TP-Link TD-W300KIT Manual de usuario

TL-WN821N

300Mbps Wireless N USB Adapter

REV: 3.0.2

1910010447

Specifications are subject to change without notice. is a registered trademark

of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or

registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any

derivative such as translation, transformation, or adaptation without permission from TP-LINK

reserved.

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

•Consult the dealer or an experienced radio/ TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that may

cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized

modifications to this equipment. Such modifications could void the user’s authority to operate the

equipment.

FCC RF Radiation Exposure Statement:

This device has been tested for compliance with FCC RF Exposure (SAR) limits in the typical

laptop computer configuration and this device can be used in desktop or laptop computers. This

device cannot be used with handheld PDAs (personal digital assistants). This device and its

antenna must not be co-located or operated in conjunction with any other antenna or transmitter.

SAR measurements are based on a 5mm spacing from the body and that compliance is achieved

at that distance.

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio interference, in

which case the user may be required to take adequate measures.

National restrictions

This device is intended for home and office use in all EU countries (and other countries following

the EU directive 1999/5/EC) without any limitation except for the countries mentioned below:

Country Restriction Reason/remark

Bulgaria None General authorization required for outdoor use and

public service

France

Outdoor use limited to 10

mW e.i.r.p. within the band

2454-2483.5 MHz

Military Radiolocation use. Refarming of the 2.4 GHz

band has been ongoing in recent years to allow current

relaxed regulation. Full implementation planned 2012

Italy None If used outside of own premises, general authorization is

required

Luxembourg None General authorization required for network and service

supply(not for spectrum)

Norway Implemented This subsection does not apply for the geographical area

within a radius of 20 km from the centre of Ny-Ålesund

Russian Federation None Only for indoor applications

Note: Please don’t use the product outdoors in France.

TP-LINK TECHNOLOGIES CO., LTD

TP-LINK TECHNOLOGIES CO., LTD.

South Building, No.5 Keyuan Road, Central Zone, Science & Technology Park, Nanshan,

Shenzhen, P. R. China

DECLARATION OF CONFORMITY

For the following equipment:

Product Description: 300Mbps Wireless N USB Adapter

Model No.: TL-WN821N

Trademark: TP-LINK

We declare under our own responsibility that the above products satisfy all the technical

regulations applicable to the product within the scope of Council Directives:

Directives 1999/5/EC

The above product is in conformity with the following standards or other normative documents:

ETSI EN 300 328 V1.7.1: 2006

ETSI EN 301 489-1 V1.8.1:2008 & ETSI EN 301 489-17 V1.3.2:2008

EN60950-1:2006

EN62311:2008

Recommendation 1999/519/EC

Person is responsible for marking this declaration:

Yang Hongliang

Product Manager of International Business

CONTENTS

Package Contents .................................................................................................... 1

Chapter 1. Introduction ........................................................................................ 2

1.1 Overview of the product...................................................................................................... 2

1.2 Features ............................................................................................................................. 2

1.3 LED Status ......................................................................................................................... 3

Chapter 2. Installation Guide ............................................................................... 4

2.1 Hardware Installation.......................................................................................................... 4

2.2 Software Installation ...........................................................................................................4

2.2.1 For Windows XP.......................................................................................................... 4

2.2.2 For Windows Vista ...................................................................................................... 9

2.2.3 For Windows 7 .......................................................................................................... 12

Chapter 3. Configuration Guide......................................................................... 16

3.1 For Windows XP............................................................................................................... 16

3.1.1 Current Status ........................................................................................................... 16

3.1.2 Profile Management .................................................................................................. 18

3.1.3 Diagnostics................................................................................................................ 27

3.2 For Windows Vista............................................................................................................ 28

3.3 For Windows 7 ................................................................................................................. 30

Chapter 4. QSS Configuration ........................................................................... 33

4.1 PBC (Push Button Configuration) method ........................................................................ 34

4.2 PIN method ......................................................................................................................37

4.2.1 Enter a PIN into your AP device................................................................................ 37

4.2.2 Enter the PIN from your AP device............................................................................ 38

Chapter 5. Example for Application .................................................................. 40

5.1 Configuration of PSP XLink Online game......................................................................... 40

Appendix A: Specifications................................................................................... 44

Appendix B: Glossary............................................................................................ 45

TL-WN821N 300Mbps Wireless N USB Adapter

Package Contents

The following contents should be found in your box:

¾One TL-WN821N 300Mbps Wireless N USB Adapter

¾Quick Installation Guide

¾One USB cable

¾One Resource CD for TL-WN821N, including:

•TP-LINK Wireless Client Utility (TWCU) and Drivers

•User Guide

•Other Helpful Information

)Note:

Make sure that the package contains the above items. If any of the listed items are damaged or

missing, please contact with your distributor.

Conventions:

The ‘Adapter’ mentioned in this user guide stands for TL-WN821N 300Mbps Wireless N USB

Adapter without any explanations.

TL-WN821N 300Mbps Wireless N USB Adapter

Chapter 1.Introduction

Thank you for choosing TL-WN821N 300Mbps Wireless N USB Adapter.

1.1 Overview of the product

The adapter is an 802.11n client device; it is designed to provide a high-speed and unrivaled

wireless performance for your notebook and PC. With a faster wireless connection, you can get a

better Internet experience, such as downloading, gaming, video streaming and so on.

With the 802.11n technology, higher throughput improvements using MIMO (multiple input,

multiple output antennas), the TL-WN821N’s auto-sensing capability allows high packet transfer

rate of up to 300Mbps for maximum throughput. It has good capability on anti-jamming, it can also

interoperate with other wireless (802.11b/g) products. The adapter supports WEP, WPA and

WPA2 encryption to prevent outside intrusion and protect your personal information from being

exposed.

The Quick Setup Wizard guides you step-by-step through the installation process; the TP-LINK

Wireless Client Utility helps you create a wireless connection immediately.

With unmatched wireless performance, reception, and security protection, the TL-WN821N is the

best choice for easily adding or upgrading wireless connectivity.

1.2 Features

¾Complies with IEEE802.11b, IEEE802.11g, IEEE802.11n standards

¾Supports WPA/WPA2 data security, IEEE802.1x authentication, TKIP/AES encryption, WEP

encryption

¾Supports high rate of up to 300Mbps for maximum throughput, supports automatically adjust

to lower speeds due to distance or other operating limitations

¾Provides USB interface

¾Supports Ad-Hoc and Infrastructure modes

¾Good capability on anti-jamming

¾Supports roaming between access points when configured in Infrastructure mode

¾Ease to configure and provides monitoring information

¾Supports Windows 2000, XP, Windows Vista and Windows 7.

¾Built-in two internal antennas which are listed in a format of 2x2 for two receivers and two

transmitters.

TL-WN821N 300Mbps Wireless N USB Adapter

1.3 LED Status

Status Working Status

On The driver has not been installed.

Flashing Slowly The driver has been installed but there is no data being

transmitted or received.

Flashing Quickly There is data being transmitted or received.

)Note:

When the card failed to connect to a wireless network, the LED may be off. Please choose your

network and try to connect again.

TL-WN821N 300Mbps Wireless N USB Adapter

Chapter 2.Installation Guide

2.1 Hardware Installation

There are two ways to install the Adapter:

1. Plug the Adapter directly to the USB port on your computer.

2. Connect the Adapter and your computer through the USB cable attached in package.

)Note:

The promoted Found New Hardware Wizard screen will pop up when the adapter is installed

correctly. Click Cancel.

2.2 Software Installation

2.2.1 For Windows XP

The Setup steps for Windows 2000 and XP are similar with each other. This user guide takes

Windows XP for example.

1. Insert the Resource CD into your CD-ROM drive, and then Figure 2-1 will appear. To

continue, select the TL-WN821N. There will be a menu including Install Driver & Utility,

QSS Installation and User Guide.

Figure 2-1

2. Click Install Driver & Utility to load the following screen.
