Uniden DSS3405 Manual de usuario

DSS3405

ADDITIONAL HANDSET

OWNER'S MANUAL

Welcome

Important!

Congratulations on your purchase of the Uniden DSS3405

accessory handset and charger. You can place this fully featured

cordless handset anywhere your home has AC power.

The DSS3405 accessory handset will not operate until it is

registered to a Uniden main base. This manual describes how to

set up your new handset; for more detailed instructions on

operating your new handset, please refer to the manual supplied

with your base.

The main part of the phone that connects to your

phone line and lets you make and receive calls.

A cradle that charges an accessory handset. It

connects to power but not to a phone line.

base.

Accessory handsets must be registered to a base.

The handset is not in use. If it is off the cradle, no

line has been activated. No dial tone is present.

Any handset or the base.

A telephone line has been activated on the handset

or the base, enabling a dial tone.

Base

Charger

Accessory

Handset

Standby

Station

Talk

Note: Illustrations in this manual are used for explanation

purposes. Some illustrations may differ from the actual unit.

Caution: The earcap of this telephone may attract and retain

small metallic objects

Terminology Used in this Manual

A handset that works with an expandable phone

(1)

Compatible Bases

Installing the Accessory Handset

Installing the Battery

This handset is compatible with Uniden's 2.4 GHz Digital

Expandable phone system: the DSS3415, DSS3455 and DSS3435

series. Visit www.uniden.com.au (Australian model) or

www.uniden.co.nz (New Zealand model) for the most up-to-date list

of compatible bases.

Make sure your package contains the following items. If any

items are missing or damaged, contact your place of purchase.

Follow the steps below to install the

rechargeable battery pack.

1. Using the finger indentation, press in on

the battery case cover and slide it down

to remove it.

2. Plug the battery connector into the

battery compartment jack. Be sure to

match the red and black wires to the label

near the jack.

3. Gently pull on the battery wires. If the

battery connector comes loose, try

connecting it again.

4. Replace the battery case cover and slide

it up until it clicks into place.

Checking the Package Contents

Note: Use only the Uniden BT-909 rechargeable battery

pack supplied with your cordless telephone.

• Cordless Handset • Charging Cradle

• AC Adapter, model #AAD-600S • Rechargeable NiMH Battery

Input: 240V AC 50 Hz Pack, model #BT-909

Output: 9V DC 210 mA Capacity: 600 mAh,3.6V

• Belt Clip • Printed Material

(2)

Installing the Belt Clip

Installing the Optional Headset

Line up the tabs with the holes on each side

of the handset. Press the belt clip down until

both tabs click into place. To remove the belt

clip, pull both sides of the clip to release the

tabs from the holes.

Your phone may be used with an optional

headset. To use a headset, insert the headset

plug into the headset jack. Headsets may be

purchased by contacting Uniden. See

warranty on inside back cover for contact

information.

The handset is powered by a rechargeable battery pack that

automatically recharges when the handset is placed in the

charger.

1. Connect the AC adapter to

the jack and to a

240V AC outlet that is not

controlled by a wall switch.

2. Set the charger on a desk or

tabletop, and place the handset in

the charger with the keypad facing forward.

3. Make sure that the LED illuminates. If the LED does not

illuminate, check to see that the AC adapter is plugged in and

the handset makes good contact with the charging contacts on

the charging cradle.

4. Charge the handset battery pack for at least 15-20 hours before

using your new handset for the first time.

Charging the Accessory Handset

DC IN 9V

Caution: Use only the

Uniden AAD-600S adapter.

charge

(3)

Registering the Handset

You must register the handset to the base before you can use it.

Only one handset can be registered at a time. (If an accessory

handset has ever been registered to a base, you must reset the

handset before you can register it to a new base).

To register to a DSS34 series base,

place the accessory handset in the

base. While the handset is registering,

HANDSET REGISTERING appears in

the LCD. When REGISTRATION

COMPLETE is displayed, the handset

has been registered to the base.

If REGISTRATION FAILED appears,

remove the handset from the base

and try again.

For DSS34 Series Bases

(DSS3415, DSS3455, DSS3435)

(4)

Resetting the Handset

Resetting the Handset Without the Base

If you want to register the handset to a different base or replace a

handset with another one, you must first clear the registration

information from the base and the handset.

1. Press and hold and

for at least 5 seconds, until

the SYSTEM RESET menu

appears.

2. Select the DEREGISTER

HS submenu by pressing .

WHICH HANDSET? appears in the display.

3. Use or to select the handset ID to be de-

registered from the list, and then press .

DEREGISTER HS appears.

4. Press to move the cursor to YES, and then press

. You will hear a confirmation tone.

If the original base the handset was registered to is not available for

some reason (for example, it is lost or somehow

incapacitated), you can still reset the handset and use it with

another base.

1. Press and hold and for at least 5 seconds, until the

SYSTEM RESET menu appears.

2. Press to move the cursor to REPLACING BASE and then

press . REPLACE BASE appears.

3. Press to move the cursor to YES, and then press

You hear a confirmation tone, and the handset

deletes its own link to the base without trying to contact the base.

4. Register the handset to the new base.

[ ] [#/>]

[select/ ]

[][]

[select/ ]

[]

[select/ ]

[ ] [#/>]

[]

[select/ ]

[]

[select/ ].

(5)

Using the Interface

Parts of the Handset

(6)

1. Antenna

2. Headset jack

cover

3. Belt Clip hole

4. Speakerphone

speaker and

ringer

5. Battery

compartment

6. New message

LED

7. Earpiece

8. LCD display

10.

11.

(talk/flash)

12. (phonebook)

13.

14.

(transfer/intercom)

15.

(select/messages)

16. (up)

17. (end call)

18. (Caller ID)

19. (down)

20. (pound)

21. (speaker)

22. Microphone

23. Charging

contacts

[menu/clear ]

[redial/pause ]

[ /flash ]

[]

[*/tone/<]

[xfer/intercom]

[select/ ]

[]

[#/>]

[]

Reading the Display

The handset display uses icons to tell you the status of your phone.

The table below lists the icons and what they mean.

When the phone is in standby, the display shows the following:

Your handset has a four-way function

key that allows you to move the cursor

or pointer on the display and access the

most commonly used features at the

touch of a button. Press the left side of

the key to open the phonebook. Press

the right side to open the Caller ID list.

ICON STATUS DESCRIPTION

The Standby Screen

Using the Four-way Function Key

(7)

Standby/Talk

Standby

Talk

The icon indicates the handset

battery status: full, medium, low, and empty.

The icon indicates that the ringer is

turned off.

The icon appears when you mute the

handset.

The icon appears while recording

a conversation.

The icon appears when the Clarity

Boost feature is activated.

The icon appears when the handset

speakerphone is in use.

The icon appears when Privacy

Mode is turned on.

battery

ringer off

mute

call record

boost

speaker

privacy

To use this four-way key, place your thumb over the key on the

handset and move to the four positions to get the feel of how it

moves and operates

To open the menu, press . Select the option you

want by pressing the four-way function key. This will move the

cursor; the option currently selected has a triangle beside it.

Activate the selected option by pressing . Pressing

again will go back to the previous menu. To exit the

menu and return to standby, press .

If you do not press a key within 30 seconds, the phone will

time out and exit the menu. When setting the day and time,

the time-out period is extended to two minutes.

If you subscribe to Caller ID, you can store up to 100 Caller ID

records. Your phone shares memory between your phonebook and

Caller ID entries. If you have 100 phonebook entries, Caller ID

records won't be saved (but will display when the call comes in).

Press to open the Caller ID record list. The first thing you will

see is the summary screen. From the summary screen, you have

the following options:

Using the Handset Menus

Making and Receiving Calls

Using Caller ID and Call Waiting

[menu/clear]

[select/ ]

[menu/clear]

[]

With the earpiece With the speakerphone

Make a

call

Answer

a call

Hang

*If AutoTalk is on, the phone answers when you remove the handset from the charging cradle.

**If Any Key Answer is on, you can press any key in the twelve-key pad.

(8)

1. Remove the handset from

the cradle.

2. Dial the number.

3. Press .

1. Pick up the handset.*

2. Press .**

Press or return the

handset to the cradle.

[ /flash ]

[]

1.Remove the handset from

the cradle.

2. Dial the number.

3. Press .

1. Pick up the handset.*

2. Press .

Press or return the

handset to the cradle.

[]

Scroll through the

records

Jump to records that

start with a certain

letter

Store a record in the

phonebook

Dial a record

Delete a record

Delete all records

Exit the Caller ID list

To scroll through the records from A to Z, press .

To scroll trough the records from Z to A press .

Press the number key corresponding to the letter

you want to jump to.

Find the record you want to store and press

Find the entry you want to dial and press

or .

Find the entry you want to dial and press

Press .

Press or press again if you are on a call.

[]

[select/ ]

[ /flash ]

[]

[menu/clear]

[] [ ]

Using Call Waiting

Redialing a Number

Using the Phonebook

If you subscribe to call waiting, a tone sounds if a call comes

in when you are on the phone. If you subscribe to Caller ID on

call waiting, the Caller ID information of the waiting call appears on

the display. Press and then on

the handset to switch between callers.

Press on the handset to switch

between callers.

To redial one of the last 3 numbers dialed on the handset, press

when the phone is in standby. This opens the redial

list. Use repeatedly or and to find the

number you want to dial, and then press or . (You

can also press or and then to redial

the last number dialed.)

You can store up to 100 names and numbers in the phonebook.

Your handset shares memory between your phonebook and Caller

ID entries. When all the phonebook entries are full, you will hear a

beep and MEMORY FULL appears. You cannot store any

additional names and numbers unless you delete some of the

existing ones.

For Australian model: [ /flash] 2

For New Zealand model: [ /flash]

[redial/pause]

[redial/pause] [ ] [ ]

[ /flash]

[ /flash ] [ ], [redial/pause]

[]

(9)

Tabla de contenidos

Otros manuales de Auricular de Uniden

Uniden

Uniden DRX402 Manual de usuario

Uniden

Uniden DCX320 Manual de usuario

Uniden

Uniden DCX320 Manual de usuario

Uniden

Uniden WXI3077 Manual de usuario

Uniden

Uniden DCX170 Manual de servicio

Uniden

Uniden DCX770 - DCX 770 Cordless Extension Handset Manual de usuario

Uniden

Uniden DCX400 Manual de usuario

Uniden

Uniden DECT 1705 Manual de usuario

Uniden

Uniden XC631Plus Manual de usuario

Uniden

Uniden WDECT2380 Manual de usuario

Uniden

Uniden DCX170BT Manual de servicio

Uniden

Uniden WDSS 5305 Manual de usuario

Uniden

Uniden 2305 Manual de usuario

Uniden

Uniden DCT646 Series Manual de usuario

Uniden

Uniden DCX 490 Manual de usuario

Uniden

Uniden WDECT2380 Manual de usuario

Uniden

Uniden DCX291 Manual de lista de piezas

Uniden

Uniden DCX700 Manual de usuario

Uniden

Uniden DCX300 Series Manual de usuario

Uniden

Uniden DCX350 Manual de usuario

Uniden

Uniden TCX 805 Manual de usuario

Uniden

Uniden D1484 series Manual de usuario

Uniden

Uniden DCX330 Manual de servicio

Uniden

Uniden WDECT3315 Manual de usuario

Manuales populares de Auricular de otras marcas

Swissvoice

Swissvoice ePure HD Manual de usuario

Philips

Philips TD6736/BH051P Manual de usuario

ASCOM

ASCOM I62 - Manual de usuario

LG-Ericsson

LG-Ericsson LIP-9010 Manual de usuario

GE 1583 Manual de usuario

iiNet

iiNet Handset Manual de usuario

ASCOM

ASCOM 9p23 Manual de usuario

AT&T

AT&T DLP70110 Manual de usuario

AirCell

AirCell ST 3100 Manual de usuario

Eaton

Eaton HHIR-LCD-PROG Instrucciones de montaje

Mitel

Mitel 112 Manual de usuario

SBC

SBC SBC-381H Manual de usuario

Mitel

Mitel 5602 Manual de usuario

ASCOM

ASCOM d81 Messenger Instrucciones de instalación

SpectraLink

SpectraLink 7522 Manual de usuario

Avaya

Avaya L100 Series Cómo utilizar

ooma

ooma HD2 Handset Manual de usuario

Yealink

Yealink IPW56 Manual de usuario
