Uniden WDSS 5305 Manual de usuario

WDSS 5305

Accessory handset for

WDSS 5300 series

Owner’s Manual

Welcome

Congratulations on your purchase of the Uniden WDSS 5305

accessory handset and charger. You can place this fully featured

cordless handset anywhere your home has AC power.

Note: Illustrations in this manual are used for explanation

purposes. Some illustrations may differ from the actual unit.

Important!

The WDSS 5305 accessory handset will not operate until it is

registered to a Uniden main base. This manual describes how

to set up your new handset; for more detailed instructions on

operating your new handset, please refer to the manual supplied

with your base.

Terminology Used in this Manual

Base The main part of the phone that connects to your phone

line and lets you make and receive calls.

Charger A cradle that charges an accessory handset. It connects to

power but not to a phone line.

Accessory

Handset

A handset that works with an expandable phone base.

Accessory handsets must be registered to a base.

Standby The handset is not in use. If it is off the cradle, no line has

been activated. No dial tone is present.

Station Any handset or the base.

Talk A telephone line has been activated on the handset or the

base, enabling a dial tone.

Compatible Bases

This handset is compatible with Uniden's 5.8 GHz Digital

Expandable phone system: the WDSS 5300 series.

Please visit our website at www.uniden.com.au for Australian

model, www.uniden.co.nz for New Zealand model for the most

up-to-date list of compatible bases.

Installing the Accessory Handset

Checking the Package Contents

Make sure your package contains the following items. If any

items are missing or damaged, contact your place of purchase.

• Cordless Handset • Belt clip

• Charging Cradle • Printed Material

• AC Adapter, model # AAD-600S

Input: 240V AC 50 Hz Output: 9V DC 210 mA

• Rechargeable NiMH Battery Pack, model # BT-909

Capacity: 600 mAh, 3.6V

Installing the Battery

Follow the steps below to install the

rechargeable battery pack.

Using the nger indentation, press in on

the battery case cover and slide it down

to remove it.

Plug the battery connector into the

battery compartment jack. Be sure to

match the red and black wires to the

label near the jack.

Gently pull on the battery wires. If the

battery connector comes loose, try

connecting it again.

Replace the battery case cover and slide

it up until it clicks into place.

Note: Use only the Uniden BT-909 rechargeable battery pack

supplied with your cordless telephone.

Installing the Belt Clip

Line up the tabs with the holes on each side of

the handset. Press the belt clip down until both

tabs click into place.

To remove the belt clip, pull both sides of the clip

to release the tabs from the holes.

Installing the Optional Headset

Your phone may be used with an optional headset.

To use a headset, insert the headset plug into the

headset jack. Headsets may be purchased by

calling the Uniden Parts Department. See back

cover page for contact information.

Charging the Accessory Handset

The handset is powered by a rechargeable battery pack that

automatically recharges when the handset is placed in the

charger.

Connect the AC adapter to the DC IN 9V jack and to a 240V

AC outlet that is not controlled by a wall switch.

Caution: Use only the Uniden AAD-600S adapter.

Set the charger on a

desk or tabletop, and

place the handset in the

charger with the keypad

facing forward.

Make sure that the

charge LED illuminates.

If the LED does not

illuminate, check to see

that the AC adapter

is plugged in and

the handset makes

good contact with the

charging contacts on

the charging cradle.

Charge the handset battery pack for at least 15-20 hours

before using your new handset for the rst time.

Route the

cord.

To AC outlet To DC IN 9V

AC adapter (supplied)

Route the

cord.

To AC outlet To DC IN 9V

AC adapter (supplied)

Registering the Handset

You must register the handset to the base before you can use it.

Only one handset can be registered at a time. (If an accessory

handset has ever been registered to a base, you must reset the

handset before you can register it to a new base.)

To register to a WDSS 5300

series base, place the accessory

handset in the base. While the

handset is registering, HANDSET

REGISTERING appears in the

LCD. When REGISTRATION

COMPLETE is displayed, the

handset has been registered to

the base.

If REGISTRATION FAILED

appears, remove the handset from

the base and try again.

Resetting the Handset

If you want to register the handset to a different base or replace

a handset with another one, you must rst clear the registration

information from the base and the handset.

Press and hold [ ] and [#] for at least 5 seconds, until the

SYSTEM RESET menu appears.

Select the DEREGISTER HS

submenu by pressing [select/ ].

WHICH HANDSET? appears in the

display.

Use [ ] or [ ] to select the handset ID to be de-registered

from the list, and then press [select/ ]. DEREGISTER HS

appears.

Press [ ] to move the cursor to YES, and then press

[select/ ]. You will hear a conrmation tone.

Charge the handset

for 15-20 hours.

Place the extra

handset in the main

base to register.

4GIKUVTCVKQP

%QORNGVG

Charge the handset

for 15-20 hours.

Place the extra

handset in the main

base to register.

4GIKUVTCVKQP

%QORNGVG

9JKEJ*CPFUGV!

*CPFUGV

*CPFUGV

9JKEJ*CPFUGV!

*CPFUGV

*CPFUGV

Resetting the Handset Without the Base

If the original base this handset was registered to is not

available for some reason (for example, it is lost or somehow

incapacitated), you can still reset the handset and use it with

another base.

Press and hold [ ] and [#] for more than 5 seconds, until the

SYSTEM RESET menu appears.

Press [ ] to move the cursor to BASE UNAVAILABLE and

then press [select/ ]. BASE UNAVAILABLE appears.

Press [ ] to move the cursor to YES, and then press

[select/ ]. You hear a conrmation tone, and the handset

deletes its own link to the base without trying to contact the

base.

Now you are ready to register the handset to the new base.

Using the Interface

Parts of the Handset

Headset Jack Cover

Belt Clip Hole

Speakerphone Speaker

and Ringer

Handset Battery

Compartment

New Message LED

Handset Earpiece

LCD Display

[menu/clear] key

[ ] key (up)

[/ash] key (talk/ash)

[ ] key (phonebook/left)

10.

11.

[

/tone] key

[hold/int’com/xfer] key

[redial/pause] key

[select/ ] key (select/

messages)

[ ] key (caller ID/right)

[ ] key (end call)

[ ] key (down)

[#] key

[ ] key (speaker)

Handset Microphone

Handset Charging

Contacts

12.

13.

14.

15.

16.

17.

18.

19.

20.

21.

22.

8 15

Reading the Display

The handset display uses icons to tell you the status of your

phone. The table below lists the icons and what they mean.

Icon Status Description

Standby/

Talk

The battery icon indicates the handset

battery status: full, medium, low, and empty.

1((

Standby The ringer off icon indicates that the ringer

is turned off.

Talk The mute icon appears while the handset

microphone is muted.

Talk The boost icon appears when the Clarity

Boost feature is activated.

Talk The speaker icon appears when the handset

speaker phone is in use.

Talk The privacy icon appears when the Privacy

Mode is turned on.

The Standby Screen

When the phone is in standby, the handset display shows the

following items:

Using the Four-way Function Key

Your handset has a four-way

function key that allows you to

move the cursor or pointer on

the display and access the most

commonly used features at the

touch of a button. Press the

left side of the key to open the

phonebook. Press the right side

to open the Caller ID list.

To use this four-way key, place your thumb over the key on the

handset and move to the four positions to get the feel of how it

moves and operates.

*CPFUGV

0GY%+&

1(( Ringer off icon (when the ringer is off) / battery icon

Number of new Caller ID calls received

Handset ID

*CPFUGV

0GY%+&

1(( Ringer off icon (when the ringer is off) / battery icon

Number of new Caller ID calls received

Handset ID

View the

phonebook

Four-way

Function Key

View the

Caller ID

Down

View the

phonebook

Four-way

Function Key

View the

Caller ID

Down

Using the Handset Menus

To open the menu, press [menu/clear]. Select the option you

want by pressing the four-way function key. This will move the

cursor; the option currently selected has a triangle beside it.

Activate the selected option by pressing [select/ ]. To exit the

menu and return to standby, press [ ].

If you do not press a key within 30 seconds, the phone will time

out and exit the menu.

Entering Text from Your Handset

You can use the number keypad on your phone to enter text by

referring to the letters printed on each number key. When you

press the number key in a text entry eld, the phone displays

the rst letter printed on the number key. Press the number key

twice to display the second letter and three times to display the

third. Capital letters are displayed rst, then lower case letters,

then the number on the key.

If two letters in a row use the same number key, enter the rst

letter, then use [right] or [left] on the four-way function key to

move the cursor to the next position to enter the second letter.

Number of times key is pressedNumber of times key is pressed

For example, to enter "Movies":

Press [6] once to enter M.

Use [right] on the four-way function key to move the cursor

to the right.

Press [6] six times to enter o.

Press [8] six times to enter v.

Press [4] six times to enter i.

Press [3] ve times to enter e.

Press [7] eight times to enter s.

Press [select/ ] to end your text entry.

If you make a mistake while entering a name, use [right] or [left]

on the four-way function key to move the cursor to the incorrect

character. Press [menu/clear] to erase the wrong character, and

then enter the correct character. To delete all characters, press

and hold [menu/clear].

Tabla de contenidos

Otros manuales de Auricular de Uniden

Uniden

Uniden DSS 7905 Manual de usuario

Uniden

Uniden DCX309 Manual de servicio

Uniden

Uniden DECT 1705 Manual de usuario

Uniden

Uniden D1484 series Manual de usuario

Uniden

Uniden DECT 3105 Manual de usuario

Uniden

Uniden TCX860 Manual de usuario

Uniden

Uniden DSS 5805 Manual de usuario

Uniden

Uniden TCX860 Manual de usuario

Uniden

Uniden DCX309 Manual de usuario

Uniden

Uniden DSS7805 Manual de usuario

Uniden

Uniden DCX170BT Manual de usuario

Uniden

Uniden DCX300 Series Manual de usuario

Uniden

Uniden DECT1820 Manual de usuario

Uniden

Uniden DSS8900 Series Manual de usuario

Uniden

Uniden DECT 1802 Manual de usuario

Uniden

Uniden DCX170BT Manual de usuario

Uniden

Uniden DCX 520 Manual de usuario

Uniden

Uniden XS1215 Series Manual de usuario

Uniden

Uniden DCX160 Manual de usuario

Uniden

Uniden DCX770 - DCX 770 Cordless Extension Handset Manual de usuario

Uniden

Uniden XS1455/1455+1 Manual de usuario

Uniden

Uniden WDECT2380 Manual de usuario

Uniden

Uniden DCX309 Manual de usuario

Uniden

Uniden DCX170 Manual de usuario

Manuales populares de Auricular de otras marcas

Swissvoice

Swissvoice ePure HD Manual de usuario

Philips

Philips TD6736/BH051P Manual de usuario

ASCOM

ASCOM I62 - Manual de usuario

LG-Ericsson

LG-Ericsson LIP-9010 Manual de usuario

GE 1583 Manual de usuario

iiNet

iiNet Handset Manual de usuario

ASCOM

ASCOM 9p23 Manual de usuario

AT&T

AT&T DLP70110 Manual de usuario

AirCell

AirCell ST 3100 Manual de usuario

Eaton

Eaton HHIR-LCD-PROG Instrucciones de montaje

Mitel

Mitel 112 Manual de usuario

SBC

SBC SBC-381H Manual de usuario

Mitel

Mitel 5602 Manual de usuario

ASCOM

ASCOM d81 Messenger Instrucciones de instalación

SpectraLink

SpectraLink 7522 Manual de usuario

Avaya

Avaya L100 Series Cómo utilizar

ooma

ooma HD2 Handset Manual de usuario

Yealink

Yealink IPW56 Manual de usuario
