Triumph Adler DC 2080 Manual

Instruction Handbook

Basic

DC 2060 | 2080

Digital Multifunctional

System

ThisOperation Guide is for models DC 2060 and DC 2080. In this guide, DC 2060 refers to the

60 cpm (copies per minute) model and DC 2080 to the 80 cpm model.

NOTE: This Operation Guide contains information that corresponds to using both the inch and

metric versions of these copiers.

The inch versions of these copiers are shown in the screens in this guide. If you are using the

metric version, use the messages provided for the inch version as reference only. In the body

text, only the inch messages are given if these versions differ only in capitalization. When there

is even a slight difference in the message, we have listed the information for the inch version

followed, in brackets, by the corresponding information for the metric version.

Take Advantage of Advanced Functions

For information on basic copying, refer to Chapter 3 of the Operation Guide.

Selecting Image Quality

Enjoy crisp, high-quality copies, even

of photographs.

Adjusting Exposure

Freely adjustable copy exposure

level.

Auto Zoom

Reduce or enlarge original images to

fit your selected paper size.

Manual Zoom

Reduce or enlarge original images by

25 to 400 % (25-200 % with the

document processor).

Preset Zoom

One-touch selection of

magnifications.

XY Zoom

Select vertical and horizontal

magnification individually.

Duplex Mode

Create two-sided copies

automatically from any kind of

original.

Split Mode

Copy double-sided or two-page

originals onto separate sheets

automatically.

Sort Mode

Make separate sets in the quantity of

your choice.

11 × 17": 129 %

51/2 ×81/2": 64 %

A3: 141 %

A5: 70 %

81/2 × 11"

25 %

400 %

70%

75%

90%

106%

127%

141%

200%

50%

64%

77%

78%

121%

129%

154%

200%

Height

Width

Read more about these sophisticated functions in Chapter 1 of the Advanced Operation Guide.

Auto Paper Selection

Automatic selection of paper to

match the original.

Offset Mode

Handy option to stack sets in

alternating orientations.

Combine Mode

Combine two or four originals on a

single page.

Margin Mode

Set up blank margin or gutter space

for your binding needs.

Centering Originals

Customize output by centering the

image on the page.

Border Erase

Eliminate unnecessary borders on

the original for cleaner output.

Page Numbering

Print sequential page numbers on the

copies.

Cover Mode

Use a distinctive front and/or back

cover.

Form Overlay

Copy images from separate originals

together onto one sheet.

Booklet from Sheets

Create booklets from separate

originals.

Booklets from Booklets

Reproduce booklets just as they are.

Memo Mode

Add space for notes next to copied

images.

-5-

-4-

-3-

-2-

-1-

iii

Batch Scanning

Copy high-volume originals in a

single copy job.

Proof Mode

Copy a test sheet before a

high-volume job.

Repeat Copy

Produce more copies as needed after

making the initial copies.

Backing Sheets for Transparencies

Use paper as backing sheets when

printing transparencies for projectors.

Auto Rotation

Automatically match the orientation of

originals.

EcoPrint (Economy Printing) Mode

Use toner more efficiently as

necessary.

Inverted Copying

Invert both black and white and color

images.

Mirror Image

Create mirror images of originals.

Auto Selection Mode

Easily handle originals of different

sizes.

Multi-Page Forms

Great for bound originals made up of

several sheets.

Programmed Copying

Store commonly used settings.

200

100

Read more about these handy document/output management functions in Chapter 2 of the Advanced Operation

Guide.

Programming Multi-Part Jobs

Simply specify your series of special

copying needs-such as cover pages,

internal cover pages...

and zooming or border erase for

particular pages...

load the originals, and voila!

Automated copying of your detailed

jobs.

Form Box

Add and manage graphics for

compositing.

Shared Data Box

Easily store commonly used

documents...

to produce them later as needed

without the original.

Synergy Print Box

Just add common documents... to make them instantly available later

in combination with other copying

jobs.

Output Management

Control and modify the copying order

of originals

Features for Easier Copying

Read about our full line of useful Optional Equipment on page 4-1.

Job Accounting Mode: Refer to

Chapter 3 of the Advanced Operation

Guide.

Use department codes to manage

total copy volume.

Weekly Timer: Refer to Chapter 3 of

the Advanced Operation Guide.

Auto Power on/off.

Language Setting: Refer to

Selecting the Language on

page 2-20.

Choose the correct message display

language.

Side Feeder Document Finisher (When equipped with a multi-job tray

and folding unit)

Key Counter Printer Kit Scanner Kit

Security Kit

A B C

OFF ON

DeutschEnglish

vii

Legal and Safety Information

Please read this information before using your copier. This chapter provides information on the

following topics:

• Legal Information...viii

• Energy Star Program...ix

• Safety Conventions in This Guide...x

• Caution Labels...xii

• Installation Precautions...xiii

• Precautions for Use...xiv

Energy Star Program

We have determined as a participating company in the International Energy Star Program that

this product is compliant with the standards laid out in the International Energy Star Program.

International Energy Star Program has as its basic goals the promotion of efficient energy use

and the reduction of the environmental pollution that accompanies energy consumption by

promoting the manufacture and sale of products that fulfill program standards.

International Energy Star Program standards require that copies come equipped with a Low

Power Mode where energy consumption is reduced after a certain amount of time elapses since

the device was last used, as well as an Off Mode where the device automatically turns itself off

after there is no activity within a set amount of time. When the copier includes printer and fax

functions, the printer and fax must enter a Low Power Mode where power consumption is

automatically reduced after a certain amount of time elapses since they were last used, and they

must also support a Sleep Mode where power consumption is reduced to a minimum when

there is no activity within a set amount of time. This product is equipped with the following

features as a result of its compliance with International Energy Star Program standards.

Low Power Mode

The device automatically enters Low Power Mode when 15 minutes have passed since the

device was last used. The amount of time of no activity that must pass before Low Power Mode

is activated may be lengthened. Refer to Low-Power Mode on page 3-19 for more information.

Off Mode

The device automatically enters Off Mode when 90 minutes have passed since the device was

last used. The amount of time of no activity that must pass before Off Mode is activated may be

lengthened. For more information refer to Sleep Mode on page 3-20.

Sleep Mode (If the copier has printer and/or facsimile function)

The device automatically enters Sleep Mode when 90 minutes have passed since the device

was last used. The amount of time of no activity that must pass before Sleep Mode is activated

may be lengthened. For more information refer to Sleep Mode on page 3-20.

Automatic 2-Sided Copy Function

The Energy Star Program encourages the use of 2-sided copying which reduces the load on the

environment and this device includes 2-sided copying as a standard function. For example, by

copying two 1-sided originals onto a single sheet of paper as a 2-sided copy, it is possible to

lower the amount of paper used. For more information refer to Duplex Mode on page 3-11.

Paper Recycling

The Energy Star Program encourages the use of environmentally friendly recycled paper. Your

sales or service representative can provide information about recommended paper types.

About the International Energy Star Program
