FEATURES

8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX 414.354.7905 U-LINE.COM

CO1175

C O117 5 10 0 0 Se rie S

Black

Stainless

• 4.2 cubic feet overall refrigerator capacity maximizes storage

• Daily ice rate of up to 18 lbs and storage of up to 13 lbs of crescent ice cubes

(1/2"W x 3/4"H x 2-1/2"L)

• No drain required, easy and inexpensive installation, only required a 1/4" diameter

outside line

• Uses less than one gallon of water to produce 8 lbs of ice

• Mechanical dial controlled passive cooling system provides a stable and consistent

environment for optimum food and beverage storage

• Temperaturesettingfrom34to45˚Fprovidesexibilityforpreservingawide

variety of items

• Manual defrost

• UL residential listing

• Three tempered glass shelves with bullnose edge to maximize storage potential

• Twoin-doorstoragebinsprovideeasyaccessandstorageexibility

• Standard commercial stainless steel handle is interchangeable with professional

handle option on stainless steel model

• Stainless steel wrap door with black end caps on stainless model must be ordered

left or right hand hinged

• Blackmodeldooriseldreversible

• Blackvinylcladtexturedcabinetismoreresistanttoscratching,peelingandaking

• Unit can be built-in or freestanding providing a custom aesthetic

• Black model will accept a 1/4" insert panel to match with surrounding decor

• Allow 1/4" width overall for proper installation (see backside for details)

• No additional clearance around sides, top or rear of unit is needed for ventilation

• Durable,factoryinstalledlevellegsprovideamorepreciseundercountert

• Donotobstructfrontgrilleairow

• Product note: with left hand hinge installation, allow for 125º door swing to ensure

easy removal of ice bin

INTEGRATION INTERIOR / ExTERIOR PERFORmANCE

The Combo®Models

bring together abundant

ice supply with generous

refrigeration capacity in the

convenience of one unit.

COmbO®mOdElS / RF

DIMENSIONS AND SPECIFICATIONS

Please visit www.u-line.com for installation guide.

All specifications are subject to change without notice.

8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX 414.354.7905 U-LINE.COM

CO1175

COMBO®MODELS / RF

Height 34-1/8" (86.6)

Width 23-15/16" (60.8)

Depth 23-1/2" (59.7)

With stainless steel handle 24-15/16" (63.3)

Shipping Weight:

Black model 117 lbs (53 kg)

Stainless model 119 lbs (54 kg)

Running amps 2.5

Maximum start-up amps 18.0

Amps pertain to voltage rating 110/115 volt, 60 Hz

Optional in 220/230 voltage, 50/60 Hz

Capacities:

Defrost technology Manual defrost

Refrigerator volume 4.2 Cu. Ft

Freezer volume N/A

Approximate daily ice production Up to 18 lbs

Ice storage Up to 13 lbs

*Wheninstallingaleft-handhingemodel,allowa125˚doorswingforproperremovaloficebin

OVERALL DIMENSIONS CO1175

Stainless Right-hand U-CO1175S-00

Stainless Left-hand U-CO1175S-01

Black U-CO1175B-00

CO1175S Stainless Model and

CO1175B Black Model

* Add 3/16" to depth for water line clearance

BLACK CO1175

23-1/4" *

34-1/8"

23-15/16"

STAINLESS CO1175

23-1/16"*

*Add 3/16”to Depth For Water Line Clearance

3-1/2"

BLACK CO1175

23-1/4" *

34-1/8"

23-15/16"

STAINLESS CO1175

23-1/16"*

*Add 3/16”to Depth For Water Line Clearance

3-1/2"

24"

Minimum

24-3/16"

34-1/4"

35-1/8"

6-3/4”*

2-1/2”

4 1/6”

3-1/4”*

Legend: E - Electrical W - Water

*Can Vary +1”depending on leg leveler height

*Can Vary Up To +1” Depending on Leg Leveler Height
