Tripp Lite Thunderbolt MTB3-002-HD Manual de usuario
1
Quick Start Guide
Thunderbolt™3 to
Dual HDMI Adapter
Model: MTB3-002-HD
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Este guía esta disponible en español en la página
de Tripp Lite: tripplite.com/support
Ce guide est disponible en français sur le site Web
de Tripp Lite : tripplite.com/support
Русскоязычная версия настоящего краткого
руководства представлена на веб-сайте
компании Tripp Lite по адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der
Tripp Lite-Website verfügbar: tripplite.com/support
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
2
Product Features
• Compatible with macOS®10.12 and below and
Windows®10 and below
• Supports Ultra High Definition (UHD) 4K x 2K
video resolutions up to 4096 x 2160 (60 Hz),
as specified in HDMI 2.0, when transmitting to
two displays
• Supports up to 36-bit Deep Color (12 bits
per channel)
• Compatible with HDCP 2.2 and previous
HDCP specifications
• Supports chroma subsamplings of YUV 4:4:4,
as well as RGB and YUV 4:2:2
• Plug-and-play adapter—no drivers required
3
System Requirements
Installation
Package Contents
• Thunderbolt 3-enabled Mac or Windows PC
• HDMI-enabled monitor
1. Connect the adapter’s Thunderbolt 3 connector
to the Thunderbolt 3 port on your Mac or
Windows PC.
2. Connect the adapter’s HDMI port to a monitor
using an HDMI cable (such as Tripp Lite’s
P568-Series cables).
3. The video image will appear on the add-on
monitor. Customize how video is displayed on
the add-on monitor using your device’s
display settings.
• MTB3-002-HD
• Quick Start Guide
4
Specifications
Connectors
Input Thunderbolt 3 (Male)
Display 2x HDMI (Female)
Video
Maximum Resolutions Dual Monitor: 4096 x 2160
(60 Hz)
Color Depth 36-bit Deep Color Maxium
(12 bits per channel)
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 85% RH,
Non-Condensing
Storage Temperature 14° to 158°F (-10° to 70°C)
Storage Humidity 10% to 90% RH,
Non-Condensing
Power Requirements
External Power Supply No
5
Warranty and Product Registration
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Some states do not permit limitation
or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
6
Warranty and Product Registration
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply.
See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
7
Warranty and Product Registration
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to
operate this equipment.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos
and illustrations may differ slightly from actual products.
8
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
20-12-305 93-3C2D_RevB
