Trust WB-3100P Manual de usuario

WB-3100P PORTABLE WEBCAM

Product information

A: Snapshot button

B: Lens/Focus ring

C: Activity LED

D: Camera clamp

E: Stand attachment point

F: Desk stand UK

Installation

1 Turn the computer on. Start Windows.

Insert the CD-ROM into the CD-ROM drive.

2 Select ‘Install driver’.

Follow the on-screen instructions.

3 Click ‘Finish’.

4 Position the camera.

Use the stand if the camera is not placed on a notebook.

Connect the camera to a free USB port.

The driver will be installed.

Windows XP: Æ6

Windows 2000, Windows ME: Æ7

Windows 98SE: Æ8

Windows XP Service Pack 2 (A):

Click ‘No not this time’.

Windows XP:

(B) and (C): driver installation.

Go to step 9.

Windows 2000, Windows ME:

The new hardware will be installed automatically. If necessary, click ‘Finish’.

Restart the computer.

Go to step 9.

Windows 98SE:

Follow the on-screen instructions.

Insert the Windows 98SE installation CD-ROM into the CD-ROM drive when requested.

If a message saying ' A file being copied… …to keep this file’ appears, click ‘Yes’ to keep the file.

Go to step 9.

Testing the camera

- Click ‘Start ÆProgramsÆTrust ÆWB-3100P Portable Webcam ÆAMCAP’.

- Click 'Options' and select 'Preview'.

The image will be displayed.

WB-3100P PORTABLE WEBCAM

10 Focussing: use the focus ring.

11 Configuring the camera’s image settings:

Click ‘Amcap – Options – Video Capture filter’

Snapshot function

Two functions: An application which does not use the webcam ÆAMCAP opens automatically.

Application which does use the webcam ÆA photograph is taken.

12 Press the snapshot button.

13 Click ‘File’ and select ‘Save As’ to save the photograph.

Setting the snapshot resolution:

A snapshot can be taken with a maximum resolution of 1280 x 960.

14 Start AMCAP.

Click 'Options’ and select ‘Video Capture Pin’.

15 Select ‘640 x 480’.

Click ‘OK’.

Click 'Options’ and select ‘Video Capture Pin’ (see 1).

Select ‘VGA Snapsize'.

VGA =640 x 480 XGA = 1024 x 768

SVGA =800 x 600 SXGA = 1280 x 960

Click ‘OK’.

USE WITH MSN MESSENGER

If MSN Messenger has not been installed, SELECT ‘Download MSN Messenger’ on the Trust Installer

CD-ROM.

For extra help on MSN Messenger, select ‘MSN Messenger Tour’ on the Trust Installer CD-ROM.

Installation

Windows 98SE: After restarting the computer the ‘Microsoft TV/VIDEO connection’ installation may start.

Follow the on-screen instructions (the Windows 98SE installation CD-ROM is required).

Windows 98SE: No network connection after installing Microsoft TV/VIDEO connection:

- Click ‘Control Panel – Network’ and select ‘Microsoft TV/VIDEO connection’.

- Click ‘Properties.

- Click the ‘Bindings’ tab.

- Unselect ‘TCP/IP -> Microsoft TV/Video Connection’. Restart the computer.

Tips

Make sure there is sufficient light when using the webcam.

Use the focus ring to get the sharpest image.

WB-3100P PORTABLE WEBCAM

Select ‘WB-3100P Portable Webcam’ as the video source before using the device with certain

applications.

The webcam cannot be used in more than one application at the time. UK

Always use the same USB port for the webcam.

Go to www.trust.com/14273 for up-to-date FAQs, drivers and instruction manuals.

Safety instructions

• Do not use this device near water or other liquids.

• Do not use this device in a damp area, such as a bathroom, damp basement or swimming pool.

• This device meets the essential requirements and other relevant conditions of the applicable European

directives. The Declaration of Conformity (DoC) is available at www.trust.com/14273/ce.

• If possible, dispose of the device at a recycling centre. Do not dispose of the device with the household

waste.

Warranty & copyright

• This device has a two-year product warranty which is valid from the date of purchase. Go to

www.trust.com/warranty for more information.

• It is forbidden to reproduce any part of this instruction manual without the permission of Trust International

B.V.
