Tripp Lite BP24V15RT2U Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: BP24V15RT2U

BP24V15RT2U - External Battery Pack for UPS System

Highlights

Extends the runtime of compatible Tripp Lite UPS Systems that accept a 24V

DC external battery connector

Simple installation; 2U rackmount, tower and stack adaptable

Description

BP24V15RT2U rack/tower external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite systems.

Multi-use form factor supports configuration in stacking, upright tower and rackmount applications using only 2 rack spaces (2U). Includes heavy

gauge cabling with high current DC connector for simple installation.

Compatible UPS Systems: OMNIVS1500XL, OMNIVSINT1500XL, SU750XL, SU750RTXL2U, SU1000XLa, SU1000RTXL2Ua,

SUINT1000RTXL2Ua, SMART750RMXL2U and other Tripp Lite UPS systems that specify the use of this battery pack.

Applications

Ideal means of lengthening the battery runtime provided by compatible Tripp Lite UPS systems. Battery pack may be ordered at time of

original UPS purchase or sourced at a later date to extend runtime performance if site power conditions deteriorate and longer battery

runtime is desired.

Package Includes

BP24V15RT2U External Battery Pack

Rack/tower brackets

Owner's manual with warranty information

Features

Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems

Supports stacking or rackmount installation using only 2 rack spaces (2U)

Includes heavy gauge cabling with high current DC connectors for simple installation

NOTE: LIMIT OF 1 BP24V15RT2U PER UPS, SEE BP24V70-3U FOR MULTI-PACK COMPATIBILITY

Specifications

BATTERY

DC system voltage (VDC) 24

Connects to UPS via Attached 24VDC 75amp connector

Typical battery lifespan 4-6 years typical (North America)

PHYSICAL

Shipping weight (lbs) 29.25

Shipping weight (kg) 13.2

Unit Dimensions (HWD/in) 3.5 x 17.25 x 10.5

Unit Dimensions (HWD/cm) 8.89 x 43.8 x 26.7

Shipping Dimensions

(HWD/in)

21.5 x 15 x 29.25

Shipping Dimensions

(HWD/cm)

54 x 38 x 74.3

Unit weight (lbs) 27.25

Unit weight (kg) 12.3

Material of construction Polycarbonate

Form factors supported 2U rack/tower

CERTIFICATIONS

Certifications CE

WARRANTY

Product Warranty Period

(U.S. & Canada)

2-year limited warranty

Product Warranty Period

(International)

1-year limited warranty

Product Warranty Period

(Mexico)

1-year limited warranty

Product Warranty Period

(Puerto Rico)

1-year limited warranty

Optional Coverage 3 year, 5 year, next day and on-site warranty coverage available

Related Items

Optional Products

Product Type Related Model Description Qty.

Extended Warranties WEXT3-BP24V 3-Year Extended Warranty - For All 24V Battery Packs 1

Extended Warranties WEXT5-BP24V 5-Year Extended Warranty - For All 24V Battery Packs 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3827.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
