Turtle Beach Disney Infinity 2.0 Manual de usuario

USER GUIDE

Officially Licensed Stereo Gaming Headset

FOR / POUR: Xbox 360 | PS4™ | Wii U™ | PC | Mac | Mobile Gaming

Power Up your sound with the Disney Innity: Marvel Super Heroes Multiplatform Stereo Gaming Headset! Get

massive sound from 50mm speakers to match the huge levels and incredible gameplay along with clear chat and

unmatched comfort for a heroic gaming experience.

DISNEY INFINITY:

MARVEL SUPER HEROES MULTIPLATFORM

STEREO GAMING HEADSET

Go to Table of Contents

Package Contents

For our Knowledgebase and Technical Support please visit

turtlebeach.com/support

A C

Turtle Beach Sticker Decals

Marvel Super Heroes Headset

with In-line Amplifier

In-line Amplifier RCA Splitter Cable

Xbox 360® Chat Cable

E F

CHAT

GAME

BASS BOOST MUTE-MIC-ON

About the Marvel Super Heroes P5

Using the In-Line Amplier P6

Xbox 360 Setup P7

PS4 Setup P12

Wii U Setup P14

PC Setup P15

Mac Setup P16

Mobile Setup P17

Using your Decals P18

Troubleshooting Tips P19

Specications P20

Table of Contents

Go to Table of Contents

Super power your sound with the Disney Innity: Marvel Super Heroes Stereo Gaming Headset! Get massive sound

to match the huge levels and incredible gameplay along with clear chat and unmatched comfort for a heroic

gaming experience.

About the Marvel Super Heroes

Transform Your Headset

Personalize your headset with three included character decals!

Full-Range Audio

Powerful 50mm Neodymium speakers deliver sizzling highs &

thunderous lows.

Be Heard Loud & Clear

Fully adjustable, high-sensitivity microphone on a removable boom.

Quiet & Comfortable

Adjustable, around-the-ear design optimized for noise isolation and

long play sessions.

For All Your Audio Needs

Go beyond games and use the headset for Skype™, enjoying videos,

music and more.

Boost Your Bass*!

Add more rumble to the game audio.

Set the Mix*!

Set the balance of game and chat audio how you’d like.

Stop SHOUTING*!

Hear your own voice in the headset to avoid shouting into the mic.

*Amplier features available for Xbox 360 and PC/Mac.

Go to Table of Contents

Using the In-Line Amplier

Chat Volume Control

Xbox 360 Chat

Connection

Game Volume Control

Bass Boost Control

Mic Mute Switch

Mic Mute Indicator LED

Headset Connection

CHAT

GAME

BASS BOOST MUTE-MIC-ON

Chat Volume Control

Controls the level of incoming chat audio from your Xbox 360.

Game Volume Control

Controls the level of game audio from your Xbox 360. On the PC this will act as a master volume (Game+Chat).

Bass Boost Control

Adjusts the Bass Boost intensity. Turn this up for a more powerful bass response.

Mic Mute Switch

Switches to enable or mute the microphone. The Mic Mute Indicator LED indicates if the Mic is On (Green) or

muted (Red).

Xbox 360 Chat Jack

Connect the included Xbox 360 Chat Cable from this jack to a Xbox 360 Controller to chat. Make sure to follow all

of the instructions in the Xbox 360 Setup section of this guide for best performance.

Go to Table of Contents

Xbox 360 Setup

Xbox 360

Audio

Adapter

For best Xbox chat performance, use with official Microsoft Xbox 360 products.

*Older Xbox 360 models and Xbox 360 Slim models require an Xbox 360 Audio Adapter Cable for

audio output when used with an HDMI connection (Adapter available from turtlebeach.com).

Note: If your HDMI TV has red and white AUDIO OUT RCA jacks, you can use them to feed the sound

from your TV to your Disney Infinity headset. (AUDIO IN jacks will not send sound to your headset.

AUDIO OUT is required).

HDMI

Xbox 360 Audio Adapter*

HDMI Cable

Green

USB

HDMI

USB

CHAT

GAME

BASS BOOST MUTE-MIC-ON

Pink (not used)

The Disney Innity Marvel Super Heroes Headset can be set up a variety of ways to match different Xbox 360

Console Versions and A/V Connections. Check the following pages for the set-up that most closely resembles your

home gaming system. If you still have questions visit turtlebeach.com/support for more information.

Xbox 360® Slim Setup

Go to Table of Contents

Xbox 360 Setup

Audio In

White

Red

Yellow

Red

White

Yellow

Green

USB

CHAT

GAME

BASS BOOST MUTE-MIC-ON

Pink (not used)

Xbox 360® AV Cable

Xbox 360® A/V Setup

Go to Table of Contents

Xbox 360 Setup

HDMI

USB

Green

HDMI Cable

CHAT

GAME

BASS BOOST MUTE-MIC-ON

Pink (not used)

Xbox 360 E HDMI Setup

Go to Table of Contents

Xbox 360 Setup

RCA

USB

Audio In

White

Red

Yellow

USB

Red

White

Yellow Green

CHAT

GAME

BASS BOOST MUTE-MIC-ON

Pink (not used)

Xbox 360® AV Cable

Xbox 360 E RCA Setup
