6. Support Pedestal Installation
6.2 After removing the drawers, you must
place the structure of the drawer
underneath the Work Surface, and use
10/12x1" screws to fix the storange unit to
the Work surface. As show on Image 6.2
Image 6.2.
Screws
10/12x1"
Work Surface
(Detail 2)
Plastic Levers
Derecho
(Detail 3)
Izquierdo
1
Detail 3
Image 6.1.
®
6.1 To install Support Pedestals to a Work Surface you must first remove the drawers by following these
steps:
To begin you must remove the top drawer () and once you can see the Plastic Levers you must lower the lever on the
right rail (Detail 2) and move the lever from the left rail up (Detail 3) once you´ve done this the drawer can be
removed from rails (repeat the same process for the next drawer)
