TRENDnet TU2-ET100 Manual de usuario

TRENDnet User’s Guide Cover Page

TRENDnet User’s Guide Table of Contents

Contents

Product Overview....................................................................................2

Package Contents......................................................................................................2

Features....................................................................................................................2

Product Hardware Features.......................................................................................3

Application Diagram..................................................................................................3

Installation on Windows..........................................................................4

Windows 7/Vista ......................................................................................................4

WindowsXP ..............................................................................................................5

Verifying the Driver Installation on Windows.............................................................6

TCP/IP Settings on Windows......................................................................................7

Installation on Mac................................................................................11

MacOS 10.4 ~ Mac OS 10.7.....................................................................................11

Verifying the Driver Installation on Mac...................................................................13

TCP/IP Settings on Mac............................................................................................14

TRENDnet User’s Guide TU2-ET100

Product Overview

TU2-ET100

Package Contents

The package includes:

TU2-ET100

Multi-Language Quick Installation Guide

CD-ROM (Driver & User’s Guide)

If any package contents aremissing or damaged, please contact the retail store,

online retailer, or reseller/distributor that the item was purchased.

Features

The TU2-ET100 is a high speedUSB network adapter that allows you toinstantly

connect toa 10/100Mbpsnetwork from a USBenabled desktop or Notebook PC.

Compliant with USB 2.0 and backwards compatible with the USB 1.0 and 1.1, you can

share files and printers and also gain access to broadband Internet to explore valuable

resources on the web.

Connect your laptop or PC at Fast Ethernet speeds

Quickly share data, music, movies and more

Compact design is ideal for on the go professionals.

TRENDnet User’s Guide TU2-ET100

Product Hardware Features

Product View

USB Port – Connect the USB port to your computer.

Ethernet Port –Connect one end of the network cable to Ethernet Port and the

other end to the Router

LED

LED Color Description

100Mbps Green On for 100Mbps

Off for 10Mbps or not connected

Link Amber LAN activity. Blinking when there is dataflow

between LAN and the host computer.

Application Diagram

TRENDnet User’s Guide TU2-ET100

Installation on Windows

Windows 7/ Vista

1. Insert the Driver CD-ROM into your CD-ROM Drive.

2. Click Run Autorun.exe (Windows 7 & Vista only)

3. Click Install Driver to install the driver.

4. Click Next.

TRENDnet User’s Guide TU2-ET100

5. Click Install.

6. Click Finish.

7. Remove the CD-ROMfrom yourcomputer’sCD-ROM drive.

8. Connect the adapter toan available USBport onyour computer

9. The adapter’s drivers will install automatically.

10. Connect a network cable from the TU2-ET100 to a switch, router or cable/DSL

modem.

Windows XP

1. Insert the Driver CD-ROM into your CD-ROM Drive.

2. Click Install Driver to install the driver.

3. Click Next.

TRENDnet User’s Guide TU2-ET100

4. Click Install.

5. Click Finish.

6. Remove the CD-ROMfrom yourcomputer’s CD-ROM drive.

7. Connect the adapter toan available USBport onyour computer

8. The adapter’s drivers will install automatically.

9. Connect a network cable from the TU2-ET100 to a switch, router or cable/DSL

modem.

Verifying the Driver Installation on Windows

To verify the driver installation on your Ethernet adapter, please launch

Device Manager through the steps below.

On Windows® 7/Vista: Right-click on the Computer icon on the desktop and

select Properties > Device Manager.

On Windows® XP: Right-click on the My Computer icon on the desktop and

select Properties > System > (Hardware) > Device Manager.

TRENDnet User’s Guide TU2-ET100

TCP/IP Settings on Windows

1. Click Start, Control Panel and, then click Network and Sharing Center, and then

clicking Change Adapter settings.

2. Right-click on the Local Area Connection of the adapter, and then click

Properties.

3. Under Networking tab, click Internet Protocol Version 4 (TCP/IPv4) for IPv4

setting or Internet Protocol Version 6 (TCP/IPv6) for IPv6 setting, and then click

Properties.

TRENDnet User’s Guide TU2-ET100

4. Setup the IPv4 IP address:

a. To obtain IP settings automatically, click Obtain an IP address

automatically, and then click OK.

b. To manual setup the IP address, select User the following IPv4 address,

then enterIP addresson the IP address,Subnet Mask, and Default

gateway boxes, and then specify the IP address on the Preferred DNS

server andAlternate DNS server boxes, and then click OK.

TRENDnet User’s Guide TU2-ET100

5. Setup IPv6 IP address settings:

Note: On Windows XP, it required to install IPv6 protocol in order to setup the

IPv6 IP . Please follow the How to Install IPv6 protocol on Windows XP on next

section for instruction.

a. To obtain IP settings automatically, click Obtain an IPv6 address

automatically and Obtain DNS server address automatically, and then

click OK.

b. To manual setup the IP address, select User the following IPv6 address,

then enterIP addresson the IPv6 address,Subnet prefix length, and

Default gateway boxes, and then specify the IP address on the Preferred

DNS server andAlternate DNS server boxes, and then click OK.
