Ubiquiti Horn-5-30 Manual de usuario

28/09/2020 Horn-5-30 Quick Start Guide

https://dl.ubnt.com/qsg/Horn-5-30/Horn-5-30_EN.html 1/5

Horn-5-30

Package Contents

Before You Begin

If you have an existing horn antenna, remove it.

Hardware Installation

The horn antenna is compatible with the following models:

IsoStation™ IS-M5

IsoStation IS-5AC

PrismStation™ PS-5AC

airFiber® AF-LTU

These instructions show the IsoStation; however, they also apply to the PrismStation and

airFiber AF-LTU.

Horn-5-30 Quick Start Guide

28/09/2020 Horn-5-30 Quick Start Guide

https://dl.ubnt.com/qsg/Horn-5-30/Horn-5-30_EN.html 2/5



Horn-5-30 Quick Start Guide

28/09/2020 Horn-5-30 Quick Start Guide

https://dl.ubnt.com/qsg/Horn-5-30/Horn-5-30_EN.html 3/5

3. Follow the installation instructions in the Quick Start Guide of your radio.

Specications

Horn-5-30

Dimensions 221.4 x 221.4 x 184.2 mm

(8.72 x 8.72 x 7.25")

Weight 1.1 kg

(2.43 lb)

Frequency Range 5.15 - 5.85 GHz

Compatible Radios IsoStation/PrismStation/airFiber AF-LTU

Gain 19 dBi

HPOL Beamwidth 30°

VPOL Beamwidth 30°

Elevation Beamwidth 30°

Polarization Dual-Linear

Cross-Pol Isolation 17 dB

Max. VSWR 2:1

Wind Loading

(with PrismStation) 56 N @ 200 km/h

(12.59 lbf @ 125 mph)

Wind Survivability 200 km/h

(125 mph)

Horn-5-30 Quick Start Guide

28/09/2020 Horn-5-30 Quick Start Guide

https://dl.ubnt.com/qsg/Horn-5-30/Horn-5-30_EN.html 4/5

Safety Notices

1. Read, follow, and keep these instructions.

2. Heed all warnings.

3. Only use attachments/accessories specied by the manufacturer.

WARNING:

Do not use this product in location that can be submerged by water.

WARNING:

Avoid using this product during an electrical storm. There may be a remote risk of

electric shock from lightning.

Electrical Safety Information

1. Compliance is required with respect to voltage, frequency, and current requirements indicated on

the manufacturer’s label. Connection to a diﬀerent power source than those specied may result in

improper operation, damage to the equipment or pose a re hazard if the limitations are not

followed.

2. There are no operator serviceable parts inside this equipment. Service should be provided only by a

qualied service technician.

Limited Warranty

ui.com/support/warranty

The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and,

where applicable, specify arbitration instead of jury trials or class actions.

Compliance

WEEE Compliance Statement

Online Resources

Horn-5-30 Quick Start Guide

28/09/2020 Horn-5-30 Quick Start Guide

https://dl.ubnt.com/qsg/Horn-5-30/Horn-5-30_EN.html 5/5

Horn-5-30 Quick Start Guide
