TriStar AT-5464BS Manual de usuario
AT-5464BS
EN| Instruction manual
PARTS DESCRIPTION / ONDERDELENBESCHRIJVING / DESCRIPTION DES PIÈCES / TEILEBESCHREIBUNG /
DESCRIPCIÓN DE LAS PIEZAS / DESCRIÇÃO DOS COMPONENTES / DESCRIZIONE DELLE PARTI /
BESKRIVNING AV DELAR / OPIS CZĘŚCI / POPIS SOUČÁSTÍ / POPIS SÚČASTÍ / ПИСАНИЕ ЗАПЧАСТИ
1
2
3
4
5 6
Instruction manual
3
SAFETY
• By ignoring the safety instructions the
manufacturer cannot be held responsible for
the damage.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Never move the appliance by pulling the
cord and make sure the cord cannot
become entangled.
• To protect yourself against an electric shock,
do not immerse the cord, plug or appliance
in the water or any other liquid.
• The appliance must be placed on a stable,
level surface.
• The user must not leave the device
unattended while it is connected to the
supply.
• This appliance is only to be used for
household purposes and only for the
purpose it is made for.
• This appliance shall not be used by children
aged less than 8 years. This appliance can
be used by children aged from 8 years and
above and persons with reduced physical,
sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Keep the
appliance and its cord out of reach of
children aged less than 8 years. Cleaning
and user maintenance shall not be made by
children unless older than 8 and supervised.
• Empty the tank and refill every third day.
Before refilling, clean it with fresh tap water
or cleaning agents if required by the
manufacturer. Remove any scale, deposits,
or film that has formed on the sides of the
tank or on interior surfaces, and wipe all
surfaces dry.
• Clean the filter regularly.
• Be aware that high humidity levels may
encourage the growth of biological
organisms in the environment.
• Unplug the appliance during filling and
cleaning.
• Never leave water in the reservoir when the
appliance is not in use.
EN
Instruction manual
4
• Empty and clean the air cooler before
storage. Clean the air cooler before next
use.
• WARNING: Microorganisms can grow in the
water reservoir and be blown in the air
causing serious health risks when the water
is not renewed and the tank is not cleaned
regularly and properly.
Cleaning and maintenance
• Always disconnect the power cord from the
socket before any cleaning.
• Clean the outside with a damp cloth. Never
use harsh and abrasive cleaners, steel wool
or a scouring pad as this will damage the
device. Do not immerse in water or other
liquid.
• To clean the water tank; unlock the knob and
pull out of the water tank, pull out the plug at
the bottom of the tank, drain the water
through the small hole, seal with plug and
close the water tank.
• If the fan will not be used for a long period of
time, drain the condensate water and store it
in a dry place.
• This electrical appliance was manufactured
in accordance with the relevant safety
requirements. Repairs should only be carried
out by qualified persons using original spare
parts, otherwise this may result in
considerable danger to the user.
Instruction manual
5
PARTS DESCRIPTION
1. Control panel
2. Air outlet
3. Water level indicator
4. Caster wheel
5. Remote control
6. Ice boxes
Remote control
• 2xAAA size batteries are required.
• Ensure batteries are inserted in the correct direction.
• When replacing, ensure both batteries are changed
simultaneously.
• Press the corresponding buttons as explained in the use part to
operate the cooler.
BEFORE THE FIRST USE
• Take the appliance andaccessoriesoutthebox.Removethe
stickers,protective foilorplasticfrom thedevice.
• Place the device on a flat stable surface and ensure a minimum
of 10 cm. free space around the device. This device is not
suitable for installation in a cabinet or for outside use.
• Putthepower cable intothe socket.(Note: Make surethe
voltagewhich is indicated on the devicematchesthe
localvoltage beforeconnecting the
device.Voltage220V-240V50Hz)
• Fill the water tank. See picture below for instructions.
• To increase the cooling effect, you can put the frozen ice boxes
in the water tank.
USE
• Press the on/off button to turn the fan on or off.
• Press the speed button to select the desired airflow
speed. There are three levels to choose from (high, medium and
low speed).
• Use the swing button to turn on the oscillation mode. The
airflow will now move from side to side. Press the button again to
turn it off.
• When the unit is in on, press the timer button repeatedly
to have the fan automatically stop after 0.5 to 7.5 hours.
EN
Instruction manual
6
• Press the cool button to turn on the cooling function. The
unit will act as a evaporator now. If combined with the ice boxes,
this unit can lower its surrounding temperature even more.
• Use the mode button to select a type of airflow. You can
choose between normal airflow, a natural mode and a sleep
mode. The natural mode will try to simulate natural wind, while
the sleep mode provides a more constant airflow. Experiment with
these functions to see what you prefer.
• If you want to use the ice boxes, remember to put it in the freezer
beforehand. Use them when they are completely frozen.
TABLE
Information requirements for comfort fans P
Information to identify the model(s) to which the information relates
to:
Description Symbol Value Unit
Maximum fan flow rate F 5.18 m³/min
Fan power input P 54.1 W
Service value Sv 0.10 (m³/min)/W
Standby power consumption Psb 0.48 W
Off power consumption Poff N/A W
Fan sound power level Lwa 61.71 dB(A)
Maximum air velocity C 6.03 meters/sec
Season electricity
consumption
Q 17.85 kWh/a
Measurement standard for
service value
EN ISO 5801:2008
ENVIRONMENT
This appliance should not be put into the domestic garbage at
the end of its durability, but must be offered at a central point for the
recycling of electric and electronic domestic appliances. This symbol
on the appliance, instruction manual and packaging puts your
attention to this important issue. The materials used in this appliance
can be recycled. By recycling of used domestic appliances you
contribute an important push to the protection of our environment. Ask
your local authorities for information regarding the point of
recollection.
Support
You can find all available information and spare parts at
www.tristar.eu!
