Removing the Original Rear Frame
1. Firstly undo the seat quick release clip
2. Slide the seat all the way forward so that the seat is out of the way
3. Using the 13mm socket and spanner remove the three M8 bolts holding the
rear section of the frame onto the main frame
4. Remove the rear frame from the main frame by lifting it upwards
Installing the Replacement Rear Frame
1. Place the new rear frame onto the main section of the frame ensuring that all
three mounting holes line up with the original frame
2. Using the three M8 high tensile bolts provided in the conversion kit, a 6mm
allen key, and a 13mm spanner, attach the replacement rear frame to the main
frame using the original mounting holes
Installing the Spur Gear Drive to the Rear Frame
1. In the kit are two pre-assembled Spur Gear Drives (SGD) with axles already
installed. One is the left side and one the right side. Slide the axles into the
25mm box section with the motor facing backwards and SGD bashguard at
the bottom.
2. Place three M8 x 50mm hex bolts with M8 washers through the rear frame and
into the top of each axle and tighten with a 13mm socket or spanner.
3. On the bottom of the axe place an M8 flange nut on the remaining thread
and tighten using a 13mm socket or spanner.
