About this Manual

This manual provides you with instructions on installing your TYAN

GT24-B5501. This Manual is intended for experienced users and

integrators with hardware knowledge of personal computers.

This manual consists of the following parts:

Chapter1: Provides an introduction to the TYAN GT24-B5501

barebones, standard parts list, describes the external

components, gives a table of key components, and

provides block diagram of the system.

Chapter2: Covers procedures on installing the CPU, memory

modules and hard drives.

Chapter3: Covers removal and replacement procedures for

pre-installed components.

Appendix: List the cable connection and FRU part tables for

reference of system setup, and technical support in

case a problem arises with your system.

For information on the motherboard, please refer to the

attached motherboard user’s manual. You can find the detailed

description about jumper and BIOS settings from the

motherboard manual.

http://www.tyan.com

SAFETY INFORMATION

Before installing and using TYAN GT24-B5501, take note of the following

precautions:

·Read all instructions carefully.

·Do not place the unit on an unstable surface, cart, or stand.

·Do not block the slots and opening on the unit, which are provided for

ventilation.

·Only use the power source indicated on the marking label. If you are not

sure, contact the power company.

·The unit uses a three-wire ground cable, which is equipped with a third

pin to ground the unit and prevent electric shock. Do not defeat the

purpose of this pin. If you outlet does not support this kind of plug,

contact your electrician to replace your obsolete outlet.

·Do not place anything on the power cord. Place the power cord where it

will not be in the way of foot traffic.

·Follow all warnings and cautions in this manual and on the unit case.

·Do not push objects in the ventilation slots as they may touch high

voltage components and result in shock and damage to the

components.

·When replacing parts, ensure that you use parts specified by the

manufacturer.

·When service or repairs have been done, perform routine safety checks

to verify that the system is operating correctly.

·Avoid using the system near water, in direct sunlight, or near a heating

device.

·Cover the unit when not in use.

http://www.tyan.com

Table of Contents

Chapter 1: Overview.........................................................................9

1.1 About the TYAN GT24-B5501 .................................................. 9

1.2 Product Models......................................................................... 9

1.3 Features.................................................................................. 10

1.4 Standard Parts List ................................................................. 14

1.4.1 Box Contents ................................................................... 14

1.4.2 Accessories ..................................................................... 15

1.5 About the Product................................................................... 16

1.5.1 System Front View........................................................... 16

1.5.2 System Rear View ........................................................... 16

1.5.3 LED Definitions ................................................................ 17

1.5.4 Motherboard (S5501) Layout........................................... 19

1.5.5 Jumpers & Connectors .................................................... 20

1.5.6 System Block Diagram .................................................... 21

1.5.7 Internal View .................................................................... 22

Chapter 2: Setting Up..................................................................... 23

2.0.1 Before you Begin ............................................................. 23

2.0.2 Work Area........................................................................ 23

2.0.3 Tools ................................................................................ 23

2.0.4 Precautions...................................................................... 24

2.1 Installing Motherboard Components....................................... 25

2.1.1 Removing the Chassis Cover .......................................... 25

2.1.2 Installing the CPU and Heatsink...................................... 26

2.1.3 Installing the Memory....................................................... 29

2.1.4 Installing Hard Drives....................................................... 32

2.1.5 Installing the PCI-E Cards ............................................... 34

2.2 Rack Mounting........................................................................ 36

2.2.1 Installing the Server in a Rack......................................... 36

http://www.tyan.com

2.2.2 Installing the inner Rails to the Chassis........................... 37

2.2.3 Installing the Outer Rails to the Rack .............................. 38

2.2.4 Rack mounting the Server ............................................... 40

Chapter 3: Replacing Pre-Installed Components ........................ 43

3.1 Introduction ............................................................................. 43

3.2 Disassembly Flowchart........................................................... 43

3.3 Removing the Cover ............................................................... 45

3.4 Replacing Motherboard Components..................................... 45

3.4.1 Replacing Expansion Card .............................................. 45

3.4.2 Disconnecting All Motherboard Cables ........................... 47

3.4.3 Removing the Motherboard ............................................. 49

3.5 Replacing the LED Control Board .......................................... 50

3.5.1 M1008 LED Control Board Features ............................... 52

3.5.2 M1008 LED Control Board Connector Pin Definition ...... 52

3.6 Replacing the System Fan ..................................................... 53

3.7 Replacing the M1232 HDD Backplane ................................... 56

3.7.1 M1232 HDD Backplane Features.................................... 58

3.7.2 M1232 HDD Backplane Connector Pin Definitions ......... 60

Appendix I: Cable Connection Tables ..........................................65

Appendix II: FRU Parts Table ........................................................ 67

Appendix III: Technical Support....................................................69

http://www.tyan.com

Chapter 1: Overview

1.1 About the TYAN GT24-B5501

Congratulations on your purchase of the TYAN®GT24-B5501, a highly

optimized rack-mountable barebone system. GT24-B5501 is designed to

support one Intel® Xeon processor 3400 Series and up to 32GB RDIMM or

16GB UDIMM DDR3-800/1066/1333 memory, providing a rich feature set

and incredible performance. Leveraging advanced technology from Intel®,

GT24-B5501 server system is capable of offering scalable 32 and 64-bit

computing, high bandwidth memory design, and lightning-fast PCI-E bus

implementtation.GT24-B5501 not only empowers your company in

nowadays IT demand but also offers a smooth path for future application

usage.

TYAN®is also proud to deliver GT24-B5501 in flavor while supporting up to

four hot-swap hard drives. GT24-B5501 uses TYAN®’s latest chassis

featuring a robust structure and a solid mechanical enclosure. All of this

provides GT24-B5501 the power and flexibility to meet the needs of

nowadays server application.

1.2 Product Models

Model HDD Bays Power supply

B5501G24V4H Hot-swap, 4 HDDs 400 Watts single

http://www.tyan.com

1.3 Features

TYAN GT24B5501 (B5501G24V4H)

Form Factor 1U Rackmount

Chassis Model GT24

Dimension (D x W x

25.4" x 17.2" x 1.72" (645 x 436 x 43.6mm)

Motherboard S5501GM3NR

Board Dimension EATX, 12"x13" (305x330mm)

System

Gross Weight 16 kg

Buttons (1) RST / (1) NMI / (1) ID / (1) PWR w/ LED

LEDs (1) ID / (1) Warning / (3) LAN / (1) Reserved

Front Panel

I/O Ports (2) USB ports

Type / Q'ty 3.5" Hot-Swap / (4)

External Drive

Bay Supported HDD

Interface

SATA-II 3.0Gb/s

System Cooling

Configuration

FAN (4) 4cm fans

Type EPS1U

Input Range Full-range AC(100-240V)

Frequency 47 - 63 Hertz

Output Watts 400 Watts

Power Supply

Efficiency PFC

Supported CPU

Series

Intel Xeon Processors 3400 Series

Processor

Socket Type / Q'ty LGA 1156/ (1)

Tabla de contenidos

Otros manuales de Servidor de TYAN

TYAN

TYAN GT24-B7066 Guía de inicio rápido

TYAN

TYAN Transport GT26-B4987 Manual de usuario

TYAN

TYAN FT76-B7922 Guía de inicio rápido

TYAN

TYAN FT48A-B7070 Guía de inicio rápido

TYAN

TYAN TS65A-B8036 Guía de inicio rápido

TYAN

TYAN Transport TX46 B4985-E Manual de usuario

TYAN

TYAN Tank GT25 (B5381) Guía de inicio rápido

TYAN

TYAN Transport GX28 B2882 Manual de usuario

TYAN

TYAN TA70-B8237 Guía de inicio rápido

TYAN

TYAN Tank GT20 B5375 Manual de usuario

TYAN

TYAN FT83A-B7129 Guía de inicio rápido

TYAN

TYAN FT48 B7025 Manual de usuario

TYAN

TYAN MicroServer FM65-B5531 Guía de inicio rápido

TYAN

TYAN Tank TA26 B5380 Manual de usuario

TYAN

TYAN FT68-B7910 Guía de inicio rápido

TYAN

TYAN TA77-B7061 Guía de inicio rápido

TYAN

TYAN Transport TA26 B2932 Manual de usuario

TYAN

TYAN Transport GS10 B2094T15 Manual de usuario

TYAN

TYAN YR190-B8238 Guía de inicio rápido

TYAN

TYAN Tank TA26 B5397 Manual de usuario

TYAN

TYAN Transport TA26 B3992 Manual de usuario

TYAN

TYAN TS65-B8036 Guía de inicio rápido

TYAN

TYAN B5102 Manual de usuario

TYAN

TYAN Transport GT20 B5151 Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
