TRIUMPH BOARD MULTI Touch Series Manual de usuario
User Manual v 6.0
May 2013
MULTI Touch Series
TRIUMPH BOARD 78” MULTI Touch
TRIUMPH BOARD 89” MULTI Touch
TRIUMPH BOARD 96” MULTI Touch
TRIUMPH BOARD a.s. , Neklanova 122/15, 128 00 Praha 2, Czech Republic, European Union, www.triumphboard.com
TRIUMPH BOARD a.s. Page 2 of 28
DECLARATION OF CONFORMITY
We TRIUMPH BOARD a.s., Neklanova 122/15, 128 00 Praha 2
Declare under sole responsibility that the product:
TRIUMPH BOARD MULTI Touch Series
Model: 78” MULTI Touch / 89” MULTI Touch / 96” MULTI Touch
EAN: 8592580101458, 8592580091773 / 8592580101465, 8592580091407 /
8592580101472, 8592580091667
Is in conformity of essential requirements of EU/CZ directives:
Czech Standards
EU Standards
ČSN ETSI EN 301 489-1 V1.8.1:2008
ČSN ETSI EN 301 489-3 V1.4.1:2003
ČSN ETSI EN 300 440-1 V1.4.1:2009
ČSN ETSI EN 300 440-2 V1.2.1:2009
ČSN EN 50371:2002
ČSN EN 60950-1 ed. 2:2006
EN 55022: 2010
EN 55024: 2010
EN 61000-3-2:2006 +A1: 2009 +A2: 2009
EN 61000-3-3:2008
and following Governmental regulations, as amended:
Government Regulation No. 17/2003 Coll. as amended (2006/95/EC including amendments)
Government Regulation No. 616/2006 Coll. as amended (including amendments 2004/108/EC)
The last two digits of the year in which the CE marking was affixed: 13
Place of Issue: Praha
Datum of issue: 9st January 2013
Ing. Ondřej Kryšpín, Chairman of the Board of Directors
Note: Translation from original CE
TRIUMPH BOARD a.s. Page 3 of 28
Content
1) Safety Information.......................................................................................................................4
2) Product Description.....................................................................................................................8
3) Technical Specifications..............................................................................................................9
4) Package contents......................................................................................................................12
5) Wall mount Installation..............................................................................................................13
6) Software Installation..................................................................................................................17
7) HW Installation..........................................................................................................................18
8) MULTI Touch Driver Configuration............................................................................................21
a) Wireless Setting..................................................................................................................21
d) Settings...............................................................................................................................23
9) Hotkey Setting.........................................................................................................................24
a) TB Comenius MULTI Touch v5 ...........................................................................................24
b) RM Easiteach .....................................................................................................................25
10) MS OfficeAnnotations (only for Vista & Windows-7,8 )..........................................................27
11) Repair Service and Contacts..................................................................................................28
TRIUMPH BOARD a.s. Page 4 of 28
1) Safety Information
Please read, understand and follow the information contained in this User Guide before
installation and use this product.
Safety Information
This product was designed, and intended for use indoor via a USB cable or wireless USB receiver connected to
a desktop or laptop computer. Use this product in an outdoor and/or wet environment could damage this product
and create a potentially unsafe operating condition
Meaning of Signal Words
Indicates a potential hazard that could result in serious injury or death and/or
property damage.
Indicates hazards that could result in minor or moderate injury and/or property
damage.
oPlease read, understand and follow all safety information contained in this User Manual before
installation and use this product.
oDo not use this product in an outdoor and/or wet environment.
oDo not use this product near water. Electric shock will result.
oThis product is not intended for use by unsupervised children. Always provide proper adult
supervision when using this product around children.
oAt least two qualified service technicians should perform the installation and removal procedure.
Failure to do so could result in serious personal injury and/or damage from dropping this product.
oBefore installation, take the wall material and wall strength into consideration.
oAlways place this product on a stable and level surface.
oUse only the designated wall mount and mobile stand hardware.
oFollow all installation instructions carefully.
oMake sure the mounting screws are properly sized to handle the weight of this product.
oMake sure the mounting hardware is securely anchored to a solid structure.
oOnly plug the power cord, power plug or power adaptor into an AC power outlet with the proper and
TRIUMPH BOARD a.s. Page 5 of 28
Safety Information (Continue….)
indicated power supply voltage and is effectively grounded (earthed) through the normal wiring. If
this product is used at a power supply voltage other than the one indicated, it would fail and may
result in fire or electric shock.
oIf the power cord or power plug or power adaptor cannot be plugged into the AC power outlet,
contact a licenses electrician to replace the AC power outlet with a properly grounded (earthed) one.
oWhen you operate this product, the AC power outlet should be near this product and easily
accessible.
oThe fact that this product operates satisfactorily does not imply that the AC power outlet is grounded
(earthed) and that the installation is completely safe. For your safety, if in any doubt about the
effective grounding (earthling) of the AC power point, consult a qualified electrician.
oDo not defeat the purpose of the grounding (Earthing) plug (for example, do not use a conversion
plug).
oAlways plug the power cord, power plug or power adaptor securely and firmly into an AC power
outlet. Otherwise, overheating will occur, possibly resulting in electric shock or fire.
oDo not pull, bend, rest objects on, or chafe the power cord or power plug or power adaptor. Damage
to the power cord or power plug or power adaptor can cause fire or electric shock.
oDo not attempt to repair the power cord, power plug or power adaptor. If the power cord or power
plug or power adaptor is damaged or frayed, contact an authorized service representative for a
replacement.
oPeriodically clean the power cord or power plug or power adaptor to ensure the connection is free of
dust. In a damp environment, a contaminated connector can draw a significant amount of current
that can generate heat and eventually cause fire if left unattended over an extended period of time.
oNever move the power cord or power plug or power adaptor with wet hands. Electric shock will
result.
oStop operation immediately if your product emits smoke, excessive heat, abnormal smell or unusual
noise. These conditions can cause fire or electronic shock. Immediately turn your product off and
unplug the power cord or power plug or power adaptor, and contact an authorized service
representative for service.
oWhen disconnecting this product, hold the power plug or the power adaptor instead of the power
cord. Pulling on a power cord forcibly can damage it and cause fire or electric shock.
oTo prevent fire or shock hazard, do not expose this product to rain or any type of moisture.
oIf metal objects or a liquid get into this product, turn this product off and unplug this product
immediately. Contact an authorized service representative for service. Operating the contaminated
product can cause fire or electronic shock.
oNever open or remove unit covers that are screwed with screws. A high-voltage component can
cause electric shock.
oDo not alter this product or modify any parts. Alternation or modification can cause fire or electronic
shock
oBefore cleaning this product, unplug the power cord or power plug or power adaptor as electric
shock may result.
TRIUMPH BOARD a.s. Page 6 of 28
Safety Information (Continue….)
oDo not open or alter the casing of this product. Electric shock or injury may result.
oBe careful about the location of the power cord, power plug or power adaptor to avoid that it trips
someone or causes this product to fall, etc. It may cause injury or product failure.
oDo not leave this product or any of its accessories on the floor to avoid someone breaking it when
stepping on it or injury by tripping on it.
oUse only the included power cord or power plug or power adaptor. If other power cord or power plug or
power adaptor is used, fire or electric shock might result.
oDo not operate this product in a location with high temperature or high humidity. This product is suitable
to work under: Temperature: 10℃to 40℃; Humidity: 10% to 80%; NO condensation.
oUnplug the power cord, power plug or power adaptor from theAC power outlet when:
- The power cord or power supply plug is damaged.
- A liquid is spilled onto this product.
- This product is exposed to rain or water.
- This product becomes malfunctions and/or need repairing.
- This product falls or after its cabinet is damaged.
This product must be disposed in accordance with the relevant federal, state, and local laws and
regulations.
Do not install this product other than by a qualified service personnel.
Avoid fire and heat source above 100℃.
When this product is not used over an extended period of time, switch it off and unplug the power plug
or power adaptor. If it is unused and is left connected to a power source for a long period, degraded
insulation may cause electronic shock, current leakage or fire.
Do not position this product in a location where it is unstable.
Do not place this product in a hot humid or dusty environment. Prolonged exposure to these adverse
conditions may cause fire or electric shock.
When moving this product, be sure to unplug the power cord, plug or power adaptor from the AC power
outlet. If this product is moved with the power cord or plug or power attached, it can cause damage to
the power cord, plug or power adaptor which could result in fire or electric shock.
After installing or moving this product, lock the casters when it is hanging on a mobile stand.
If this product falls down or gets damaged, turn this product off and unplug the power cord or power
plug or power adaptor. Otherwise, it may cause fire or electric shock.
Do not put drinks, other liquids or heavy items on the tray or screen. Accidental spillage of liquid into
this product may cause severe damage. If this occurs, turn this product off, unplug the power cord or
power plug or power adaptor and contact an authorized service representative for service.
TRIUMPH BOARD a.s. Page 7 of 28
Do not lean against this product even when this product is mounted on the wall.
Do not install this product where it may be exposed to direct sunlight, near heating equipment, or near
air-conditioning vents.
Do not install this product in strong sunlight or strong lighting.
Do not install this product in locations where the temperature may change suddenly.
Do not allow writing to remain on the screen for an extended period of time as it will become harder to
erase.
Do not erase with an overly dirty eraser.
Use commercially available white board cleaner for hard-to-erase stains.
Use only designated markers and erasers. Use of accessories other than those authorized (such as oil-
based markers) may damage the screen or result in hard-to-erase markings.
Fasten the screws tightly to avoid that the stand or this product falls which may cause injury or
damage.
Before installation, take the wall material and wall strength into consideration. For details, please
consult your dealer.
TRIUMPH BOARD a.s. Page 8 of 28
2) Product Description
TRIUMPH BOARD MULTI Touch is an interactive whiteboard that allows four users to write, draw, move
objects or two users to resize and rotate two objects with two fingers per object simultaneously. Truly multi-
touch, requiring no separate multiuser mode settings. Users can write, draw and move objects with a finger,
stylus or even a pointer.
TRIUMPH BOARD MULTI Touch connects to a computer through a fast USB 2.0 interface or optionally with
wireless radio technology with 2,4 GHz, just plug-n-play, makes the lecture more interactively and enhances the
efficiency of the class
TRIUMPH BOARD MULTI Touch supports Linux, Mac, all Microsoft Windows & multiuser writing and common
multi touch gestures currently recognized in Microsoft Win-7, 8. Use simple intuitive finger or hand gestures to
toss, rotate or zoom in/out on objects
TRIUMPH BOARD MULTI Touch is based on IR Cell LED Optical technology which uses a combination of IR
LEDs and photo transistors that are aligned in pairs around the active surface. These pairs of LEDs and photo
transistors cast a grid over the surface. When the surface is touched, the beam of infrared light between the
LEDs and the photo transistors is interrupted at the point of touch. This position is converted into an ‘X’ and a ‘Y’
coordinate which the computer then converts into a mouse position.
TRIUMPH BOARD MULTI Touch interactive whiteboards are used in classrooms at all levels of education, in
corporate board rooms and training rooms, in professional sports coaching, etc. Interactive whiteboards replace
traditional whiteboards, flipcharts and other traditional systems
For proper functioning of 4 users simultaneous writing on the whiteboard it is recommended to write at
least 10 to 15 cm apart from each other and at different heights.
MULTI Touch 78” MULTI Touch 89” MULTI Touch 96”
TRIUMPH BOARD a.s. Page 9 of 28
3) Technical Specifications
TRIUMPH BOARD 78” MULTI Touch
EAN: 8592580101458, 8592580091773
Active screen area size: 1576 x 1168, 78” diagonal
Aspect ratio: 4:3
Technology: IR (Infrared) cell LED optical
Resolution: 12800x9600
Projection screen area: 1557 x1168 mm
Interface Type: USB 2.0 / 2.4 GHz RF Wireless (optional)
Cable Length: 6 m
Working Environment -20 to 40°C
Response time: 6ms
Power supply: USB DC 5V from PC (optional wireless PC receiver and USB adaptor
/220V)
Power consumption: < 260 mA (wireless PC receiver 20mA)
Temperature Range: -20 to 40°C, storage temperature - 40 to 70°C
Humidity Operating 30-90% non-condensing, storage 0-95%, noncondensing
Platform: Windows 8, 7, XP and Vista, Linux, MAC
Board size without packing: 1693 x1284x35 mm (width x height x depth without plastic pen tray)
Board size with packing: 1869 x 1395 x 67 mm (width x height x depth without plastic pen tray)
Optional: Speakers, Active Pen Tray, various Stands and Lift Systems
TRIUMPH BOARD a.s. Page 10 of 28
TRIUMPH BOARD 89” MULTI Touch
EAN: 8592580101465, 8592580091407
Active screen area size: 1944 x 1127, 89” diagonal
Aspect ratio: 16:10 (with hotkeys), 16:9
Technology: IR (Infrared) cell LED optical
Resolution: 12800x9600
Projection screen area: 1803 x 1127 mm (with the hotkeys)
Interface Type USB 2.0 / 2.4 GHz RF Wireless (optional)
Cable Length 6 m
Working Environment -20 to 40°C
Response time: 6ms
Power supply: USB DC 5V from PC (optional wireless PC receiver and USB adaptor
/220V)
Power consumption: < 280 mA (wireless PC receiver 20mA)
Temperature Range: -20 to 40°C, storage temperature - 40 to 70°C
Humidity Operating: 30-90% non-condensing, storage 0-95%, non-condensing
Platform: Windows 8, 7, XP and Vista, Linux, MAC
Board size without packing: 2060 x 1244 x 35 mm (width x height x depth without plastic pen tray)
Board size with packing: 2236 x 1355 x 67 mm (width x height x depth without plastic pen tray)
Board weight (net): 31,5 kg
Weight incl. packing: 39,5 kg
Optional: Speakers, Active Pen Tray, various Stands and Lift Systems
Otros manuales para MULTI Touch Series
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Panel táctil de TRIUMPH BOARD
Manuales populares de Panel táctil de otras marcas
IBASE Technology
IBASE Technology ASTUT-152-RE1S Manual de usuario
YASKAWA
YASKAWA TP 610C Manual de usuario
B&R
B&R Power Panel C Series Manual de usuario
Beijer Electronics
Beijer Electronics X2 control Manual de usuario
AXIOMTEK
AXIOMTEK GOT321W-521 Manual de usuario
TRIDONIC.ATCO
TRIDONIC.ATCO x-touchBOX Manual de usuario
