Two Wheel Tractors
with PowerSafe®Clutch
MODELS 710 ●728 ●738 ●740 ●750
Operating Instructions
Before commissioning the machine, read operating instructions
and observe warning and safety instructions.
Two Wheel Tractor Power Unit
Page 2 TWT/PU/0616
Contents
Page 3 Safety
Page 4 Controls Diagrams - 710 & 728
Page 5 Controls Diagrams - 738 & 740 & 750
Page 6 Controls Description
Page 7 Assembly Instructions
Page 8 Attaching Implements
Page 9 How to Start Petrol Engine
How to Start Diesel Engine
Page 10 Operation
How to Stop Engine
Page 11 Maintenance Guide
Page 12 Maintenance Programme
Page 13 Service Information
Page 15 Troubleshooting Guide
Page 16 Risk Assessment
Page 17 Service Record
No liability will be accepted for any damage caused to persons or property
through failure to observe the operating and safety instructions.
!
IMPORTANT READ CAREFULLY
Two Wheel Tractor Power Unit
TWT/PU/0616 Page 3
Safety
ALWAYS start the engine in the open air
DO NOT smoke when refuelling
DO NOT mix OIL with the fuel
ALWAYS stop the engine before making any adjustments, refuelling, moving or
cleaning, or when the unit is unattended
USE ONLY fuel from containers designed for this purpose - refuel outdoors only and
replace the tank cap securely
IN CASE of petrol spillage move the machine away from the area of spillage and allow
the petrol vapours to dissipate before starting the engine
DO NOT remove any safety guards that are tted
DO NOT touch any moving parts or attempt any maintenance whilst the machine is
running - KEEP HANDS AND FEET AWAY
BEFORE starting work clear the work area of any objects that could damage the
machine
DO NOT allow children or anyone uninstructed to operate the machine - KEEP
ANIMALS AWAY
DO NOT use on slopes or banks of more than 20o
ALWAYS wear suitable clothing to give personal protection including footwear that
offers a good grip
AVOID wearing loose garments that may catch in moving parts
KNOW how to stop the machine in an emergency
NEVER interfere with any control settings on the engine
NEVER select reverse gear with your back to a wall or other immovable object
IF A FAULT develops DO NOT attempt any repair - immediately contact the supplier
from whom the machine was obtained
VISUALLY INSPECT the machine before use - ensure all nuts and bolts are tight and
not worn or damaged - replace if necessary
KEEP IN MIND the operator is responsible for accidents or hazards occurring to people
or property
Two Wheel Tractor Power Unit
Page 4 TWT/PU/0616
Controls
A
C
B
N
F
E
D
G
H
L
BCS 728
A
C
B
N
E
D
G/H
F
BCS 710
Two Wheel Tractor Power Unit
TWT/PU/0616 Page 5
Controls
A
C
B
N
F
E
D
G
H
L
L
M
A
C
B
N
F
E
D
G
H
M
O
P
BCS 740 & 750
BCS 738
Two Wheel Tractor Power Unit
Page 6 TWT/PU/0616
Controls Description
Models 710 - 728 - 738 - 740 - 750
(A) OPC LEVER (red lever that stops the machine when released)
(B) ENGINE STOP LEVER
(C) CLUTCH CONTROL LEVER
(D) GEAR LEVER (the location of different gears are shown on the selector)
(E) PTO LEVER (there is a safety device that prevents engagement with reverse gear)
(F) THROTTLE LEVER
(G) HANDLEBAR HEIGHT ADJUSTMENT LEVER
(H) STEERING COLUMN SWIVEL LEVER
(L) FORWARD/REVERSE LEVER (always engage the clutch before engaging this lever)
(M) DIFFERENTIAL LOCK LEVER
(N) PARKING BRAKE LEVER
(O) RIGHT BRAKE LEVER
(P) LEFT BRAKE LEVER
Two Wheel Tractor Power Unit
TWT/PU/0616 Page 7
Assembly Instructions
1. Remove the machine from its packing case.
2. Rotatethehandlebarstemtotheoperatingpositionandtthehandlebars-checkoperationand
routing of cables.
3. Fit the wheels, ensuring the correct rotation (see diagram A below) and check the tyre pressures
(20psi).
4. Fit the gearbox dipstick.
5. Check the engine oil level.
6. Follow the instructions in this Owner’s Manual to run the machine.
Diagram A
Two Wheel Tractor Power Unit
Page 8 TWT/PU/0616
Attaching Implements
Models 710 - 728 - 738 - 740
Implementsareeithermounteddirectlytotheange
(g.12,A)
or coupled with the quick release
assembly
(g.13,C)
. It is important that nuts
(g.13,D)
which fasten the implement and the
bushing are well tightened.
Model 750
Implements are mounted directly to the machine coupler
(g.14,A)
by attaching the coupler
(g.
14, C)
thatisxedtotheimplement.
Thettingandremovalofattachmentsisachievedbyrotatingtheknob
(g.15,R)
. The the device
islockedbyturningtheknobclockwiseandunlockedbytheknobanti-clockwise.Itisimportantthat
nuts
(g.15,D)
which fasten the implement and the bushing are well tightened.
Fig. 12 Fig. 13
Fig. 14 Fig. 15
R
A
C
D
AC
D
Two Wheel Tractor Power Unit
TWT/PU/0616 Page 9
To Start Petrol Engine
To Start Diesel Engine
Using the dipstick provided, check the engine oil level. Top up with 10w/40 oil if necessary.
Checkfuellevel.Onlyuseunleadedpetrolfromacleancontainer.Neverre-fuelwhentheengineis
hot or running. Leave 1” air space in the fuel tank.
Turn the fuel tap to ‘ON’ position, if the engine is cold set the choke lever to ‘ON’ position.
Beforestartingtheengineensurethegearlever(D)isinneutralpositionandthepowertake-off
(PTO) lever is disengaged (E).
Apply half throttle (F).
Move the engine stop lever (B) to position 1 ‘ON’.
Pull the recoil start handle gently until it engages then give it a good strong pull to start the engine.
When the engine has started, release the choke lever after a few seconds and return the throttle
lever (F) to idle position.
Kohler Diesel Engines
Using the dipstick provided, check the engine oil
level. Top up with 10w/40 oil if necessary.
Check fuel level. Only use diesel from a clean
container.Neverre-fuelwhentheengineishot
or running.
Before starting the engine ensure the gear lever
(D)isinneutralpositionandthepowertake-off
(PTO) lever is disengaged (E).
Apply ¾ throttle (F).
Move the engine stop lever (B) to position 1 ‘ON’.
Pull the recoil start handle gently until it
engages then give it a good strong pull to start
the engine.
Once the engine has started return the throttle
lever (F) to idle position.
Yanmar Diesel Engines
Using the dipstick provided, check the engine oil
level. Top up with 10w/40 oil if necessary.
Check fuel level. Only use diesel from a clean
container.Neverre-fuelwhentheengineishot
or running.
Before starting the engine ensure the gear lever
(D)isinneutralpositionandthepowertake-off
(PTO) lever is disengaged (E).
Apply ¾ throttle (F).
Move the engine stop lever (B) to position 1 ‘ON’.
Press and hold the decompression lever on top
of the engine.
Pull recoil start handle gently until it engages
then, keeping the decompression lever
depressed,slowlypulltheengineover2-3times
to prime the engine.
Release the decompression lever and gently pull
over the engine until compression is felt.
Press, but do not hold, the decompression lever
and give the starter handle a good strong pull to
start the engine.
Once the engine has started return the throttle
lever (F) to idle position.
Two Wheel Tractor Power Unit
Page 10 TWT/PU/0616
Operation
Use handlebar adjuster (G) to set handlebar height.
Hold the handlebar and pull up the clutch lever (C).
Depress the OPC lever (A) and select the correct working speed using the gear lever (D).
Ensure forward/reverse lever is in the correct position to move forward (L):
If the handlebars are positioned over the engine then this lever should be in the fully back
position.
If the handlebars are positioned over the implement then it should be in the fully forward
position.
Engage drive to the working implement by using the PTO lever (E):
If the handlebars are positioned over the engine then pull the PTO lever (E) towards you.
If the handlebars are positioned over the implement then push the PTO lever (E) away from
you.
Release clutch lever (C) slowly and fully, keeping the red machine stop lever depressed as the
machine will stop if released.
Movethethrottlelevertothecorrectpositionfortheimplementyouareoperating-pleasereferto
the Implement Manual.
Commence work
Close the throttle (F).
Engage clutch lever (C).
Locate gear lever (D) in neutral position.
Disengage drive to the digging knives by pulling the PTO lever (E) backwards.
Release clutch lever (C).
Release the OPC lever (A) completely.
Move the engine stop lever (B) to position O ‘STOP’.
WARNING: THE EXHAUST COVER MAY BE HOT - DO NOT TOUCH.
To Stop Engine
