypad Lock 21

Placing a Call on Hold 21

Redialing a Call 22

Adjusting the Handset Ringer,

Earpiece and Speaker Volume 23

Mute Microphone 24

Tone Dialing Switch-Over (Australia Only) 24

Traveling Out-of-Range 24

Clarity Booster 25

Privacy Mode 25

Find Handset 26

Flash and Call Waiting 26

Using One Touch Voice Mail Access 27

PHONEBOOK 28

Phonebook 28

Storing Phone Numbers, Names,

Distinctive Rings, and Speed Dial 28

Steps for Entering Names and Special Characters 30

Viewing the Phonebook 32

Making Calls Using the Phonebook 33

Speed Dialing 33

Editing or Erasing a Stored Name,

Phone Number, Distinctive Ring, and Speed Dial 34

Chain Dialing 35

CALLER ID 36

Caller ID 36

Viewing the Caller ID List 37

Deleting a Caller ID Message 38

Using the Caller ID Message List 39

EXPANDING YOUR PHONE 40

Expanding your Phone 40

Using Two Way Communication between the Handsets

Anywhere without the Base (Directlink) 42

Room Monitor 42

3-Way Conferencing 43

Intercom/Call Transfer Feature 43

Replacing the Base 44

ADDITIONAL INFORMATION 45

Changing the Digital Security Code 45

Note on Power Sources 46

TROUBLESHOOTING 47

INDEX 49

WARRANTY 50

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page v

GETTING STARTED

[ 1 ]

CONTROLS AND FUNCTIONS

1. Handset Antenna

2. Headset Jack Cover

3. Beltclip Hole

4. Hands-Free Speaker

5. Handset Battery Compartment

6. New Message LED

7. Handset Earpiece

8. LCD Display

9. /del Key

10. /vol/ / Key

a. ringer volume control

b. scroll keys for display screen

11. Key

12. redial/pause Key

13. speaker Key

14. Key

15. Key

16. Key

17. Key

18. Key

19. phonebook Key

20. /transfer/int’com Key

21. Handset Microphone

22. Handset Charging Contacts

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page 1

[ 2 ]

27 28

23. Base Antenna

24. Base Charging Contacts

25. charge LED

26. Key

27. TEL LINE Jack

28. DC IN 9V Jack

29. Charging Contacts

30. charge LED

31. DC IN 9V Jack

Charger BaseMain Base

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page 2

Congratulations on your purchase of the Uniden Multi-Handset Cordless System telephone. This unit is

different from conventional cordless telephones. When the base unit is connected to AC power and a

telephone line, it can support up to 4 handsets. Using extra handsets, you can establish a 3-way conference

call (2 handsets and an outside line), while two other handsets are making an intercom call. You can now

place a fully featured cordless handset anywhere in your home or office where AC power is available to

connect the handset chargers.

Note: The illustrations in this manual are intended as a guide and may differ from actual unit.

WELCOME

[ 3 ]

To bring outstanding wireless communication products to people’s lives throughout the world.

UNIDEN COMPANY PHILOSOPHY

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page 3

[ 4 ]

Great features of this cordless phone include:

• Designed and Engineered in Japan

• Wide Band Digital Technology

• Multi (4) Handset Capable

• Digital Duplex Speakerphone on Handset

Advanced Alpha Display Caller ID Features:

• Alpha Memory Dialling

• POP ID - Caller Name Identification*

• 20 Individual Caller Tone Allocation*

• 100 Caller ID * Memories with Phonebook

• 3 Line Backlit Full Dot Matrix LCD Display with Clock

• Maxi-Sound - Extra Loud Handset Volume Control

• Intercom/Announce Call Transfer

• Handset Conferencing (2 Handsets + Outside Call)

• Two-Way Communication between Handsets Anywhere without the Base

• And More!

FEATURES

* Caller ID, POP ID and Individual Caller Tone Allocation (Distinctive Ring) features work only if you subscribe to the

service provided by your local telephone company. There is usually a fee for this service.

#Range may vary depending on environmental and/or topographical conditions.

UP409ZH (WDECT2315-2) OM 12/22/05 3:25 PM Page 4
