StoreJet 25 mobile

User’sManual

(Version 1.0.7)

TableofContents

Introduction ......................................................................................1

PackageContents ............................................................................1

Features ............................................................................................2

SystemRequirements .....................................................................2

SafetyPrecautions ..........................................................................3

General Use...................................................................................................................3

Backing UpData............................................................................................................3

Transporting..................................................................................................................3

Power..............................................................................................................................3

Reminders......................................................................................................................4

ProductOverview ............................................................................5

DriverInstallation ............................................................................6

DriverInstallation forWindows2000, XPand WindowsVista...............................6

DriverInstallation forMac OS 9.0, orLater...............................................................6

DriverInstallation forLinux Kernel2.4,or Later......................................................6

Connecting to aComputer ..............................................................7

Disconnectingfrom a Computer ....................................................9

Removing theStoreJet25inWindows2000,XP and WindowsVista .................9

Removing theStoreJet25inMac OS9.0, or Later..................................................9

Removing theStoreJet25inLinux Kernel 2.4, or Later..........................................9

Formatting theHardDrive ............................................................10

Windows®2000/XP......................................................................................................10

WindowsVista ..........................................................................................................11

Troubleshooting ............................................................................15

Specifications ................................................................................17

Ordering Information .....................................................................17

Transcend LimitedWarranty ........................................................18

Introduction

Congratulations onpurchasingTranscendsStoreJet 25 mobile.Thistiny,ultra-portable,

high-speedUSB storagedevice isthe perfectdatamanagementsystemforuploading,

downloading,storing andtransferring yourvitaldataand information.Withitshugestorage

capacityand fast480MbpsUSB 2.0datatransferrates,the compactStoreJet25 isidealfor

carrying yourfiles,folders,documents,photos,musicand videos toand fromdesktopornotebook

computers.Inaddition,the StoreJet25 comeswithveryusefulsoftware*thatcan increase your

mobileproductivity.ThisUser sManualisdesignedtohelpyou getthemostfromyournew device,

please read bothindetail beforeusingtheStoreJet 25.

*Note:The StoreJet elite softwareonlyworks in Windows- pleaseseetheSoftwareUser'sManual for details

PackageContents

TheStoreJet 25packageincludes thefollowingitems:

StoreJet 25 mobile

1MiniUSB to2Standard-AUSB cable(USB Ycable)

QuickStartGuide

Features

Hi-Speed USB 2.0compliant and backwards compatiblewithUSB 1.1

EasyPlugandPlayinstallation

HighcapacityHardDiskDrive

Durableanti-shockrubber outercase

Ultra-portability

OneTouchAuto-Backupbutton

Powered viathe USB port. Noexternalpower orbatteryneeded

High-Speeddatatransfer ratesup to480Mbitsper second

Includes StoreJet elite softwarepack: (helps you manageyour data)

LED indicates power on, datatransferactivity

System Requirements

Desktop or notebookcomputer withaworking USB port.

One offollowingOperating Systems(OS):

• Windows2000

• WindowsXP

• WindowsVista

• MacOS9.0, or later

• LinuxKernel2.4,orlater

SafetyPrecautions

Theseusageand safetyguidelines are IMPORTANT! Please followthem carefully.

Please ensurethatyou connecttheUSB cabletotheStoreJet25 and your

computercorrectly(smallend àStoreJet 25,largeend àPC)

General Use

• Carefullyunpack thecontentsof theStoreJet 25package.

• Duringoperation,avoidexposingyourStoreJet25toextremetemperaturesabove55 ,

or below5 .

• Donot drop yourStoreJet 25.

• Donot allowyour StoreJet 25tocomeincontactwithwater oranyother liquids.

• Donot use adamp/wet clothtowipe or clean the exterior case.

• Donotstoreyour StoreJet 25inanyof thefollowing environments:

o Direct sunlight

o Next toanair conditioner, electricheaterorotherheat sources

o Inaclosed carthatisindirectsunlight

o Inanareawithstrongmagneticfields or excessivevibration

Backing UpData

• Transcend does NOTtake anyresponsibilityfordataloss,ordamageduring

operation.Ifyoudecide tostoredataon yourStoreJet25westronglyadvise thatyou

regularlybackupthedatatoacomputer, or otherstoragemedium.

• ToensureHigh-Speed USB 2.0datatransferrates when usingyourStoreJet25 witha

computer,please checkthatthe computerhastherelevantUSB drivers.Ifyou are

unsureabouthowtocheck this,pleaseconsult thecomputerormotherboardUsers

Manualfor USB driver information.

Transporting

• DonotpackyourStoreJet25 intoluggagewithouttheproperpaddedsupport.Other

itemsinthe luggagemaydamageyourStoreJet25 ifitdoes nothavethe proper

protection.

• Avoidsqueezingyour StoreJet25 (topreventdamagetothe internalHDD).

• Avoidplacingobjectsontoyour StoreJet25 (toprevent compression damage).

Power

• The StoreJet25 ispowered directlyviaacomputerUSB port.However, the power

supplied bythe USB porton someoldercomputersisbelowthe5VDCrequiredto

powerthe StoreJet25.Inthisinstance,please connectthesparelargeconnectorof the

provided USB Ycabletoasecond USB portonthe computer,thiswillprovide the

additionalpower necessarytorun the drive.

• Please use the MiniUSB toUSB A-Type cablethatcamewiththe StoreJet25 to

connectit toacomputer,andalwaysensurethatthecableyou areusing isingood

condition. NEVER useacablethatisfrayed or damaged.

• EnsurenothingisrestingontheUSB cableandthatthecableisnot locatedwhereit can

be tripped over orsteppedon.

Reminders

Alwaysfollowthe procedures inthe “Disconnecting fromaComputer”section toremovethe

StoreJet fromyour computer.

TheextraUSB connectorprovides additionalpowerforthe

StoreJet 25

Product Overview

Figure1: StoreJet25 mobile

OneTouchAuto-Backup Button

Mini USB Port

DriverInstallation

DriverInstallation forWindows2000, XPand WindowsVista

Nodriversarerequired.TheseWindows®Operating Systemshavebuilt-indriverstosupportthe

StoreJet25.PlugyourStoreJetintoanavailableUSB portandWindowswill install thenecessary

files.Anew LocalDisk drivewithanewlyassigned driveletterrepresentingthe StoreJet25 will

appear inthe MyComputer window.

DriverInstallation forMac OS 9.0, orLater

Nodriversarerequired.PlugyourStoreJet25 intoan availableUSB port and yourcomputerwill

automaticallydetect it.

Figure2: MacDriver Installation

DriverInstallation forLinux Kernel2.4,or Later

Nodriversarerequired. Plugyour StoreJet25 intoaUSB portand mount it.

1. First createadirectoryforthe StoreJet25.

Example: mkdir/mnt/Storejet

2. Then,mounttheStoreJet 25.

Example: mount –a –tmsdos/dev/sda1 /mnt/Storejet

Connecting toaComputer

Ifyou wanttousetheStoreJet25as anexternalharddrivetoupload/download datatoandfrom

your computer, you willneed toconnect it toaUSB port on the computer usingtheprovided USB

Y-cable.

Figure3: Mini USB toStandard-AUSB cable (USBY-cable)

1. Plugthe small end oftheUSB Y-cableintothe MiniUSB porton the StoreJet 25.

2. Plugthelargeendofthe cableintoanavailableUSB port onyourdesktop,ornotebook

computer.

*Onsomeoldercomputers,the powersupplied by the USBport isbelowthe required 5VDC

power.Inthisinstance,please connectthe sparelargeconnectoronthe provided USBY-cable

toasecondUSB portonthe computer.Thiswillprovide the additionalpowernecessarytorun

the drive.

Figure4: ConnectingtoaComputer

3. WhentheStoreJet25 issuccessfullyconnected toacomputer, the StoreJetsPowerLED will

lightup,anew LocalDisk drivewithanewly-assigneddriveletterwill appearinthe My

Computer window,and aRemovableHardwareicon will appearon theWindowsSystem

Tray. The StoreJet25sinternalharddrivecomespre-formattedfor FAT32.

Figure5: *F:is an exampledriveletter,theletter inyour "MyComputer"windowmaydiffer

4. Once connected,you canuse the StoreJet25 asan externalharddrivetotransferdatatoand

fromyourcomputer. Simplydrag and dropfiles or foldersontothe LocalDisk driveletterthat

representsthe StoreJet 25.

5. Ifyou haveinstalled thebundled StoreJet elite software,you can pressthe StoreJet25s

OneTouch “BackupButton”toinstantlybackupyourdata(see theStoreJet elite Software

User sManualfor details).

Figure6: OneTouchAuto-Backup Button
