TPL VISION LITE LBAR+ Series Manual de usuario

Preamble

This notice includes all the advice and warnings that enables a correct set up and a safe use of the product.

TPLVision can not be responsible for the bad use of the notice. If so, TPL Vision cancels the guarantee’s effects.

rISk claSS

Colour Class Risk

White WHI, Green 525 nm, Red 630 nm 0none

UV 405 nm, Blue 470 nm, IR 850 nm 1low

UV 365 nm 2moderate

UV 385 nm 3high

In all cases, TPL Vision recommends

the use of the protection glasses

that are listed in its catalog.

For more information about photo-

biological risks, do not hesitate to

USer gUIde

TPL Vision can provide calculation notes about the nominal distance of eye risks (security distance).

BEWARE to the infrared light, invisible to the eyes.

To know if the light is on, please refer to the LED indicators.

The EN-62471 norm about lighting uxes enables the classication of led lightings in 4 distinct groups, according

to their hazardousness degree. Please nd below an indicative table, recapitulating the classes of risk for our

standard products.

UnPackIng

Products are packed in our factory, using suitable materials for a safe transport through the usual means of trans-

portation, in France and internationally. However, a damaged package must be reported to the carrier on delivery.

Hand-written reservations must be indicated on the delivery order. Moreover, please send a letter or an email to

TPL Vision as soon as possible (up to 24 hours after the delivery). If the transportation damage has not been stipu-

lated on the delivery order and reported to TPL Vision in time, the package will not be taken back nor exchanged.

To open the package, do not use any cutting blade to avoid damaging the product(s). Please use the delivered

accessories, if needed (do not use any other products or equivalents to replace the delivered accessories).

USer gUIde P2/8

* Total length, without connector.

fIxIng

dImenSIonS

led IndIcatorS

Length*

(mm)

Height

(mm)

Width

(mm)

A B C

LBAR+250 283 45 47,6

LBAR+500 533 45 47,6

LBAR+750 783 45 47,6

LBAR+1000 1033 45 47,6

LBAR+1250 1283 45 47,6

LBAR+1500 1533 45 47,6

LBAR+1750 1783 45 47,6

: Strobe LED indicator

: Power LED indicator

SET AT

EQUAL

DISTANCE

nLength (Lg) < 600 mm : 2 M4 nuts

n600 mm < Lg < 1250 mm : 3 M4 nuts

n1250 mm < Lg < 1750 mm : 4 M4 nuts

During the set up, the light has to be switched off and unplugged. Please use the delivered nuts and insert them

in the groove located in the back of the light. The light will be better xed if you spread the attachment points as

indicated on the scheme above. You can also use M4 screws (not supplied) with a tightening torque from 0.5 to

1.5Nm. We also recommend the use of a threadlocker (not supplied) to avoid any risk of loosening.

Nuts M4 – supplied Screws M4 – not supplied

P3/8

The M12 male connector 5 points is COMPLIANT with the M12 female connector 4 points.

In that case, the dimming option is not available.

connectIon

WIrIng

M12 Connector

5 male points

+ 24 V

Ground

PNP

5Dim 0-10V

STROBE PNP

+ 24 V

NPN

Ground

STROBE NPN

+ 24 V

Ground

PNP

+ 24 V

NPN

Ground

CONTINUOUS MODE :

+ 24 V

3GND

5DIM 0-10V

STROBE

NPN

STROBE

PNP 5Dim 0-10V

5Dim 0-10V 5Dim 0-10V

black

brown

blue

grey

white

Dimensions 250 500 750 1000 1250 1500 1750

Max voltage drop in the bar (V) 0,02 0,08 0,18 0,31 0,49 0,70 0,96

Power supply cable : max length 5x0,34²

for acceptable voltage drop (m) >150 >150 >150 116 89 69 55

VOLTAGE DROP

If you use an angled connector, please note that the angle will be the same as shown below.

Front view Top view

USer gUIde P4/8

control

For a longer lifespan, the light can work in strobe mode.

The product is optimised for a lifespan >50kh in a 40°C atmosphere.

In strobe mode, the strobing time is directly equivalent to the time during which the strobe entry is activated.

Strobe PnP & nPn

dImmIng 0-10V

20%

40%

60%

80%

100%

0 2 4 6 8 10

VOLTS

Potential dimming between 0 & 10 V.

At 0 Volts, the productreaches100%

of itslighting power.

PNP : from 5 to 24V for 100% ON. From 0 to 1V for 100% OFF.

NPN : less than 1V for 100% ON. Above 2V for 100% OFF. Max 20V.

Strobe mode

Entrée Déclenchement

Sortie Éclairage

Triggering input

Light

15 µs 10 µs

P5/8

tecHnIcal InformatIon

250 500 750 1000 1250 1500 1750

Max. comsumption (W) 14.4 28.8 43.2 57.6 72 86.4 100.8

Min. functioning Voltage 20V in the light input

Normal functioning Voltage 24V in the light input (±10%)

Max. functioning Voltage 30V in the light input

Max. consumption Strobe signal 5mA

Operating temperature -10° to +40°C / 80% of humidity without condensation.

No thermal shock (max temperature variation: 10°C in 24h)

comParISon Previous versions

lIgHtIng PoWer

DIMENSIONS POWER

Lite LBAR+250 LBAR 4 –30 mm Power LBAR4 +20%

Lite LBAR+500 LBAR 8 –60 mm Power LBAR8 +20%

Lite LBAR+750 LBAR 12 –90 mm Power LBAR12 +20%

Lite LBAR+1000 LBAR 16 –120 mm Power LBAR16 +20%

Lite LBAR+1250 LBAR 20 –150 mm Power LBAR20 +20%

Lite LBAR+1500 LBAR 24 –180 mm Power LBAR24 +20%

Lite LBAR+1750 LBAR 28 –210 mm Power LBAR28 +20%

EQUIVALENCE

Lite LBAR+250 Essential EBAR+250 x 0.75

Lite LBAR+500 Essential EBAR+500 x 0.75

Lite LBAR+750 Essential EBAR+750 x 0.75

Lite LBAR+1000 Essential EBAR+1000 x 0.75

Lite LBAR+1250 Essential EBAR+1250 x 0.75

Lite LBAR+1500 Essential EBAR+1500 x 0.75

Lite LBAR+1750 Essential EBAR+1750 x 0.75

The dimensions of useful surfaces keep on being the same.

eqUIPment maIntenance

CLEANING (when the product is switched off)

Please use a soft and dry cloth. Do not use any abrasive material.

Do not use any cleaning solvent or aggressive chemical product.

TPL Vision recommends to use isopropyl alcohol.

USer SecUrIty

Do respect the power supply voltages and the connection terminals.

Do not modify or dismantle all or part of the product.

Do not connect or clean when power is on.

Do not watch the lighting source directly, and follow the advice below :

• If the workstation enables it, interpose a lter that will stop the lighting radiation under xed or adjustable

frame between the source and the operator.

• When these measures cannot be implemented, supply the operators with glasses (class 4) available for sale

at TPLVision, or with a dedicated protective mask, that will stop the lighting radiation.

• Forbid or limit the direct access to the lighting source (exposure into the radiation axis).

• Establish a security perimeter so as to prevent the operators from approaching the lighting source beyond

therecommendations of the manufacturer, as for eye irritation is concerned.

• In any case, ensure that the chosen means properly reduce the exposition quantities (features of screens or

glasses to be chosen, according to the wavelengths that the operators are exposed to).

USer gUIde P6/8

TPL VISION UK

Brenchley House – School Road – Charing – Kent TN27 0JW – UK

Tel. +44 (0)1738 310 392 – www.tpl-vision.com

Features and presentations liable to changes without notice. Ref.UG-010601-D2, 2020/01 edition.
