U.S. General PRO 62580 Instrucciones de montaje
Visit our website at: http://www.harborfreight.com
Specifications
Total Wt. Capacity 457 lb. Drawer Size Number of
Drawers
Weight Capacity
(per drawer)
Weight 101 lb. A12″ x 15-3/4″ x
2-1/2″ 5 59 lb.
Material Steel B12″ x 15-3/4″ x
5-3/4″ 2 59 lb.
Rails Ball-Bearing Weight Capacity for Top Panel 44 lb.
WARNING
To prevent serious injury and property damage:
2. Do not exceed 457 lb. weight capacity, evenly
distributed. Be aware of dynamic loading!
Sudden load movement may briefly create
excess load causing product failure.
3. Load evenly from bottom up.
4. Do not open or leave open more
than one drawer at a time.
5. Do not stand or climb on Cabinet.
6. Wear ANSI-approved safety goggles
during assembly and setup.
7. Only lift with partner and only while empty.
If cabinet still too heavy, get further assistance.
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2015 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
REV 15c
Mounting Instructions
1. Remove the handle from the side of
the 13 Drawer Roll Cabinet.
2. Using an assistant, carefully lift the
empty End Cabinet onto the side of the
Roll Cabinet and make sure that the lip on
the edge of the End Cabinet fits securely
over the top edge of the Roll Cabinet.
3. With an assistant ensuring that the
End Cabinet does not come loose, insert
one Bolt (8 x 1.25) into each hole and
tighten it into the side of the Roll Cabinet.
4. The End Cabinet is now secure
and ready to be loaded.
Bolts
13 Drawer
Roll Cabinet
7 Drawer End Cabinet
ALL DRAWERS MUST BE PUSHED IN FULLY BEFORE CABINET WILL LOCK.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • 1-888-866-5797
