True GDIM-26 Manual de usuario

............ www.truemfg.com ............

TABLE OF CONTENTS

Safety Information

Safety Precautions 1

Do’s and Don’ts 2

Proper Disposal 3

Connecting Electricity 4

Adapter Plugs 4

Installation / Operation Instructions

Ownership 5

Required Tools 5

Uncrating 5

Locating & Installation of Leg/Castors 6

Leveling Cabinet 7

Wire Gauge Chart 8

Sealing Cabinet to Floor & Electrical Inst. 9

Start-up 10

Defrost Time Clock Operation (Grasslin) 11

Field Troubleshooting 12-13

Maintenance, Care & Cleaning

Cleaning Condenser Coil 14-15

Cabinet Cleaning 16-17

Light Bulb Replacement 17

Warranty (U.S.A. & Canada Only!) 18

INSTALLATION MANUAL FOR GDIM

(GLASS DOOR ICE MERCHANDISERS)

GDIM - GLASS DOOR

ICE MERCHANDISERS

TRUE FOOD SERVICE EQUIPMENT, INC.

2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366

(636)-240-2400 • FAX (636)272-2408 • INT’L FAX (636)272-7546 • (800)325-6152

Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471

CONGRATULATIONS!

You have just purchased the finest commercial

freezer available. You can expect many years of

trouble-free operation.

GDIM-26

GDIM-26NT

GDIM-49

6/20/07-500 SB #897013

*Spanish, German, and French versions included.

............ www.truemfg.com ............

True Food Service Equipment, Inc.

............ www.truemfg.com ............

SAFETY INFORMATION

True Food Service Equipment, Inc.

This freezer must be properly installed and

located in accordance with the Installation

Instructions before it is used.

Do not allow children to climb, stand or hang

on the shelves in the freezer. They could dam-

age the freezer and seriously injure themselves.

Do not touch the cold surfaces in the freezer

compartment when hands are damp or wet.

Skin may stick to these extremely cold surfaces.

Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any

other appliance.

Keep fingers out of the “pinch point” areas;

clearances between the doors and between the

doors and cabinet are necessarily small; be

careful closing doors when children are in the

area.

NOTE: We strongly recommend that any

servicing be preformed by a qualified

individual.

Unplug the freezer before cleaning and making

repairs.

Setting temperature controls to the 0 position

does not remove power to the light circuit,

perimeter heaters, or evaporator fans.

WARNING!

Use this appliance for its intended purpose as described in this Owner Manual.

How to Maintain Your Freezer

to Receive the Most Efficient and

Successful Operation

You have selected one of the finest commercial freezer units made. It is

manufactured under strict quality controls with only the best quality materials

available. Your TRUE freezer when properly maintained will give you many

years of trouble-free service.

SAFETY PRECAUTIONS

When using electrical appliances, basic safety precautions should be followed, including the following:

............ www.truemfg.com ............

True Food Service Equipment, Inc.

SAFETY INFORMATION

............ www.truemfg.com ............

True Food Service Equipment, Inc.

SAFETY INFORMATION

PROPER DISPOSAL OF THE REFRIGERATOR

DANGER!

RISK OF CHILD ENTRAPMENT

USE OF EXTENSION CORDS

NEVER USE AN EXTENSION CORD! TRUE will not warranty any freezer that has been

connected to an extension cord.

Child entrapment and suffocation are not problems

of the past. Junked or abandoned refrigerators are

still dangerous… even if they will sit for “just a few

days.” If you are getting rid of your old refrigerator,

please follow the instructions below to help

prevent accidents.

Before You Throw Away Your Old Refrigerator

or Freezer:

Take off the doors.

Leave the shelves in place so that children may

not easily climb inside.

Refrigerant Disposal

Your old refrigerator may have a cooling system

that uses “Ozone Depleting ” chemicals. If you are

throwing away your old refrigerator, make sure the

refrigerant is removed for proper disposal by a

qualified service technician. If you intentionally

release any refrigerants you can be subject to

fines and imprisonment under provisions of the

environmental regulations.

............ www.truemfg.com ............

True Food Service Equipment, Inc.

The power cord of this appliance is equipped with

a 3-prong (grounding) plug which mates with a

standard 3-prong (grounding) wall outlet to

minimize the possibility of electric shock hazard

from this appliance.

Have the wall outlet and circuit checked by a

qualified electrician to make sure the outlet is

properly grounded.

If the outlet is a standard 2-prong outlet, it is your

personal responsibility and obligation to have it

replaced with the properly grounded 3-prong wall

outlet.

The freezer should always be plugged into it’s own

individual electrical circuit, which has a voltage

rating that matches the rating plate.

This provides the best performance and also

prevents overloading building wiring circuits which

could cause a fire hazard from overheated wires.

Never unplug your freezer by pulling on the power

cord. Always grip plug firmly and pull straight out

from the outlet.

Repair or replace immediately all power cords that

have become frayed or otherwise damaged. Do not

use a cord that shows cracks or abrasion damage

along its length or at either end.

When removing the freezer away from the wall, be

careful not to roll over or damage the power cord.

HOW TO CONNECT ELECTRICITY

Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.

For personal safety, this appliance must be properly grounded.

WARNING!

The incoming power source to the cabinet

including any adapters used must have the adequate

power available and must be properly grounded.

USE OF ADAPTER PLUGS

NEVER USE AN ADAPTER PLUG! Because of potential safety hazards under certain conditions, we

strongly recommend against the use of an adapter plug.

SAFETY INFORMATION

North America Use Only!

NEMA plugs

TRUE uses these types of plugs.

If you do not have the right outlet

have a certified electrician install

the correct power source.

............ www.truemfg.com ............

True Food Service Equipment, Inc.

INSTALLATION / OPERATION INSTRUCTIONS

To insure that your unit works properly from the

first day, it must be installed properly. We highly

recommend a trained refrigeration mechanic and

electrician install your True equipment. The cost

of a professional installation is money well spent.

Before you start to install your True unit, carefully

inspect it for freight damage. If damage is discov-

ered, immediately file a claim with the delivery

freight carrier.

True is not responsible for damage incurred

during shipment.

OWNERSHIP

Adjustable Wrench

Phillips Head Screwdriver

Level

REQUIRED TOOLS

Step 1

The following procedure is recommended for

uncrating the unit:

A. Remove the outer packaging, (cardboard and

bubbles or styrofoam corners and clear plastic).

Inspect for concealed damage.Again, immediate-

ly file a claim with the freight carrier if there is

damage.

B. Move your unit as close to the final location as

possible before removing the wooden skid.

C. Remove door bracket on swinging glass door

models (see image 1-2).

Note: Keys for coolers with door locks are located

in warranty packets.

UNCRATING

INSTALLATION / OPERATION INSTRUCTIONS

REMOTE UNITS (This section applies to

remotes only!)

• Remote cabinets must be ordered as remote.

We do not recommend converting for a standard

self contained to remote system.

• All remote cabinets must be hard wired.

• No castors available.

• All remote cabinets come standard using 404A

refrigerant.

• All remote units come standard with expansion

valve, liquid line solenoid, heated condensate

pan, and defrost timer when applicable.

• Contact True Technical Service for BTU

requirements.

• No wiring necessary between cabinet and

condensing unit.

• All remote condensing units purchased from

True are 208/230 volts single phase.

If you have any questions regarding this

section, please call True at 1-(800)-325-6152.

............ www.truemfg.com ............

True Food Service Equipment, Inc.

INSTALLATION / OPERATION INSTRUCTIONS

Step 2

A. Carefully lay the unit on its back to remove skid.

Place packing material behind cabinet as a cushion.

When lifting unit remember to

leave the cabinet upright for 24 hours before

plugging into power source.

B. Remove skid by unscrewing all base rail anchor

brackets. Place skid to the side.

C. Carefully upright cabinet.

LOCATING

Rail End

Lower Rail

Assembly

Snug Fit

Here

Leveling Shim

CastorLeg

Bearing

Race

Lower Rail Assembly

Snug Fit

Here

Rail End

Removing

skid from

bottom of

cabinet.

Thread castor into the under-

side of cabinet frame rail.

Thread leg into cabinet

bottom frame rail.

The end of the leg is

adjustable to easy leveling.

Use the tool provided to

tighten the castor into place.

For leveling, insert the shim

between the castor and frame rail.

1234

INSTALLATION OF LEGS AND CASTORS

Important Safeguard for installation of leg/castor (Images 1-5 demonstrate procedure)

Step 3

Securing Castors and Legs

To obtain maximum strength and stability of the

unit, it is important that you make sure each castor

is secure. Legs are hand-tightened securely against

the lower rail assembly. The bearing race on the

castor of the top edge of the leg must make firm

contact with the rail.

Unit leveling

Four leveling shims have been provided for level-

ing castored units positioned on uneven floors.

Shims must be positioned between rail end and

bearing race.

A. Turn the bearing race counter-clockwise until

the cabinet is level. Level front to back and side to

side. (diagonally)

B. Install the desired number of shims, making sure

the slot of the shim is in contact with the threaded

stem of the castor.

C. If more than one shim is used, turn the slot at a

90° angle so they are not in line.

D. Turn the bearing race clockwise to tighten and

secure the castor by tightening the anchoring bolt

with a 3/4 inch open-end wrench or the tool

provided.

CAUTION

To avoid damage to lower rail assembly,

slowly raise unit to upright position.

Note: Open holes located on the cross members of the

frame rail should be plugged before unit is in use.

............ www.truemfg.com ............

True Food Service Equipment, Inc.

INSTALLATION / OPERATION INSTRUCTIONS

NEPCO/CENTRALAB

1227-5

REMOVECOVERMAKEPOWER CONNECTION

Step 4

A. Set unit in its final location. Be sure there is ade-

quate ventilation in your room. Under extreme heat

conditions, (100°F+, 38°C+), you may want to install

an exhaust fan.

Warning

Warranty is void if ventilation is insufficient.

B. Proper leveling of your True cooler is critical to

operating success (for non-mobile models). Effective

condensate removal and door operation will be

effected by leveling.

C. The cooler should be leveled front to back and

side to side with a level.

D. Ensure that the drain hose or hoses are posi-

tioned in the pan.

E. Free plug and cord from inside the lower rear of

the cooler (do not plug in).

F. The unit should be placed close enough to the

electrical supply so that extension cords are never

used.

Warning

Compressor warranties are void if the unit is more

than 7 ft. (2.1m) from plug-in connection.

LEVELING

............ www.truemfg.com ............

True Food Service Equipment, Inc.

CONDUCTORS AND CIRCUITS

INSTALLATION / OPERATION INSTRUCTIONS

Wire Gauge for 2% Voltage Drop in Supply Circuits

115 Volt Distance In Feet To Center of Load

Amps 20 30 40 50 60 70 80 90 100 120 140 160

2 141414141414141414141414

3 141414141414141414141412

4 141414141414141414121212

5 141414141414141212121010

6 141414141414121212101010

7 1414141414121212101010 8

8 14141414121212101010 8 8

9 141414121212101010 8 8 8

10 14 14 14 12 12 10 10 10 10 8 8 8

12 14 14 12 12 10 10 10 8 8 8 8 6

14 14 14 12 10 10 10 8 8 8 6 6 6

16 14 12 12 10 10 8 8 8 8 6 6 6

18 14 12 10 10 8 8 8 8 8 8 8 5

20 14 12 10 10 8 8 8 6 6 6 5 5

25 12 10 10 8 8 6 6 6 6 5 4 4

30 12 10 8 8 6 6 6 6 5 4 4 3

35 10 10 8 6 6 6 5 5 4 4 3 2

40 1088665544322

45 1086665443321

50 1086654433211

Wire Gauge for 2% Voltage Drop in Supply Circuits

230 Volts Distance In Feet To Center of Load

Amps 20 30 40 50 60 70 80 90 100 120 140 160

5 141414141414141414141414

6 141414141414141414141412

7 141414141414141414141212

8 141414141414141414121212

9 141414141414141412121210

10 14 14 14 14 14 14 14 12 12 12 10 10

12 14 14 14 14 14 14 12 12 12 10 10 10

14 14 14 14 14 14 12 12 12 10 10 10 8

16 14 14 14 14 12 12 12 10 10 10 8 8

18 14 14 14 12 12 12 10 10 10 8 8 8

20 14 14 14 12 10 10 10 10 10 8 8 8

25 14 14 12 12 10 10 10 10 8 8 6 6

30 14 12 12 10 10 10 8 8 8 6 6 6

35 14 12 10 10 10 8 8 8 8 6 6 5

40 14 12 10 10 8 8 8 6 6 6 5 5

50 12 10 10 8 6 6 6 6 6 5 4 4

60 12 10 8 6 6 6 6 6 5 4 4 3

70 10 10 8 6 6 6 5 5 4 4 2 2

80 1088665544322

90 1086655443311

100 1086654433211

Otros manuales para GDIM-26

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Comerciante de True

True

True GDM-23W-RF Manual de usuario

True

True GDM-23FC Manual de usuario

True

True GEM-23FC Manual de usuario

True

True GDM-47FC Manual de usuario

True

True GDM-23W Manual de usuario

True

True GDM-69FC Manual de usuario

True

True GDM-49RL Manual de usuario

True

True GDM-49FC Manual de usuario

True

True GDM-3 Manual de usuario

True

True G4SM-23RL Manual de usuario

True

True GDM-23RF Manual de usuario

True

True G4SM-23-PT Manual de usuario

True

True GDM-26 Manual de usuario

True

True GDM-49 Manual de usuario

True

True GEM-12FC Manual de usuario

True

True GDM-23 Manual de usuario

True

True GDM-7 Manual de usuario

True

True GDM-23FC-RF Manual de usuario

True

True GDM-7-S-LD Manual de usuario

True

True GEM-12 Manual de usuario

True

True TRM4M-BLK-WHT1-BLKLLLL-NY-4 Manual de usuario

True

True G4SM-23RL-SI Manual de usuario

True

True GDM-49DT Manual de usuario

True

True GDM-23 Manual de usuario

Manuales populares de Comerciante de otras marcas

FRIGOGLASS

FRIGOGLASS Flex 20 HC Manual de usuario

Hussmann

Hussmann ENTYCE TY3 Manual de usuario

EPTA

EPTA COSTAN RHINO MULTI Manual de usuario

Hussmann

Hussmann CRFD Instrucciones de funcionamiento

CASCO

CASCO Nano Cube Manual de usuario

Hussmann

Hussmann WDCHI Manual de usuario

Structural Concepts

Structural Concepts Oasis Mobile Series Instrucciones de instalación

Hussmann

Hussmann Q2-SS Instrucciones de funcionamiento originales

Haussmann

Haussmann RL Manual de usuario

Howard McCray

Howard McCray R-CDS32E-4 Manual de usuario

Hussmann

Hussmann microSC SHM-A Series Manual de usuario

Hussmann

Hussmann APT0500 Manual de usuario

EPTA

EPTA iarp Cool Emotions Delight Lite Manual de usuario

VALERA

VALERA BC 85 Manual de usuario

HL Display

HL Display 3eBin Manual de usuario

Hussmann

Hussmann Q1-SS Manual de instrucciones

Hussmann

Hussmann impact Excel C2X-XLEP Manual de instrucciones

Hussmann

Hussmann C2NX-XE Manual de instrucciones
