TP-Link TL-POE150S Manual de usuario
User Guide
TL-POE150S
PoE Injector
Rev:2.0.0
7106503015
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice.
is a registered trademark of TP-LINK
TECHNOLOGIES CO., LTD. Other brands and product names
are trademarks or registered trademarks of their respective
holders.
No part of the specifications may be reproduced in any form
or by any means or used to make any derivative such as
translation, transformation, or adaptation without permission
from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2009
TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
http://www.tp-link.com
FCC STATEMENT
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
¾Reorient or relocate the receiving antenna.
¾Increase the separation between the equipment and
receiver.
¾Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
¾Consult the dealer or an experienced radio/ TV technician
for help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate the equipment.
CE Mark Warning
This is a class B product. In a domestic environment, this
product may cause radio interference, in which case the user
may be required to take adequate measures.
CONTENTS
Package Contents.................................................................... 1
Chapter 1 Introduction.......................................................... 1
1.1 Overview of the Production ......................................... 1
1.2 Features ...................................................................... 2
Chapter 2 Identifying External Components....................... 2
Chapter 3 Connecting the PoE Injector............................... 3
Appendix: Specifications........................................................ 5
1
Package Contents
The following items should be found in your package.
¾TL-POE150S PoE Injector
¾One Power Adapter
¾One Ethernet (CAT5 UTP) Cable
¾This User Guide
)Note:
Make sure that the package contains the above items. If any of
the listed items are damaged or missing, please contact with
your distributor.
Chapter 1 Introduction
1.1 Overview of the Production
Thank you for choosing the TL-POE150S PoE Injector. The
Power over Ethernet (PoE*) Injector is able to supply steady
power to Powered Device (PD*) or PoE Splitter over the
Ethernet cable. The Ethernet equipment can work as a Power
Sourcing Equipment (PSE*) with the help of the TL-POE150S
connection.
PoE technology allows the existing Ethernet infrastructure to
transmit electrical power, along with data, to remote IP endpoints
over the Ethernet cables, which can greatly save the cost of the
external power cables. Your network can benefit from PoE
technology for it will ensure the normal working status of your
network while keep the existing Ethernet infrastructure secure.
2
1.2 Features
¾Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3af
standards
¾Compatible with PoE compliant PDs and PoE Splitters
¾Transmits electrical power along with data in one single
cable
¾External 48V DC power supply
¾Supports Plug-and-Play for the devices, without any
configuration
¾Elegant appearance with space-saving mini size
Chapter 2 Identifying External Components
*PoE: This technology describes a system to transmit electrical power, along
with data, to remote devices over standard twisted-pair cable in an
Ethernet network.
*PD: A device powered by a PSE and thus consumes energy. Examples
include powering IP telephones, wireless LAN access points, network
cameras, network hubs, embedded computers etc.
*PSE: A device (switch or hub for instance) that will provide power in a PoE
setup.
POWER+DATA OUT: Connect to the PD or PoE Splitter
with a CAT5 UTP cable.
3
Chapter 3 Connecting the PoE Injector
You can use TL-POE150S PoE Injector with PD or PoE Splitter
to expand your network to where there are no power lines or
outlets, where you wish to fix devices such as APs, IP Cameras
or IP Phones, etc. The following steps will tell you how to
connect the PoE Injector correctly.
1. Use a CAT5 UTP cable to connect port of Ethernet device
(such as a switch, hub or router) to the LAN IN port.
2. Please connect the power adapter properly to a power
socket with provided power cable, and then connect the
other end of the power adapter to the DC 48V port of the
TL-POE150S.
3. Connect the POWER+DATA OUT port of the TL-POE150S
to a PD or a PoE Splitter with CAT 5 UTP cable.
Now, the device can work normally with data and power.
There are two schemes to realize the PoE.
1. If the device supports PoE (take an IP camera with PoE for
example), following topology will work:
LAN IN: Connect to a
network device (such as a
Switch or Router ) with
CAT5 UTP cable.
DC 48
V
:Connect to the
provided power adapte
r
which can supply stead
y
p
ower of 48V DC.
PWR: Power LED, a steady green
light indicates that the PoE system has
detected the PD or PoE Splitter and
the
p
ower ada
p
ter is workin
g
p
ro
p
erl
y
.
4
Scheme 1
2. If the device does not support PoE, it is necessary to have a
PoE Splitter to separate the power and data, transmitting
them detached in one UTP cable and one power cable. Here
we take TP-LINK TL-POE10R Splitter for example. You can
use following topology.
Scheme 2
5
)Note:
¾Do not mistake the power port of the TL-POE150S and
TL-POE10R when choosing the Scheme 2, or else it will
cause serious damage to your network device.
¾If you want to know more details about TL-POE10R Splitter,
please refer to “TL-POE10R User Guide” on our website
http://www.tp-link.com.
Appendix: Specifications
Normal
Standards IEEE 802.3, IEEE 802.3u, IEEE
802.3af
PoE Port
Ports
LAN Port
100BASE-TX / 10BASE-T dual purpose
port
Cabling Type RJ45 CAT 5 UTP cable
LED PWR
Safety &
Emissions FCC, CE
Environmental and Physical
Operating Temp 0℃~40℃(32℉~104℉)
Storage Temp -40℃~70℃(-40℉~158℉)
Operating Humidity
10%~90% RH, Non-condensing
Storage Humidity
5%~90% RH, Non-condensing
