User Guide
[ENGLISH/08-12]
[2]
Package Contents .................................................. 3
Connecting the Microphone ......................................... 4
In-line Controls .................................................... 6
Connect To
PS®Vita ........................................................ 7
PlayStation®3 .................................................. 8
Speaker Tags ..................................................... 10
Troubleshooting ................................................... 11
Warranty ......................................................... 12
Technical Support ................................................. 13
Table of Contents
[3]
Package Contents
Quick Start Guide
Kunai Headset
In-line Audio Controller with Breakaway
Removable Microphone
[4]
Connecting the Microphone
1. Line up the arrows on the microphone and the headset.
[5]
Connecting the Microphone
2. Insert the microphone into the port on the left earcup of the headset.
Firmly push it into place, and then twist it clockwise to lock it in place.
3. Reverse the above steps to remove the microphone.
4. With the microphone removed, insert the included microphone connector
plug to cover the port.
[6]
In-line Controls
Game Audio Volume: Use to adjust
the volume of the game audio.
Voice Communication Volume:
Use to adjust the volume of the
voices of other players.
Mic Mute: Slide the mic mute switch
so that others cannot hear you. The
orange area behind the switch will
show when the mic is muted.
[7]
Connect to PS Vita
Plug the 3.5mm stereo audio connector into the 3.5mm headset jack located
on the bottom of the PS Vita.
[8]
Connect to PlayStation 3
[9]
Connect to PlayStation 3
1. Connect the USB Cable to a USB port on the console.
2. Connect the RCA Connectors to the console AV cable.
3. Plug the headset into the in-line controller.
On the PS3 go to Settings > Sound Settings and change the audio output to be
“Audio Input Connector / SCART / AV Multi.”
On the PS3 go to Settings > Accessory Settings > Audio Device Settings, and
set both the input and output to “TRITTON KUNAI Headset.” You can see a
visual confirmation that the microphone is functioning if the bar graph moves.
[10]
Speaker Tags
1. The speaker tags are held in place with magnets. Remove them by pulling
on the slots located at the top of the speaker plates.
2. To replace the speaker tags, line up the tabs on the speaker tag with the
holes at the bottom of the earcup, and then tilt the speaker tag forward so that
the magnets hold it in place.
