* Approximate dimensions.
In accordance with Tricel’s normal policy of product development these specications are subject to change without notice.
STOCK CODE:
102212
DIMENSIONS
Dimensions: 1000mm high x 750mm wide x 300mm deep
The overall height of this box is 1066mm and overall width is 754mm.
The opening size is 971mm x 678mm*
KEY FEATURES
• Electromagnetic compatibility, ideal for protecting internal
electronic communication.
• Suitable for low-voltage switchgear and control gear assemblies,
meters, compressors, etc.
• Will not corrode, weather resistant to IP43 grade protection.
• High impact resistance up to 20 Kilojoules (IK10).
• Double insulation and electrically non-conductive (1000V).
• Triple lock system supported by non-corrosive vertical bars.
• Door hinges on right, 180º opening.
• Easily cleaned and can be painted.
SPECIFICATIONS
• Constructed from Glass Reinforced Polymer (GRP).
• Supplied with hinges, lock and key.
• Polyester back mounting plate (optional) available.
• Supplied in light grey colour (Ral 7035).
• Suitable for use in temperatures ranging from -30ºC to +70ºC.
• Made from non-hygroscopic material ensuring minimum water
absorption.
• Constructed from halogen-free and self-extinguishing material.
• UV protected.
IP43 RATED COMMERCIAL
ELECTRIC METER ENCLOSURE
1000 X 750 X 300MM
COMPLIES TO IEC 62208:2011
Suitable for electrical and commercial installations.
Complies with the international standard for empty enclosures as
applied to low-voltage switchgear and control gear assemblies (IEC
62208:2011).
Example: photovoltaic nh-fuses
TRICEL UK
Tel: +44 (0)1453 791616
Registered number 02868648
TRICEL IRL
Tel: +353 (0)64 663 2421
Registered number IE 075014
102212-1177670/1-NOV2022
1066mm
300mm
754mm
