Adjusting Gear Mesh

Incorrect gear mesh is the most

common cause of stripped spur

gears. Gear mesh should be

checked and adjusted anytime

a gear is replaced. To set the

gear mesh, cut a narrow strip

of notebook paper and run it

into the gear mesh. Loosen

the motor screws and slide the

motor and pinion gear into the

spur gear. Retighten the motor

screws and then remove the

strip of paper. You should be

able to run a fresh strip of paper

through the gears without binding them.

3640

46mm

3640

46mm

2578

3x12 BCS

3159

3x10 CS

2577

3x10 BCS

2577

3x14 BCS

4628R

M3/12.5

4628R

M3/12.5

2554

3x6 CS

4690 90T

4686 86T

4683 83T

4676 76T

2542

4x12 CCS

2542

4x12 CCS

2552

3x12 CCS

TRAXXAS.com

Traxxas, 6250 Traxxas Way, McKinney, TX 75070, Phone: 972-549-3000, Fax: 972-549-3011, e-mail: support@Traxxas.com

KC2940-R00 210526

Pro Series Magnum 272R Complete Transmission Instructions

Covers Part #9495

Model 58034-1 Slash shown. Other models are similar.

Please refer to the exploded views included with your

model for detailed assembly.

Tools required:

1.5 mm hex wrench

2.0 mm hex wrench

2.5 mm hex wrench

7 mm nut driver

Motor Screws

Strip of

paper

90-tooth spur gear installed.

24054 Bandit 4683 83T 37054 Rustler 4690 90T

24076 Bandit VXL 4676 76T 37076 Rustler VXL 4683 83T

36054 Stampede 4690 90T 58034 Slash 4690 90T

36076 Stampede VXL 4686 86T 58076 Slash VXL 4686 86T

Visitez Traxxas.com/manuals pour télécharger

les instructions dans votre langue.

Visite la página Traxxas.com/manuals para

descargar el instrucciones en su idioma.

Auf Traxxas.com/manuals, können Sie

anleitung in Ihrer Sprache downloaden.

3642X

12.0 SS

2579

3x15 BCS

2579

3x15 BCS

3642X

12.0 SS

3642X

12.0 SS

3642X

12.0 SS

58034 and 58076 Slash Models only:

Included bumper brace required

for proper fitment with the new

transmission.

5552

5552X

5556 5556

2554

3x6 CS

2554

3x6 CS

2593

3x14 BCS

4676 - 76T

3792

1747

4.0 NL

5116

5x11x4 BB

3229

2.5x10 CS

3229

2.5x10 CS

2578

3x12 BCS

2580

3x20 BCS

2591

3x23 BCS

2580

3x20 BCS 2578

3x12 BCS

2578

3x12 BCS

2422

5646

3x3 GS

5116

5x11x4 BB

5116

5x11x4BB

5116

5x11x4 BB

5116

5x11x4 BB

5119

10x15x4 BB

5119

10x15x4 BB

2578

3x15 BCS

2578

3x15 BCS

2578

3x15 BCS

2578

3x15 BCS

2429

2578

3x12 BCS

3159

3x10 CS

3159

3x10 CS

3351R

9491X

9493

9490X opt.

9490A opt.

9490G opt.

9490P opt.

9490R opt.

9493

9491 opt.

9450

2578

3x12 BCS

9460

9460X opt.

9464 opt.

9490

9489

9494

2754

9492

9480

9492

9450

Pro Series Magnum 272R Transmission Assembly

TRAXXAS.com

Traxxas, 6250 Traxxas Way, McKinney, TX 75070, Phone: 972-549-3000, Fax: 972-549-3011, e-mail: support@Traxxas.com

Tuning the Sealed Differential

The differential is sealed to maintain consistent long-term performance. Changing the oil in the differential with either lower or higher viscosity oil will

vary the performance characteristics of the differential. From the factory, the differential is filled with black lithium grease, but can also be tuned with

silicone differential oil. Only use silicone oil in the differential. The differential has to be removed from the transmission and disassembled to change/

replace the oil.

Follow the steps below to access and refill the sealed differential:

1. Remove the four 2.5x10mm cap screws from the bottom of the transmission to remove the differential cover.

2. Slide the differential out of the transmission case.

3. Remove the 2.5x10mm button-head cap screws from the differential and carefully pull the differential halves apart.

Work over a towel to collect any fluid that drips from the differential.

4. Drain the fluid from the

differential. You may wish to

remove the spider gears from the

differential to make this easier.

5. Place the spider gears back into

the differential carrier (if you

removed them). Fill the carrier

with fluid until the cross pins

are covered.

6. Rejoin the differential halves,

using care to align the screw

holes. Be sure the rubber gasket

is in place or the differential

may leak.

7. Install the 2.5x10mm button-head

cap screws and tighten securely.

8. To reinstall the differential, reverse

the steps.

3229

2.5x10 CS

3229

2.5x10 CS

Sealed Differential Removal

5119

10x15x4 BB

5119

10x15x4 BB

9481

9482

9481

2.5x10 BCS

9481

2.5x10 BCS

9483

6783

9482

9481

Sealed Differential Assembly
