TRENDnet TU2-DVIV Manual de usuario
TU2-DVIV
H/W: V1.0R
Quick Installation Guide
Table of Contents
Table of Contents
Version 06.27.2008
English .....................................................................................................
Troubleshooting ........................................................................................
1
1
3
1. Before You Start
2. .....................................................................................
................................................................................
How to Install
6
System Requirements
Package Contents
1. Before You Start
English
1
?
?Driver CD-ROM
?Multi-Language Quick Installation
Guide
?Mini-USB to Type-A USB cable
?DVI-I to VGA adapter
TU2-DVIV
?
?USB Port: 2.0 or 1.1
?1.2GHz or above
?Memory: 512 MB RAM per monitor
?Available Disk Space: 30MB
?Windows 2000 Service Pack 4/XP Service Pack 2/Vista
?LCD Monitor or Projector with DVI-I or VGA port
CD-ROM Driver
English
2
Application
USB to DVI/VGA Adapter
(TU2-DVIV)
USB to DVI/VGA Adapter
(TU2-DVIV)
C
Extended View (Image divided over multiple monitors)
Mirror View (Image repeated over multiple monitors)
Rotate 90° left Rotate 90° right
A
Rotate 180°
AA
A
AA
A
A
B
Supported viewing angles
2. How to Install
English
3
1. Insert the Driver CD-ROM into your
CD-ROM Drive.
Note: Do not connect the TU2-DVIV to your computer until instructed to do so.
2. Click Run autorun.exe (Windows
Vista only).
3. Click Install Utility & Driver.
5. Click Yes to restart your computer
(Windows 2000/Vista only).
4. Choose the desired language, read
the Software End User License
Agreement and then click I
Accept.
English
4
6. Remove the Drive CD-ROM from
your computer's CD-ROM drive.
9. Repeat steps 7-8 for each
additional adapter. Maximum of 6
adapters can be connected.
1. Connect the DVI monitor cable
directly to the DVI port on the
TU2-DVIV.
Connecting to a DVI monitor
7. Connect the Mini-USB end of the
USB cable to the TU2-DVIV.
8. Connect the Type A end of the
USB cable to an available USB
port on your computer.
English
5
1. Connect the VGA monitor cable to
the VGA to DVI adapter.
2. Connect the VGA to DVI adapter to
the TU2-DVIV.
1. Right click on the utility icon.
Connecting to a VGA monitor
Configure Display Settings
2. Select the desired setting to
change.
Your installation is now complete.
For detailed information regarding the TU2-DVIV configuration and advanced
settings, please refer to User Guide on the Utility and Driver CD-ROM.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
6
Q1:
A1:
Q2:
A2:
Can I connect or disconnect TU2-DVIV while the computer is on?
Yes, you can connect or disconnect TU2-DVIV while the computer is on
because the USB interface is Plug-and-Play compliant and hot-pluggable.
Windows is unable to recognize my hardware. What should I do?
First, make sure your computer meets the minimum requirements as specified
in Section 1 of this Quick Installation Guide. Second, try plugging the adapter into
a different USB port.
If you still encounter problems or have any questions regarding the TU2-DVIV, please
refer to the User's Guide included on the Driver CD-ROM or contact TRENDnet's
Technical Support Department.
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de alimentacón
necesario para su funcionamiento. El uso de un adaptador distinto al mencionado puede producir
daños fisicos y/o daños al equipo conectado. El adaptador de alimentación debe operar con voltaje y
frecuencia de la energia electrica domiciliaria existente en el pais o zona de instalación.
Copyright ©2008. All Rights Reserved. TRENDnet.
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com/register
20675 Manhattan Place
Torrance, CA 90501
USA
