User Guide
VEHICLE JOURNEY RECORDER
(PT. No. SVC100GPS-LCA / LCA2)
Buddy BX1
CONTENTS
GPS Function .............................................................................. 5
1. Overview ................................................................................ 6
2. Contents ................................................................................ 10
3. Software Installation .............................................................. 11
4. SD Card Insert ....................................................................... 12
SD Card Care ................................................................ 15
5. Product Installation .............................................................. 16
6. LED Guide ............................................................................. 17
7. Camera Functions ................................................................ 18
Camera Operation ......................................................... 19
8. Software User Guide ............................................................ 20
PC Viewer Setting ......................................................... 20
File Loading ................................................................... 21
Playback Screen ........................................................... 23
Playback ....................................................................... 24
Google Maps ................................................................ 26
Thumbnail Function ...................................................... 27
Save JPG and AVI File ................................................. 28
Print Image ................................................................... 29
Reporting ...................................................................... 30
Backup Event/Log ........................................................ 31
Product Information ...................................................... 32
Log File Playback ......................................................... 33
CONTINUED...
GPS Log to KML Converter .............................................. 34
Enhanced Driver Report Function .................................... 35
9. Cloud Upload ........................................................................... 47
10. Setting the Journey Recorder ............................................. 48
Speed Dependant G-Sensor ........................................... 48
UserDenedG-Sensor................................................... 49
Auto Format Feature ....................................................... 50
Alarm Outputs ................................................................. 50
11. Specications ....................................................................... 52
Appendices
Appendix 1 - Recording Time Table ......................................... 53
Appendix 2 - Optional Accessory ............................................ 54
Appendix 3 - Firmware Upgrade .............................................. 57
4
SAFETY ADVICE
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DO NOT REMOVE THE COVER
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
Connect your vehicle’s power cable (Cigarette Jack) to the
product after starting the vehicle to avoid damage.
Install the product where it does not block the driver’s view of
the road. Please refer to the installation section in the user
manual for a full guide on where to install product.
Damages caused by production malfunction, loss of data or
other damages that may occur while using this product is not
the responsibility of the manufacturer. When malfunction
occurs, the product may not save all videos and the sensor
may not recognise shock impacts.
WARNING:
DO NOT EXPOSE PRODUCT TO RAIN OR MOISTURE
5
1. Activate the product in an area without large buildings to improve
GPS reception.
For commercial purposes GPS has an average range error of more than 15
meters and the range error could be more than 100 meters depending on
environmental conditions like buildings and roadside trees etc.
2. The temperature range for optimum operation of the GPS receiver in
your car is -10 ~ 50°C.
3. When using the product for the rst time or after a long period (more
than three days), it may take a little longer to recognise your current
location.
ItmaytakebetweenveandthirtyminutestogetGPSreception.
1) If there is an object at the end of the GPS antenna
2) If your vehicle has metallic elements on the windshield
3) If equipment generating electromagnetic waves that interfere with the GPS
signal are installed in the vehicle e.g. other GPS devices including certain
types of wireless activated alarms, MP3 and CD players and camera
alarms using GPS.
4) If you are using a receiver connected by a cable, electrical interference can
be avoided by simply changing the location of the receiver (antenna).
5) On heavily overcast or cloudy days, if the vehicle is in a covered location
such as under a bridge or raised roadway, in a tunnel, an underground
roadway or parking area, inside a building or surrounded by high-rise
buildings.
6) If GPS signal reception is poor, it may take longer to locate your current
position when the vehicle is moving than when it is stationary.
GPS reception may be impaired under the following circumstances:
GPS RECEPTION
6
The Buddy BX1 is a Vehicle Journey/Accident Recorder with 3 Axis Shock
Sensor & GPS for measuring braking, acceleration, driving style and
recording location. The unit includes a transparent locking case to prevent
tampering with evidence.
This evidence can protect a driver and company from many of the
issues faced on the roads today:
•Cash for Crash / Pre-meditated staged accidents
•False/Exaggerated Whiplash Claims
• ConictingReportsofActualEvents
•Lack of Witnesses
• DrivingOffenceAllegations(SpeedCameras,TrafcSignalViolations
etc...)
Features:
•Continuously records the driver’s view via a 170º high-quality lens
• Continuouslyrecordsbraking/acceleration/collisionG-forces
•Approved for installation in commercial vehicles
• Built-inGPSreceiverensuresthehighestaccuracyforvehicle
location and speed
• SimpleDIYinstallation
• E-mark,EMC,CEandFCCapprovedforextrapieceofmind
• VOSAandDataProtectionActcompliant
1. OVERVIEW
8
FRONT
Buddy BX1
Bracket
Stick adhesive
tape here
Camera Lens
Tamper Resistant
Locking Case
RIGHT LEFT
Key Lock
Protects SD
Card Slot
DC Power Input
Connected with
permanent wiring
Rear
Internal GPS
Antenna
SD Card Format
Button
Record Button
Record LED
Blue LED
Overwrite LED
Red LED
9
Buddy BX1 - Wiring Description
Remote SW+
Remote SW-
Battery -
Alarm Out (G-Sensor & Panic)
Battery+ (Connect to ignition)
For further information, please contact your installer.
If you want to power your camera permanently, please see Appendix 2 on
page 54.
Buddy BX1 with Telematic cable - Wiring Description
Remote SW+
Remote SW-
Battery -
Alarm Out (G-Sensor & Panic)
Battery+ (Connect to ignition)
Alarm Out (SD Card Fault)
10
2. CONTENTS
Buddy BX1 Camera
/Recording Unit including bracket
Wire Splice Clips
Sticker for Windscreen
Mounting (Double-sided Tape x 2)
Power Cable (Cigarette Jack)
Spare Mounting Bracket
USB 2.0 SD Card Reader
Spare Mounting Bracket
32 GB SD Memory Card*
Buddy BX1
Keys for Locking Case
Transparent Locking Case
Telematics Cable
11
3. SOFTWARE INSTALLATION
Software Installation (Windows)
PC SYSTEM REQUIREMENT
RecommendedPCspecicationsforPCViewersoftware
If the PC does not meet the minimum system requirements, the Analysis
Software may not function properly.
OS Windows 2000, Windows XP, Windows Vista,
Windows 7
CPU Pentium4 2.6GHZ or higher
RAM 512MB or higher
Interface SD Memory Card Reader
HDD Free Space Install 20MB or higher
Backup 2GB or higher
Display 1,024 x 768 pixel / High Colour (16 bit) or higher
Software Installation (Windows)
