TP TP385 Guía rápida

Build Time

1 Hr

TP385

TP Wooden Cubby House

Instructions for assembly, maintenance and safe use.

Robovision Ltd t/a TP Toys

Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England

www.tptoys.com

THIS PRODUCT CONTAINS SMALL PARTS AND SHARP

POINTS. IT IS NOT SUITABLE FOR CHILDREN UNDER 36

MONTHS UNTIL FULLY ASSEMBLED.

THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM

AGES 18+ MONTHS.

ONLY FOR DOMESTIC USE. FOR OUTDOOR USE ONLY.

TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.

CHILDREN MUST NOT USE THIS PRODUCT UNTIL PROPERLY

INSTALLED.

ADULT SUPERVISION REQUIRED.

REMOVE ALL PACKAGING BEFORE GIVING TO YOUR

CHILDREN.

RETAIN PACKAGING FOR FUTURE REFERENCE.

PLEASE RETAIN INSTRUCTIONS AS IT CONTAINS IMPORTANT

SAFETY INFORMATION.

MAXIMUM USER WEIGHT 30KGS

WARNINGS!

We constantly strive to improve our assembly instructions. To see the most current version of this

instruction for assembly, maintenance and safe use, please visit the product page at tptoys.com

TP Wooden Cubby House

Important advice for assembly, maintenance and safe use.

Please retain this information for future reference.

1. Toy must be assembled by an adult before use exactly in accordance with the instructions.

2. Children must not use this product until properly installed.

3. Check all parts are present before you start to assemble the product. Place small parts on a

tray or similar to ensure they are not lost. The manufacturing process can very occasionally

result in sharp edges/waste material so please take care when assembling this product.

4. Ifanypartsaremissingdonotusetheproductuntilthereplacementpartsaretted.

5. Ensure your product is sited on level ground. Failure to do this may put additional stress on

connections and joints and in time could cause them to fail.

6. Ensure your product is located on a soft impact surface like grass. Never locate your product on

hard surfaces like concrete.

7. Avoid locating this product in full sun.

8. Remove all packaging before giving to your children.

9. Equipment should be checked by an adult at the beginning of each season and at regular

intervals during the usage season to ensure it is safe.

10. Pay special attention to all connections and fastenings. Please check regularly all nuts and bolts

for tightness and tighten as required.

11. Parts may need to be replaced if they show signs of wear and tear. Replace any defective parts

in accordance with these instructions.

12. Due to the natural characteristics of timber, it is vital to check your playframe regularly for

splintering, lifting of surface layers of wood or exposure of rough wood. Affected areas must be

rubbed down using coarse sandpaper to restore a smooth, safe surface.

13. Any changes to this toy eg changing or adding an accessory, must be done in accordance with

our instructions. Failure to do this will render your guarantee null and void and may make your

product unsafe.

14. Neverplacetoysnearare.

15. In high winds, ensure outdoor toys are moved to a sheltered position and/or securely staked

down.

16. The age recommendation for this product is clearly stated on the packaging and in these

instructions. Please adhere to it at all times. Adult supervision is required at all times to ensure

children play safely.

17. When you dispose of this equipment please do so responsibly.

TP Wooden Cubby House

2.5m

Dimensions

98.5cm 92cm

102cm

95.5cm

91.5cm

138cm

119.5cm

Safe play free space area

The safe play area refers to the zone

extending 200cm around the toys on all

sides and 250cm above the toy.

The safe play area must be free from all

obstacles.

NOT INCLUDED

TP Wooden Cubby House

Contents

1WP2005 x1

2WP2006 x1

3WP2007 x2

5WP2009 x2

4WP2008 x2

9MW1273 x4

8MW1272 x4

7MW1271 x2

10 MW1274 x1

6MW12718 x1

FA4541 3 x 30mm

Wood screw x13

FA4523 3.5 x 50mm

Wood screw x6

FA4542 3 x 20mm

Wood screw x24

FA4543 3 x 16mm

Wood screw x8

TP Wooden Cubby House

1WP2005 x1 2WP2006 x1 3WP2007 x1

FA4542 3 x 20mm

Wood screw x6

TP Wooden Cubby House

3WP2007 x1

4WP2008 x1

27.5mm

FA4542 3 x 20mm

Wood screw x6

FA4523 3.5 x 50mm

Wood screw x3

TP Wooden Cubby House

4WP2008 x1

5WP2009 x1

27.5mm

FA4523 3.5 x 50mm

Wood screw x3

FA4542 3 x 20mm

Wood screw x4

TP Wooden Cubby House

5WP2009 x1

6MW12718 x1

10 MW1274 x1

FA4542 3 x 20mm

Wood screw x4

FA4542 3 x 20mm

Wood screw x4

FA4541 3 x 30mm

Wood screw x5

TP Wooden Cubby House

FA4541 3 x 30mm

Wood screw x8

9MW1273 x4

8MW1272 x4

7MW1271 x2

FA4543 3 x 16mm

Wood screw x8

TP Wooden Cubby House
