Tripp Lite EZB-100 Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: EZB-100

100-ft. Easy Pull Long-Run Display Cable - Type-B Digital PVC Trunk Cable

Highlights

Versatile trunk cable allows for a variety of connection options

Easily pulls through conduit or confined spaces with included end caps with

integrated pull tabs

UL20276 Digital Video Cable supports 1080i

Description

Tripp Lite's EZB-100 100 ft. Easy Pull Digital Trunk cable makes pulling video cable through conduit or confined areas a breeze. Threaded ends

feature screw on pull-caps, which can be attached to fish tape. Choose from from HDMI and DVI termination kits that easily screw on to the

threaded ends of the trunk cable. Trunk cables are available in 50 ft. and 100 ft. PVC (Plenum available as custom item). Cable ends are

colored-coded yellow to denote Digital applications (VGA trunk cables are green). Cable features 4pr UL20276 individually shielded twisted pairs,

one twisted pair and five signal conductors. UL20276 Digital Video Cable supports 1080i.

Applications

Use where standard HDMI and DVI cables won't fit, such as conduit or confined wall or ceiling spaces

Package Includes

Easy Pull Type-B Digital PVC Trunk Cable, 100 ft.

Features

Eliminates the need to field terminate HDMI and DVI connectors

Detachable, screw-on connectors

Allows cable to be run according to code - inside conduit, drop ceilings, etc.

Makes pulling long cables fast and easy

Protects entire cable from strain, dirt, debris and damage

Choose from a variety of connector combinations for the perfect fit

Available in 50 ft. and 100 ft. PVC lengths (Plenum cables available upon request)

UL20276 Digital Video Cable supports 1080i

Specifications

OVERVIEW

Intended Application Home Theater/AV, Connecting Peripherals

Display Style Easy Pull

INPUT

Cable Length (ft.) 100

Cable Length (m) 30.48

PHYSICAL

Color Black & Yellow

CONNECTIONS

Connector A

EASY PULL B (FEMALE)

Connector B

EASY PULL B (FEMALE)

Number of Connectors 2

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Video Cables & Adapters EZB-050 50-ft. Easy Pull Long-Run Display Cable

Type-B Digital PVC Trunk Cable

Video Cables & Adapters EZB-DVIF-2 Easy Pull Type-B Connectors

F/F set of DVI (Single-Link) with Faceplates

Video Cables & Adapters EZB-DVIM-2 Easy Pull Type-B Connectors

M/M set of DVI (Single-Link)

Video Cables & Adapters EZB-DVIX-2 Easy Pull Type-B Connectors

M/F set of DVI (Single-Link) with Faceplate

Video Cables & Adapters EZB-HDMIM-2 Easy Pull Type-B Connectors

M/M set of HDMI

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3786.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
