Traxon Technologies Ecue e:bus Manual de referencia

e:bus

Introduction Manual

Edition:

28.07.23 [EN_ebus_manual_v3p0]

Published by:

Traxon Technologies Europe GmbH

Karl-Schurz-Strasse 38

33100 Paderborn, Germany

Read the e:bus Introduction Manual and the Safety Instructions

carefully. Subject to modication without prior notice.

Typographical and other errors do not justify any claim for

damages. Modication of the product is prohibited.

This manual is designed for electricians, system administrators,

and product users.

All product names and trademarks mentioned in this manual are

trademarks of their respective owners.

Except for internal use, relinquishment of the instructions to a

third party, duplication in any type or form - also extracts - as

well as exploitation and / or communication of the contents is not

permitted.

Traxon Technologies Europe GmbH

Sales Operations

Karl-Schurz-Str. 38

33100 Paderborn, Germany

+49 5251 54648-0

[email protected]

Downloads and more information at:

www.ecue.com

Table of Contents

1 Introduction 03

1.1 Advantages of the e:bus system 03

1.2 General information 03

2 Topologies 04

2.1 Wiring 04

2.2 Invalidcongurations 05

3 Cable types and lengths 05

3.1 Cabletypes 05

3.2 General run lengths 06

4 Special cabling conditions 06

4.1 Glass Touch 06

5 e:bus, DALI and DMX 06

5.1 DALI 06

5.2 DMX 06

5.3 Comparison 06

IntroductionManual—e:busIntroductionManual

1 Introduction

This document gives a short introduction to the e:bus system. e:bus is a bus system developed by Traxon

e:cue for secure, bi-directional and fast system link between e:bus enabled user terminals.

1.1 Advantages of the e:bus system

Thee:busnetworkingplatformoersseveralfeaturesforasimpleinstallationandgreatreliabilityinreal

installations.

ye:busisaself-organizingnetwork.Thissimpliescongurationbyaplug&play-likebehaviour.The

addressing happens automatically.

yLinkpower.Userinterfacesaredirectlypoweredovere:bus.Fewerwiresmakethehardware

installation much easier.

yThe connections are a very reliable and a stable communication basis with polarity-insensitive wiring.

At the end of this document (see page 06),youcanndashortcomparisonofe:buswithDALIandDMX

based communication.

1.2 General information

yUptoeightdevicescanbeconnectedtothee:bus,organizedbyasignlemasterdevice.

yFreetopologyarchitectureallowsthedevicestobeconnectedincombinationofstar,busandtree

structures.

ye:bus is designed for cable lengths of up to 400 meters, depending on cable type, topology and number

of connected devices. A bus topology allows the largest cable length.

yThe maximum stub length is 30 cm.

yInterfaces are powered via e:bus.

yInterfaces will be automatically registered and addressed.

yDefectiveunitswillnotaectthecommunicationbetweenotherdevices.

yAmaximumofeighte:busdevices,e.g.e:cueGlassTouches,issupportedbyoneSYMPLe:busNode.

e:bus network communication cables should be seperated

fromhighvoltagepowercables.Followlocalelectricalcodes

with regard to cable placement.

IntroductionManual—e:busIntroductionManual| Introduction



content

2 Topologies

Bus topology

SYMPL e:bus Node

Freetopology

SYMPL e:bus Node

2.1 Wiring

The e:bus is a 2-wire-bus system using screw terminal connectors to attach the wires safely and robust. The

wiringbetweenthedevicesisextremelyexible.Inadditiontothefreetopologydesign,youdonotneedtopay

attention to polarities. As long as the two e:bus connectors of a user terminal are connected to the master

unit’sconnectors,regardlessifacablegoesfrom+to+orfrom+to-,everythingwillworkne.Thetwoe:bus

connectors of a user terminal can be connected to the master unit‘s connectors either way. The terminal

deviceswillrecognizethepolarityontheirownandcongurethemselvestheproperway.

IntroductionManual—e:busIntroductionManual| Topologies



content

2.2 Invalid congurations

Donotaddasecondmastertoane:bus

network!

Donotleaveanywiresopen!Openwireswillcausesignal

reectionsandthereforedisruptcommunication.

SYMPL e:bus Node

SYMPL e:bus Node SYMPL e:bus Node

Donotcreatecreateshort-circuits.

The + and – cables must not be directly

connected!

SYMPL e:bus Node

3 Cable types and lengths

3.1 Cable types

The maximum cable length is greatly dependent on device count, topology and cable types as well. Approved

cabletypesfore:busareAWG16(1.5sqmm)cablesandAWG24(0.28sqmm)Cat5orJ-Y(St)Ycables.The

following table shows valuable key facts:

IntroductionManual—e:busIntroductionManual| Cable types and lengths



content

3.2 General run lengths

Device

count

AWG 16 (1,5 sqmm) AWG 24 (0,28 sqmm)

Cat5 Cable or J-Y(St)Y

bus topology free topology bus topology free topology

1400 m / 1312 feet 100m/328feet 400 m / 1312 feet 100m/328feet

2400 m / 1312 feet 100m/328feet 268m/879feet 100m/328feet

4400 m / 1312 feet 100m/328feet 133 m / 436 feet 100m/328feet

6400 m / 1312 feet 100m/328feet 88m/288feet 82m/269feet

8400 m / 1312 feet 100m/328feet 66 m / 216 feet 61 m / 200 feet

4 Special cabling conditions

4.1 Glass Touch

FortheGlassTouchthevaluesabovearenotvalid.Instead,watchtheserequirements:

yUse2x0.5sqmm.

yUseadirectconnectionfromSYMPLe:busNodetoGlassTouch,nobranching.

yMaximumcablelengthis100m.

5 e:bus, DALI and DMX

5.1 DALI

DigitalAddressableLightingInterface(DALI)isastandardforcontrollightinginbuildings.Itwasestablished

asasuccessorfor0...10Vlightingcontrolsystems,andasanopenstandardalternativetoDigitalSignal

Interface(DSI),onwhichitisbased.TheDALIstandard,whichisspeciedintheIEC60929standardfor

uorescentlampballasts,encompassesthecommunicationsprotocolandelectricalinterfaceforlighting

control networks.

5.2 DMX

DMX512(DigitalMultiplex)isastandardfordigitalcommunicationnetworkstocontrolstagelightingand

eectssuchasfogmachinesandmovinglights.DMX512employsEIA-485dierentialsignalingatitsphysical

layer,inconjunctionwithavariable-size,packetbasedcommunicationprotocolat250kBit/s.Itis

unidirectionalanddoesnotincludeautomaticerrorcheckingandcorrection.DMXisthemostused

connection type in lighting control.

5.3 Comparison

Feature e:bus DALI DMX

Includes protocol   

Self-organizing network - -

Freetopologywiring   -

Linkpower - -

Polarity-insensitive - -

High-Speed signaling -

IntroductionManual—e:busIntroductionManual| Special cabling conditions



content

Please check for the latest updates and changes on the Traxon website.

www.traxon-ecue.com
