Tyco Fire Product STAR SIN S3400 SR Manual de usuario

Std. Response - Std. Coverage

Star Galaxy™ SG Easy Guard

K=5.6 Sprinklers With Guards

& Intermediate Level Sprinklers

with Guards

Quick Response - Std. Coverage

Star Galaxy™ SGQR Easy Guard

K=5.6 Sprinklers With Guards

& Intermediate Level Sprinklers

with Guards

GENERAL DESCRIPTION

The Star Galaxy Easy Guard, 5.6 K-Factor, Sprinklers

are standard coverage, glass bulb type spray sprinklers.

The SG (5 mm bulb type) Sprinklers are “standard re-

sponse”, and the SGQR (3 mm bulb type) Sprinkler are

“quick response”. The Easy Guard Sprinklers provides a

unique factory assembled guard or guard & shield, and

its double groove frame design allows installation of the

sprinkler without having to first remove the guard or

guard & shield, saving time and labor cost of field installa-

tion.

Sprinklers with guards may be located in areas that make

them susceptible to being struck, so as to help prevent

damage to the sprinklers.

Intermediate Level Sprinklers (i.e, sprinklers with shields)

are primarily designed for use in rack storage sprinkler

systems, where their thermally sensitive elements must

be shielded from the water spay of higher elevation sprin-

klers which could operate earlier during a fire. Intermedi-

ate Level Sprinklers are also used in applications such as

beneath open gridded catwalks.

WARNINGS

The Star Galaxy SG Easy Guard Sprinklers described

herein must be installed and maintained in compliance

with this document, as well as with the applicable stand-

ards of the National Fire Protection Association, in addi-

tion to the standards of any other authorities having juris-

diction. Failure to do so may impair the integrity of these

devices.

The owner is responsible for maintaining their fire protec-

tion system and devices in proper operating condition.

The installing contractor or sprinkler manufacturer should

be contacted relative to any questions.

† DuPont Registered Trademark

SIN S3400 SR Upright With Guard

SIN S3472 QR Upright With Guard

(58.7 mm)

2-5/16"

1/2" NPT

(73.0 mm)

2-7

(82.6 mm)

3-1/4"

SIN S3401 SR Pendent With Guard

SIN S3471 QR Pendent With Guard

SIN S3500 SR Upright With Guard and Shield

SIN S3572 QR Upright With Guard and Shield

SIN S3501 SR Pendent With Guard and Shield

SIN S3571 QR Pendent With Guard and Shield

NPT

1/2"

(60.3 mm)

2-3/8"

2-7

(73.0 mm)

(82.6 mm)

3-1/4"

"DI

(101.6 mm)

(84.1 mm)

3-5/16"

(58.7 mm)

2-5/16"

1/2" NPT

(60.3 mm)

2-3/8"

(76.2 mm)

"DI

1/2"

NPT

(82.6 mm)

3-1/4"

Customer Service/Sales: Tel: (800) 558-5236 • Fax: (414) 570-5010

Technical Services: Tel: (800) 381-9312 • Fax: (800) 791-5500 3-01

1-4.2.11

TYCO FIRE PRODUCTS

OBSOLETE

OPERATION

The glass bulb contains a fluid which expands when ex-

posed to heat. When the rated temperature is reached,

the fluid expands sufficiently to shatter the glass bulb,

which then allows the sprinkler to activate and flow water.

TECHNICAL DATA

Approvals

UL Listed. FM Approved.

(The approvals apply only to the service conditions indi-

cated in the Design Criteria section.)

Maximum Working Pressure

175 psi (12,1 bar)

Pipe Thread Connection

1/2 inch NPT

Discharge Coefficient

K=5.6GPM/psi

1/2 (80,7 LPM/bar1/2)

Temperature Ratings

Standard Response: 135°F/57°C, 155°F/68°C,

175°F/79°C, 200°F/93°C, 286°F/141°C, or 360°F/182°C

Quick Response: 135°F/57°C, 155°F/68°C, 175°F/79°C,

200°F/93°C, or 286°F/141°C

Finishes

Sprinkler: Natural Brass with Zinc Plated Guards

Physical Characteristics

The Star Galaxy Easy Guard Sprinklers utilize a dezincifi-

cation resistant (DZR) bronze frame, and a 5 mm diame-

ter (standard response) or 3 mm diameter (quick re-

sponse) glass bulb. The two-piece button assembly is

brass and copper. The gasketed spring plate consists of a

beryllium nickel disc spring that is sealed on both its in-

side and outside edges with a Teflon



gasket. The com-

pression screw is bronze, and the deflector is brass.

DESIGN CRITERIA

The Star Galaxy Easy Guard Sprinklers are intended for

fire protection systems designed in accordance with the

standard installation rules recognized by the applicable

Listing or Approval agency (e.g., UL Listing is based on

NFPA 13 requirements).

INSTALLATION

The Star Galaxy Easy Guard Sprinklers must be installed

in accordance with the following instructions:

NOTES

Do not install any bulb type sprinkler if the bulb is

cracked or there is a loss of liquid from the bulb. With the

sprinkler held horizontally, a small air bubble should be

present. The diameter of the air bubble is approximately

1/16 inch (1,6 mm) for the 135°F/57°C to 3/32 inch

(2,4 mm) for the 360°F/182°C temperature ratings.

A leak tight 1/2 inch NPT sprinkler joint should be ob-

tained with a torque of 7 to 14 ft.lbs. (9,5 to 19,0 Nm). A

maximum of 21 ft. lbs. (28,5 Nm) of torque may be used

to install sprinklers with 1/2 NPT connections. Higher lev-

els of torque may distort the sprinkler inlet with conse-

quent leakage or impairment of the sprinkler.

Step 1. With pipe thread sealant applied to the pipe

threads, hand tighten the sprinkler into the sprinkler fitting.

Step 2. Tighten the sprinkler into the sprinkler fitting us-

ing only the W-Type 9 Sprinkler Wrench (Ref. Figure 1).

The W-Type 9 Sprinkler Wrench is to be applied to the

sprinkler wrenching area (groove),which is located adja-

cent to the groove where the guard is mounted to the

sprinkler.

STAR SPRINKLER

Page 2 1-4.2.11

FIGURE 1

W-TYPE 9 (#1849) SPRINKLER WRENCH

WRENCH

RECESS

OBSOLETE

CARE AND MAINTENANCE

The Star Galaxy Easy Guard Sprinklers must be main-

tained and serviced in accordance with the following in-

structions:

NOTE

Before closing a fire protection system main control valve

for maintenance work on the fire protection system which

it controls, permission to shut down the affected fire pro-

tection systems must be obtained from the proper authori-

ties and all personnel who may be affected by this action

must be notified.

Sprinklers which are found to be leaking or exhibiting vis-

ible signs of corrosion must be replaced.

Automatic sprinklers must never be shipped or stored

where their temperature will exceed 100°F/38°C and they

must never be painted, plated, coated, or otherwise al-

tered after leaving the factory. Modified sprinklers must

be replaced. Sprinklers that have been exposed to corro-

sive products of combustion, but have not operated,

should be replaced if they cannot be completely cleaned

by wiping the sprinkler with a cloth or by brushing it with a

soft bristle brush.

Care must be exercised to avoid damage to the sprinklers

— before, during, and after installation. Sprinklers dam-

aged by dropping, striking, wrench twist/slippage or the

like, must be replaced. Also, replace any sprinkler that

has a cracked bulb or that has lost liquid from its bulb

(ref. Installation Section Note).

The owner is responsible for the inspection, testing, and

maintenance of their fire protection system and devices in

compliance with this document, as well as with the appli-

cable standards of the National Fire Protection Associa-

tion (e.g., NFPA 25), in addition to the standards of any

other authorities having jurisdiction. The installing contrac-

tor or sprinkler manufacturer should be contacted relative

to any questions.

It is recommended that automatic sprinkler systems be in-

spected, tested, and maintained by a qualified Inspection

Service.

LIMITED WARRANTY

Products manufactured by Tyco Fire Products are war-

ranted solely to the original Buyer for ten (10) years

against defects in material and workmanship when paid

for and properly installed and maintained under normal

use and service. This warranty will expire ten (10) years

from date of shipment by Tyco Fire Products. No warranty

is given for products or components manufactured by

companies not affiliated by ownership with Tyco Fire Prod-

ucts or for products and components which have been

subject to misuse, improper installation, corrosion, or

which have not been installed, maintained, modified or re-

paired in accordance with applicable Standards of the Na-

tional Fire Protection Association, and/or the standards of

any other Authorities Having Jurisdiction. Materials found

by Tyco Fire Products to be defective shall be either re-

paired or replaced, at Tyco Fire Products’ sole option.

Tyco Fire Products neither assumes, nor authorizes any

person to assume for it, any other obligation in connec-

tion with the sale of products or parts of products. Tyco

Fire Products shall not be responsible for sprinkler sys-

tem design errors or inaccurate or incomplete information

supplied by Buyer or Buyer’s representatives.

IN NO EVENT SHALL TYCO FIRE PRODUCTS BE LI-

ABLE, IN CONTRACT, TORT, STRICT LIABILITY OR UN-

DER ANY OTHER LEGAL THEORY, FOR INCIDENTAL,

INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES,

INCLUDING BUT NOT LIMITED TO LABOR CHARGES,

REGARDLESS OF WHETHER TYCO FIRE PRODUCTS

WAS INFORMED ABOUT THE POSSIBILITY OF SUCH

DAMAGES, AND IN NO EVENT SHALL TYCO FIRE

PRODUCTS’ LIABILITY EXCEED AN AMOUNT EQUAL

TO THE SALES PRICE.

THE FOREGOING WARRANTY IS MADE IN LIEU OF

ANY AND ALL OTHER WARRANTIES EXPRESS OR IM-

PLIED, INCLUDING WARRANTIES OF MERCHANT-

ABILITY AND FITNESS FOR A PARTICULAR PUR-

POSE.

STAR SPRINKLER

1-4.2.11 Page 3

OBSOLETE

ORDERING PROCEDURE

Please Specify:

Standard Response

5.6 K-Factor, SG Easy Guard, Standard Response

Upright Sprinkler with Guard (#3400)

5.6 K-Factor, SG Easy Guard, Standard Response

Pendent Sprinkler with Guard (#3401)

5.6 K-Factor, SG Easy Guard, Standard Response

Upright Sprinkler with Guard and Shield (#3500)

5.6 K-Factor, SG Easy Guard, Standard Response

Pendent Sprinkler with Guard and Shield (#3501)

Quick Response

5.6 K-Factor, SGQR Easy Guard, Quick Response

Upright Sprinkler with Guard (#3472)

5.6 K-Factor, SGQR Easy Guard, Quick Response

Pendent Sprinkler with Guard (#3471)

5.6 K-Factor, SGQR Easy Guard, Quick Response

Upright Sprinkler with Guard and Shield (#3572)

5.6 K-Factor, SGQR Easy Guard, Quick Response

Pendent Sprinkler with Guard and Shield (#3571)

Sprinkler Wrench

W-Type 9 Sprinkler Wrench (#1849)

Refer to Price List for complete listing of Part Numbers

with respect to temperature ratings, sprinkler finishes,

etc.

STAR SPRINKLER

Page 4 1-4.2.11

7071 S. 13th Street • Suite 103

Oak Creek, WI 53154

www.starsprinkler.com

PRINTED IN U.S.A. 3-01

OBSOLETE

Este manual sirve para los siguientes modelos

Otros manuales de Sistema de riego de Tyco Fire Product

Tyco Fire Product

Tyco Fire Product TY-B Series Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL Optima Manual de usuario

Tyco Fire Product

Tyco Fire Product Star Stealth S112 Manual de usuario

Tyco Fire Product

Tyco Fire Product D3 PROTECTOSPRAY Manual de usuario

Tyco Fire Product

Tyco Fire Product Omega HEC-12 RES Manual de usuario

Tyco Fire Product

Tyco Fire Product Gem TFP1 Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL BV-R1 Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL LF Manual de usuario

Tyco Fire Product

Tyco Fire Product Star SuperNova S126 Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL Omega Prohibitor QR Manual de usuario

Tyco Fire Product

Tyco Fire Product Star TFP1 Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL GB-LO 17/32 Manual de usuario

Tyco Fire Product

Tyco Fire Product Gem STAINLESS STEEL QUARTZOID Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL LD Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL Omega HEC-12EC PRO Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL ELO-16 GB FR Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL A Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL ELO-16 GB FR Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL ELOC Manual de usuario

Tyco Fire Product

Tyco Fire Product Star Pulsar S160QR Manual de usuario

Tyco Fire Product

Tyco Fire Product Star Galaxy SG Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL Royal Flush GB4-EC Manual de usuario

Tyco Fire Product

Tyco Fire Product Star Pulsar S160 Manual de usuario

Tyco Fire Product

Tyco Fire Product Gem F978 Manual de usuario

Manuales populares de Sistema de riego de otras marcas

Hunter

Hunter Institutional Series Manual de usuario

Cellfast

Cellfast 52-305 Manual de usuario

Oral Care Technologies

Oral Care Technologies Hydro Floss Manual de usuario

Reliable

Reliable F1-300 Manual de usuario

Netafim

Netafim NETBEAT Manual de usuario

Irrigation-Mart

Irrigation-Mart KIT-GK100-RV-B Manual de usuario

Tyco

Tyco CC3 Manual de usuario

Reliable

Reliable F4FR Manual de usuario

OpenSprinkler

OpenSprinkler OSPi Manual de usuario

EINHELL

EINHELL GE-WW 5537 E Manual de usuario

Valley

Valley Bender160 Manual de usuario

Reliable

Reliable F1FR42 Series Manual de usuario

Reliable

Reliable F1FR-300 Manual de usuario

Toro

Toro 730 Series Guía rápida

Eden

Eden 97063-EDAMZ Manual de usuario

Tyco

Tyco TY-L Series Manual de usuario

Johnson Controls

Johnson Controls tyco ESFR-17 Manual de usuario

Victaulic

Victaulic VicFlex I-VICFLEX.AQC-U Manual de usuario
