Tycon Power Systems TP-BC12-300 Manual de usuario

TP-BC12-300

AC to DC12V UNINTERRUPTED POWER SUPPLY

User Manual

Specifications and Features:

 210W Total Max.

DC power output 12A Max. (@12V)

Charge current 5A Max. (@14V).

 Net weight, only 4.63 lbs/2.1kg

 Dimensions 252*54*190 m/m (W*H*D)

 Over Voltage protection

 Over Current protection

 Quiet Internal Cooling Fan

 Input Voltage: Selectable AC input voltage

-115 Vac at 50/60Hz (5.1A@F.L.)

-230 Vac at 50/60Hz (2.6A@F.L.)

 Super Regulation:

Works with AC input from 90 to 265Vac

 Back-up Power Supply System

 Compatible with Solar and Wind Charge Controllers

PANEL DESCRIPTION

Item Name Description

1 Power Switch Control AC power On or Off,

2 Battery Type Selector

WET Flooded battery

GEL Gel battery

3 LED Indicators

3-1 LOAD Load Indicator Light GREEN when the LOAD is working

3-2 PWR AC Power Indicator

Light YELLOW when the model with AC input and

power switch is on

3-3 BATT Battery Polarity Indicator

Light GREEN when BATTERY polarity connection is

correct, light RED when connection is incorrect

3-4 CHD Floating Indicator Light GREEN when battery is in floating mode.

3-5 CHG Charging Indicator Light YELLOW when battery is in charging mode.

3-6 WET Battery Type Indicator

Green LED light on when battery type selector is set

on WET position

3-7 GEL Battery Type Indicator

Yellow LED light on when battery type selector is set

on GEL position

4 LOAD Output Terminal Block For connection to load

5 BATTERY Output Terminal Block For connection to battery

6 AC Voltage Selector

Select AC input voltage to be 115V (100V~120VAC)

or 230V (220~240VAC) Factory Default 230V

7 AC Socket For separate AC power cord connection

 INSTALLATION:

Before plugging in the model to an AC outlet, please make sure that the proper input

voltage is selected on the rear of the unit. Select 115V for 100/110/120 AC operation

or 230V for 200/220/240 AC operation. The factory default setting is 230V.

Then, connect your device to the LOAD terminal and connect a lead acid battery to

the BATTERY terminal, make sure the polarity of battery is correctly connected,

select WET for wet battery, GEL for GEL or AGM battery.

You may connect a solar panel or wind turbine to the BATTERY terminal at the same

time by connecting a solar panel or wind turbine controller to the battery terminals,

please make sure it is as the same polarity as battery, otherwise, it will damage the

battery and the control circuit.

1 2 3 4

4321

VO+ VO-

SOLAR

DC UPS

BATTERY

Solar Controller

Solar panels

BATTERY

OUTPUT

VO+

Now, plug in the power cord to AC outlet, turn the PWR switch to the “ON” position.

Turn on your device now.

 OPERATION:

The PS works as a DC UPS (Uninterruptible Power Supply) or as a backup power

supply system. When AC power is applied normally, the model offers a regulated

12V DC output at LOAD terminal for devices and a charging current output on

BATTERY terminal for charging a lead acid battery at the same time. Once AC fails,

the battery will replace the AC to power the model immediately without interruption.

The LOAD terminal will remain at 12VDC output for a while till the battery voltage

reduces to lower than 10.7V, the duration time depends on the volume of the battery

and the size of the load. When AC returns, AC takes over the battery to power the

load automatically, and start to charge the battery.

If you connect a solar panel or wind turbine to the BATTERY terminal at the same

time, if AC failed, when the battery voltage lower than 10.7V, the LOAD output will

turn off, but if the output voltage of the solar panel or wind turbine is higher than the

battery voltage, the battery will be charged by the solar panel or wind turbine, when

the battery voltage is back to 12.6V, the LOAD output will recover automatically.

The maximum load of the PS is around 210W, which means 12A maximum DC

output on LOAD and 5A maximum charge current on BATTERY. If the load draws

12A output, the charge current will be limited to around 5A, if there is no load, then

charge current also limited to 5A maximum.

The output voltage on LOAD terminal is regulated at 12.2V±0.2V, with over voltage

protection, over current protection and short circuit protection.

The charge voltage for WET battery is 14.6V, floating voltage is 13.2V.

The charge voltage for GEL battery is 14.2V, floating voltage is 13.5V

When the charger is in charging mode and charge current is more than 2.5A, the

CHG indicator light will be YELLOW, when charge current is lower than 1.8A, the

charger turns to maintenance mode, the CHG light is off and CHD light is GREEN.

All LED indicators will turn off when AC fails except BATT and battery type

indicator (WET or GEL).

If no battery is connected on BATTERY terminal, then there will be no output on the

terminal.

The cooling fan on the model will auto turn on when the inner temperature of unit

over +50C, and will turned off when the temperature less than +45C.

 NOTICE:

1. DON’T CONNECT THE PS TO 24V BATTERY. The PS was designed for 12V

system. Connection to the wrong battery will damage the PS.

2. THE AC SWITCH MUST BE TURNED OFF AT ANY TIME WHEN THE

BATTERY IS CHANGED.

3. Select the correct battery type on the panel, wrong selection will damage the

battery or it will not fully charge the battery. Do not change the battery type

selector when charging.

4. The model has a 6 amp AC input fuse inside of the unit. To replace the fuse you

should remove the old fuse by opening the case and replace it with a new 6 amp

fuse.

5. The cables for battery connection or device to the PS should be 14AWG min.

Please keeping the connect points clean to avoid spark or electrical leakage.

6. When connecting a solar panel or wind turbine controller to the PS, please make

sure of the correct polarity.

7. Product label

 PROTECTION DESCRPTION:

Battery Polarity Reverse Protection: when the battery polarity is reversed, the

BATT indicator light will display RED and the BATTERY and LOAD terminals will

terminate output. Battery reverse will not damage the model if the AC power is off.

The AC switch must be turned off at any time when the battery is changed. If AC is

on and the battery is connected, the PS polarity reverse protection is disabled, and if

the polarity is reversed again, the fuse of the PS will be burnt, sometimes causing a

spark.

Battery Low Voltage protection: When the AC is OFF or has failed, if the battery

voltage is lower than 10.7V±0.2V, the model will turn off the battery and the output

on LOAD. When AC returns or the battery voltage returns to 12.6V±0.2V, then the

output on LOAD will recover automatically.

Load Over Current Protection: the model will automatically shut down if the load

is over 12A. when the load is reduced, the PS will auto recover.

Load Over Voltage Protection: when the LOAD output is over 18V, the PS will turn

off.

Load Short Circuit Protection: output terminal short circuit will not damage the PS,

it will be simply stop the output. When the short circuit status is removed, the LOAD

will recover immediately.
