TP-Link HS103 Manual de usuario

User Guide

Kasa Smart Wi-Fi Plug Mini

HS103

Contents

About This Guide ···················································· 1

Introduction ······························································· 2

Appearance ······························································· 3

Set Up Your Smart Wi-Fi Plug Mini ················ 4

Main Device Controls··········································· 5

Congure Your Smart Wi-Fi Plug Mini ········· 6

Create Scenes························································11

Discover Kasa·························································12

About This Guide

This guide provides a brief introduction to Kasa Smart Wi-Fi Plug Mini and the Kasa Smart app, as well as regulatory information.

Please note that features of Kasa Smart Wi-Fi Plug Mini may vary slightly depending on the model and software version you have, and on your location,

language and internet service provider. All images, steps, and descriptions in this guide are only examples and may not reect your actual experience.

Conventions

In this guide, the following convention is used:

Convention Description

Teal Key information appears in teal, including management page text such as menus, items, buttons and so on.

Underline Hyperlinks are in teal and underlined. You can click to redirect to a website.

More Info

• Operating temperature, storage temperature, and other specications can be found on the product page at https://www.tp-link.com.

• Our Technical Support and troubleshooting information can be found at https://www.tp-link.com/support/.

• A TP-Link Community is provided for you to discuss our products at https://community.tp-link.com.

Introduction

Kasa Smart Wi-Fi Plug Mini is a compact home device that turns your typical electrical wall outlet into a controllable, customizable and multi-functional

outlet, enabling you to easily control your lights and household electronic devices via Kasa Smart app on your iOS or Android devices, no matter where

you nd yourself.

Control from Anywhere Compact Design No Hub Required Home Automation

• Control from Anywhere- Manages plugged-in electronics from anywhere with the Kasa Smart app.

• Compact Design- Allows two plugs to be stacked in one wall outlet.

• No Hub Required- Connects to your home’s Wi-Fi network. No need for a hub or extra equipment.

• Home Automation- Set multiple schedules, create scenes and groups, and simulate occupancy while away with away mode.

Supported Load Types:

Heater: ≤1500 W Toaster: ≤850 W

Humidier: ≤260 W Tower Fan: ≤50 W

Iron: ≤1500 W

Appearance

Smart Wi-Fi Plug Mini has a control button to turn on/o devices plugged in, and LED to show you the current status. For detailed information, see the

explanation below:

*HS103 (US version) is used for demonstration in this guide.

Press to turn the socket ON or OFF.

Press and hold (for 5 seconds) until the LED ashes amber and blue alternately to

initiate the app conguring process (SoftAP).

Press and hold (for 10 seconds) until the LED ashes amber rapidly to factory reset

the Smart Plug Mini.

Flashing amber and blue: App conguring process (SoftAP) initiated.

Flashing blue rapidly: Connecting to the network.

Solid blue: Connected to the network.

Flashing amber rapidly: Factory reset.

Solid amber: Initializing, rebooting, or no network connection.

O: The Smart Plug Mini is switched OFF.

Set Up Your Smart Wi-Fi Plug Mini

Follow the steps below to set up your smart plug via Kasa Smart app.

1. Install Kasa Smart app

Get the Kasa Smart app from Google Play or

the Apple App Store, or scan the QR code

below to download it.

2. Log in or sign up with TP-Link ID

Open the Kasa Smart app and log in with

your TP-Link ID. If you don’t have an account,

create one rst.

3. Add Device

Tap the button in the Kasa Smart app,

select Add a Device >Smart Plugs > Smart

Plug Lite / Mini and then follow step-by-step

app instructions to complete the setup.

Main Device Controls

After you successfully set up your smart plug, you will see the home page of the Kasa Smart app. Here you can view and manage all devices that you've

added to Kasa. Tap a smart plug to control and manage it.

Home Page Device Status

Congure Your Smart Wi-Fi Plug Mini

Set Schedule

You can set schedules for your smart plug to turn on/o automatically to simplify your daily rountine.

1. Tap on the Device Status Page. 2. Tap the + icon and select the time and

frequency for your smart plug to turn on or o

automatically.

3. You can also choose to turn your plug on or

o at Sunrise or Sunset, which is based on the

your location.

Set Away Mode

You can set Away Mode for your smart plug to turn on/o automatically at random intervals while you are away to make the appearance that someone

is at home.

2. Set the time period during which your smart

plug will turn on/off automatically and select

the repeating frequency.

1. Tap on the Device Status page.

Set Timer

Set the countdown timer and your smart plug will automatically be turned on/o after the time ends.

2. Set the time period after which your smart

plug will turn on or o automatically.

1. Tap on the Device Status page.
