Transcend USB JetFlash Manual de usuario
USB
128MB–512MB JetFlash™
User’s Manual
Table of Contents
Introduction
Package Contents.................................................................................... 1
Features .................................................................................................... 1
System Requirements ............................................................................. 2
Before Use ................................................................................................ 2
Driver Installation
Driver Installation for Windows 98SE..................................................... 3
Driver Installation for Windows Me, 2000, and XP ................................ 4
Driver Installation for Mac OS 9.0 or Later............................................. 4
Driver Installation for Linux Kernel 2.4 or Later .................................... 5
Data Storage...................................................................................... 5
Uninstall................................................................................................. 6
How to Unplug JetFlash Safely
To Remove JetFlash in Windows 98SE.................................................. 7
To Remove JetFlash in Windows Me, 2000, and XP ............................. 7
To Remove JetFlash in Mac OS.............................................................. 7
To Remove JetFlash in Linux ................................................................. 7
Product Overview.......................................................................... 8
Basic Operation
Enter MP3 Mode ....................................................................................... 8
Enter Record Mode .................................................................................. 8
Play a Track .............................................................................................. 9
Pause a Track........................................................................................... 9
Advance to Next Track ............................................................................ 9
Reverse to Previous Track ...................................................................... 9
Fast Forward ............................................................................................ 9
Fast Reverse............................................................................................. 9
Increase Volume ...................................................................................... 9
Decrease Volume ..................................................................................... 9
Repeat a Track ......................................................................................... 9
Repeat All Tracks................................................................................... 10
Repeat a Portion of One Track (AB Repeat) ........................................ 10
Hold......................................................................................................... 10
MP3 Function
To Download or Upload MP3/WMA files .............................................. 10
To Play MP3 Music................................................................................. 11
AB Repeat Function .................................................................. 11
Voice Recording Function
To Record Voice..................................................................................... 11
To Play the Recorded Files ................................................................... 12
LED Indication ................................................................................ 13
Recover JetFlash
To Recover JetFlash in Windows 98SE ............................................... 13
To Recover JetFlash in Windows Me, 2000, and XP ........................... 17
Troubleshooting............................................................................ 23
Specifications................................................................................. 26
Ordering Information................................................................ 26
Warranty
1
Introduction
Thank you very much for purchasing Transcend’s JetFlash™. This small device is more
than a USB Flash Drive. It combines a USB Flash Drive with MP3, AB repeat, and voice
recording functions. With a USB connector, it can expedite exchanging huge amounts of
data between any desktop or laptop computers with a USB port. With the MP3 function,
you can upload or download music files to or from a PC and use JetFlash as an MP3
player. With the AB repeat function, you can continuously replay a designated section of a
track. With the voice recording function, you can also use JetFlash as a digital recorder. In
addition, JetFlash’s mobility, strong data retention ability, and impressive appearance will
provide you with a brand-new data storage experience.
Package Contents
The JetFlash package includes the following items:
•JetFlash
•AAA battery
•Earphone with neck strap
•Driver CD
•USB extension cable
•Quick Installation Guide
Features
•USB 1.1 compliant and USB 2.0 compatible;
•Expedited Data Transfer: Maximum transfer rate up to 12Mbit/sec at full speed;
•Power Supply: For data transfer, JetFlash is powered directly via the USB port,
and no external power or battery is needed. To use it as an MP3 player or digital
recorder, one AAA battery is necessary. (One AAA alkaline battery can support
up to 12 hours of operation);
•Operating Systems Supported: Windows®98SE, Windows®Me, Windows®2000,
Windows®XP, Mac™ OS 9.0 or later, and Linux™ kernel 2.4 or later. Only
Windows®98SE needs the enclosed driver;
•MP3 Function: Supports MP3 and WMA formats and so can be used as an MP3
player;
•Supports AB repeat, enabling JetFlash to continuously replay a designated
section of a track;
•Voice Recording Function: Supports WAV format, thus making JetFlash a digital
2
recorder;
•Power Saving Function: Auto-powers off after two minutes without use.
•LEDs indicate the usage status of JetFlash.
System Requirements
Desktop or notebook computer with USB port
One of following operating systems:
•Windows 98SE
•Windows Me
•Windows 2000
•Windows XP
•Mac OS 9.0 or later
•Linux kernel 2.4 or later
Before Use
1. Keep JetFlash away from heat, direct sunlight, and moisture. Do not bend, flex, or
drop JetFlash.
2. Make sure the HOLD switch is set to the “OFF” position.
3. Plug or unplug JetFlash by grasping the sides.
4. Never use the “Quick Format” or “Full Format” of Windows to format your
JetFlash.
5. Follow the procedures in “How to Unplug JetFlash Safely” to remove JetFlash from
the system.
3
Driver Installation
Driver Installation for Windows 98SE
1. Put the Driver CD into the CD-ROM (Auto-Run supported). Click Win98 Driver button.
2. Click Next to continue.
3. The Install Shield Wizard guides you through the installation process.
4
4. Plug JetFlash into an available USB port. Your computer automatically detects this
new device. A new Removable Disk drive with a newly assigned drive letter appears
in the My Computer window.
Driver Installation for Windows Me, 2000, and XP
No driver is required. These Windows operating systems have built-in drivers to support
JetFlash. Simply plug JetFlash into an available USB port, and Windows installs the files
needed to use it. A new Removable Disk drive with a newly assigned drive letter appears
in the My Computer window.
Driver Installation for Mac OS 9.0 or Later
No driver is required. Just plug JetFlash into an available USB port and your computer
automatically detects it.
5
Driver Installation for Linux Kernel 2.4 or Later
No driver is required. Just plug JetFlash into the USB port and mount it.
Example: 1. Create directory of /mnt/JetFlash first:
mkdir /mnt/JetFlash
2. mount JetFlash:
mount –a –t msdos /dev/sda1 /mnt/JetFlash
Data Storage
After installing the driver, simply plug JetFlash into an available USB port and you can use
it like a hard drive or other data storage device.
WARNING: To prevent loss of data and/or damage to JetFlash, never remove a
JetFlash from a device while LED is flashing.
WARNING: To prevent the malfunction of JetFlash, never press the PLAY/PAUSE
button while JetFlash is connected with a USB Port.
6
Uninstall
1. Put the Driver CD into the CD-ROM (Auto-Run supported). Click Win98 Driver
button.
2. Click OK to continue.
How to Unplug JetFlash Safely
Before removing JetFlash, please make sure the LED is not flashing! If you
remove JetFlash while the LED is flashing, unpredictable damage to the files or
JetFlash may occur.
When JetFlash is unplugged, it automatically enters MP3 mode. To exit MP3
mode, press and hold the PLAY/PAUSE button until the Power/Play
LED turns off.
7
To Remove JetFlash in Windows 98SE
Unplug JetFlash from your system directly when data are not transferring.
To Remove JetFlash in Windows Me, 2000, and XP
1. Click the icon on the system tray.
2. The Safely remove USB Mass Storage Device pop-up menu will appear. Click to
continue.
3. A message box appears: The ‘USB Mass Storage Device’ device can now be
safely removed from the system.
To Remove JetFlash in Mac OS
Drag and drop the Disk icon corresponding to JetFlash into the trashcan. Then unplug
JetFlash from the USB port.
To Remove JetFlash in Linux
Execute umount /mnt/JetFlash to un-mount the device.
